User Manual
Designed and manufactured by Austin Hughes
UM-CV-751-MRK-Q424V1
dedicated KVM switch and rackmount screen technology
2U Multi-Display Console Drawer
MRK-K17-2L
MRK-F17-2L
MRK-X17-2L
MRK-19-2L
MRK-K17-3
MRK-F17-3
MRK-X17-3
MRK-19-3
MRK-K17-2R
MRK-F17-2R
MRK-X17-2R
MRK-19-2R
www.austin-hughes.com
751
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Austin Hughes CyberView MRK-K17-2L
Summary of Contents for Austin Hughes CyberView MRK-K17-2L
- Page 1 KVM switch and rackmount screen technology User Manual 2U Multi-Display Console Drawer MRK-K17-2L MRK-K17-3 MRK-K17-2R MRK-F17-2L MRK-F17-3 MRK-F17-2R MRK-X17-2L MRK-X17-3 MRK-X17-2R MRK-19-2L MRK-19-3 MRK-19-2R Designed and manufactured by Austin Hughes UM-CV-751-MRK-Q424V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, December 2024 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents < Part. 1 > Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations / OSD Product Specifi cations P.10 Keyboard / Mouse Specifi cations P.16 On-screen Display Operation ( OSD ) P.19 < Part. 3 > Options 3G / HD / SD-SDI Broadcast-grade input P.22...
- Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content MRK-K17 unit X 1 MRK-F17 / - USB (A) to (A) cable X 1 MRK-X17 / MRK-19 unit X 1 - Power adapter & Power cord X 1 - 6ft DVI cable X 2 or 3 - M6 screw, cage nut &...
- Page 6 < 1.2 > MRK-K17 / MRK-F17 / MRK-X17 Dimension 1mm = 0.03937 inch Front View Triple display MRK-K17 MRK-F1 Dual display ( LH mounted ) MRK-X17 Dual display ( RH mounted ) Rear View MRK-K17 MRK-F17 / MRK-X17 DVI-D Power Power Central Central...
- Page 7 < 1.2 > MRK-19 Dimension 1mm = 0.03937 inch Front View Triple display MRK-19 Dual display ( LH mounted ) Dual display ( RH mounted ) Rear View DVI-D Power Central Keyboard Left Mouse Right ** Actual connection port locations of the above models may vary. Side View 103.5 559.7...
- Page 8 < 1.3 > Installation - How to install Installation Slides Step ■ The left and right rear mounting brackets are attached to the Multi-display console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. ■...
- Page 9 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Unlock the key cylinder to 3 o’clock direction. Step ■ Hold the handle and slide out the drawer. Step Step ■ Flip up the LCD to a suitable angle. Step ■...
- Page 10 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Operate the multi-display drawer. Step ■ Close the Left Right display. ■ Flip down the LCD completely. Step Step ■ Must completely extend the drawer before returning it to the park position. ■...
- Page 11 < 1.3 > Installation - How to Use the Slides Figure 1. ■ A purple release button is located on the front of the slide. ( shown in Figure 1 ). ■ Pull and hold both side release buttons when Figure 2.
- Page 12 < 1.4 > MRK-K17 connection to DP Server Multi-display Console Drawer Power Central Keyboard Left Mouse Right USB type A Attached 6 ft DP cable USB (A) cable x 2 for each DP port USB type A DP server * DP cable x 2 and USB (B) to (A) cable x 1 for dual display ** Actual connection port locations of the above models may vary Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such...
- Page 13 < 1.4 > MRK-F17 / MRK-X17 / MRK-19 connection to USB Server Mult-display Console Drawer DVI-D Power Central Keyboard Left Mouse Right USB type A DVI cable USB (A) cable x 2 x 2 or 3 USB type A USB server * DVI cable x 2 and USB KB cable x 1 for dual display ** Actual connection port locations of the above models may vary Caution :...
- Page 14 < Part 2 > < 2.1 > Product Specifi cations - MRK-K17 MRK-K17 Panel Native Resolution 3840 x 2160@60Hz Panel Size ( diagonal ) 17.3-inch TFT color LCD Brightness ( cd/m² ) Contrast Ratio ( typ. ) 1000:1 Colors 16.7 M, 8-bit Viewing Angle ( L/R/U/D ) 89/89/89/89 Response Time ( ms )
- Page 15 < 2.1 > Product Specifi cations - MRK-K17 Physical Product ( W x D x H ) 441.6 x 550 x 88 Specifi cation inch 17.4 x 21.7 x 3.5 Packing ( W x D x H ) 580 x 683 x 197 inch 22.8 x 26.9 x 7.8 Triple display...
