Invacare® LiNX
3.3 Power Button (with Status LED)
A
Power button on
attendant control unit
The power button A is on the left-hand side of the remote module,
and contains a status LED that lights up or flashes depending on the
status of the system:
OFF - system down or sleeping
l
Red (flashing) - powered ON - fault, refer to 4.2 Fault
l
Indication, page 21.
Green - powered ON, ready to drive, the remote is the remote-in-
l
charge, refer to 3.6.2 User-in-Charge Indication (Compact Remote
Module), page 17 or 3.6.1 Attendant-in-charge Indication
(Attendant Control Unit), page 17.
You can use the power button for:
Powering the system up and down
l
Requesting to be user-in-charge
l
Performing an EMERGENCY STOP
l
Using lock function
l
Interrupting or waking up from sleep
l
Disabling connectivity (compact remote module only)
l
14
A
Power button on
compact remote
Powering up and down
1. Press the button to switch the system ON.
If there is no fault with the system, the status indicator
lights up green.
2. Press the button to switch the system OFF.
The system powers down and the status indicator
switches OFF.
By default, the remote module, that powers up the power
wheelchair, is in-charge of the power wheelchair.
If the attendant is not the user-in-charge, then the attendant
control unit's power button can not power down the system.
Pressing the power button when not the user-in-charge,
instead, sends a request to the system to become the user-in-
charge.
Requesting to be User-in-charge
To request control of the power wheelchair via secondary remote,
refer to 3.1 Requesting Control of Power Wheelchair, page 13.
Performing an EMERGENCY STOP
1. Press the b utton.
In the event that the power wheelchair is in a runaway situation or you
want to stop a seating motion quickly, you can EMERGENCY STOP the
power wheelchair. To stop the power wheelchair the remote of the
user, that wants to stop the power wheelchair must be remote-in-
charge.
