2.2 Labels on Product
E
A
D B
C
Hardware and Application Firmware Version Label
The hardware and application firmware version label on a Dynamic Controls product contains information about the hardware and application
version that applies for the particular module.
1608055-E
A
READ INSTALLATION
MANUAL BEFORE USE
B IPx4
C
D
E
1. Hardware version
2. Hardware major version
3. Hardware minor version
Recommendation to read the user manual before using the
module.
This is the enclosure's ingress protection rating.
Product label containing:
Dynamic Controls'
l
website address
The bar code
l
WEEE Conformity
Tamper evident seal. Warranty void if seal is broken.
4. Application version
5. Application major version
6. Application minor version
2 Components
The serial number
l
The p art number
l
Dynamic Controls'
l
'dynamic' logo