- Page 16 < 2.1 > Product Specifi cations - MRK-F17 MRK-F17 Panel Native Resolution 1920 x 1080 Panel Size ( diagonal ) 17.3" Standard Brightness ( cd/m² ) High Brightness ( cd/m² ) - Option 1000 Contrast Ratio ( typ. ) 1000:1 Colors 16.7 M, 8-bit Viewing Angle ( L/R/U/D )
- Page 17 < 2.1 > Product Specifi cations - MRK-F17 Physical Product 441.6 x 550 x 88 Specifi cation ( W x D x H ) inch 17.4 x 21.7 x 3.5 Packing 580 x 683 x 197 inch 22.8 x 26.9 x 7.8 ( W x D x H ) Triple display 25.7 kg / 56.5 lb...
- Page 18 < 2.1 > Product Specifi cations - MRK-X17 / MRK-19 MRK-X17 MRK-19 Panel Native Resolution 1920 x 1200 1280 x 1024 Panel Size ( diagonal ) 16.2" 19" Standard Brightness ( cd/m² ) High Brightness ( cd/m² ) - Option 1000 Contrast Ratio ( typ.
- Page 19 < 2.1 > Product Specifi cations - MRK-X17 / MRK-19 Physical Product MRK-X17 441.6 x 550 x 88 Specifi cation ( W x D x H ) inch 17.4 x 21.7 x 3.5 MRK-19 441.6 x 600 x 88 inch 17.4 x 23.6 x 7.8 Packing MRK-X17...
- Page 20 < 2.2 > Standard Keyboard / Mouse Specifi cations G keyboard integrated with touchpad G keyboard integrated with trackball Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS Supporting layouts America United States...
- Page 21 < 2.2 > MAC Keyboard / Mouse Options MAC keyboard integrated with touchpad MAC keyboard integrated with trackball Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts.
- Page 22 < 2.2 > SUN Keyboard / Mouse Options S keyboard integrated with touchpad S keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
- Page 23 < 2.3 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &...
- Page 24 < 2.3 > On-screen Display Operation ( OSD ) Picture Brightness : Adjust the screen brightness Contrast : Adjust the diff erence between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position Picture size : Adjust the image size...
- Page 25 < 2.3 > On-screen Display Operation ( OSD ) Reset Reset : Return the adjustment back to factory setting PIP ( Not Applicable to F17 ) PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) / PBP 3WIN ( Main screen + 2 sub screen ) / PBP 4WIN ( Main screen + 3 sub screen ) Select the signal input of each sub screen...
- Page 26 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input Austin Hughes’ SDI input is an ideal solution for the broadcast-grade video and high resolution CCTV market. Designed with CyberView displays, input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 27 < 3.2 > Options : MRK-K17 : HDMI 2.0 ( HDCP 2.2 ) M RK - F1 7 : HDMI 1.4 ( HDCP 1.4 ) DP 1.0 ( HDCP 1.3 ) M RK - X1 7 : HDMI 1.4 ( HDCP 1.4 ) MRK-19 : HDMI 1.4 ( HDCP 1.4 )
- Page 28 < 3.3 > Options : Touchscreen & driver Capacitive Touch screen Specifi cation MRK-K17 MRK-F17 MRK-X17 Model TPC-10 Multi-touch Technology Projected Capacitive Touch Point Input Type Finger or Capacitive Stylus Resolution 4096 x 4096 Touch Point Accuracy ± 2 mm Response Speed <...
- Page 29 TPC-10 Driver Connect the USB cable from the USB port on the LCD to a computer. The touch screen supports easy Plug-and-Play operations. There is no need to install additional drivers on the computer. TRB Driver Please follow the below steps to setup the touch screen:- Step 1.
- Page 30 < 3.4 > Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load 50 mA 50 mA 50 mA...
- Page 31 Intentionally Left Blank UM-CV-751-MRK-Q424V1 www.austin-hughes.com...
- Page 32 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2024 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-MRK-Q424V1 www.austin-hughes.com...
