GILES GBF-70/70 Operation & Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Electric Fryer
GBF-70
Operation & Service Manual
MODELS:
Single: GBF-70
2-Bank: GBF-70/70
3-Bank: GBF-70/70/70
CAUTION: Read instructions before using this appliance.
GILES Food Service Equipment
ISO 9001-2015 Certified
66320
REV-B
2750 Gunter Park Drive West • Montgomery, AL 36109 USA
ECO3284
Phone 334.272.1457 • Fax 334.239.4117 • Phone Toll Free 800.554.4537
11/13/2024
Website: www.gfse.com • Email: services@gfse.com
PRINTED IN USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the GBF-70/70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GILES GBF-70/70

Summary of Contents for GILES GBF-70/70

  • Page 1 Operation & Service Manual MODELS: Single: GBF-70 2-Bank: GBF-70/70 3-Bank: GBF-70/70/70 CAUTION: Read instructions before using this appliance. GILES Food Service Equipment ISO 9001-2015 Certified 66320 REV-B 2750 Gunter Park Drive West • Montgomery, AL 36109 USA ECO3284 Phone 334.272.1457 • Fax 334.239.4117 • Phone Toll Free 800.554.4537 11/13/2024 Website: www.gfse.com •...
  • Page 3 • During the Limited Warranty period, Giles will replace or recondition, at its factory, any part or parts of this unit which Giles inspectors judge defective, provided the unit has been properly installed, subjected to normal usage, and operated and maintained in accordance with specified procedures.
  • Page 5 Electric Fryer Table of Contents GBF-70 Safety ............. . . iv Safety Overview .
  • Page 6 Table of Contents Electric Fryer GBF-70 4.1.1 Keys Functions..............30 &...
  • Page 7 Table of Contents Electric Fryer GBF-70 Rear Cabinet ­ Double Bank Unit (with J.I.B. Option) ........86 Fry Vat Assembly (per Vat).
  • Page 8 The information contained in this manual has been prepared to explain proper procedures for safely installing, operating and maintaining Giles Food Service appliances and equipment. Hazard Alert Symbols are used throughout the manual, along with key words DANGER, WARNING, and CAUTION to alert users to potential personal injury hazards and/or poor operating practices.
  • Page 9 Safety Electric Fryer GBF-70 Specific Safety Precautions: For your safety, please observe the following precautions when operating or servicing the GBF Electric Fryer. Adhering to the following important safety precautions will help users avoid personal injury and/or damage to the equipment. •...
  • Page 10 Safety Electric Fryer GBF-70 • The appliance must remain in an upright position. • Exercise care when removing the unit from shipping pallet. • DO NOT operate the appliance, unless the intended function of components & controls are fully understood (see Section 3).
  • Page 11 Safety Electric Fryer GBF-70 • Components exposed on control panel surface are impact­sensitive. To avoid damage and ensure proper operation, exercise care when working around or using carts & rolling tables near the appliance. • DO NOT install the unit near combustible walls and materials. Failure to maintain safe distance may result in fire. •...
  • Page 12 THANK YOU for purchasing the Giles Model GBF‐70 Electric Fryer, manufactured by Giles Enterprises, Inc., Montgomery, Alabama (USA), hereafter referred to as "GILES". Every unit is thoroughly inspected and tested prior to shipment in an effort to ensure that it will operate flawlessly when received. With proper care and maintenance the appliance will provide years of trouble­free service.
  • Page 13 Introduction Electric Fryer GBF-70 Specifications 1.4.1 Overall Dimensions BANKED UNITS REQUIRE MINIMUM 44” [1100 mm] CLEARANCE (AISLE OR DOORWAY) FOR PASS‐THROUGH...
  • Page 14 Electric Fryer Introduction GBF-70 1.4.2 Agency Certifications 1.4.3 Basket Size Description Length Width Depth Volume Standard (2 per vat) 18­1/2 [470] 9 [229] 5­1/2 [140] 811 cu in [0.013 c m] 1.4.4 Vat Size & Capacity Cooking Oil Capacity Depth Length Width (Bottom of vat to “FULL”...
  • Page 15 Introduction Electric Fryer GBF-70...
  • Page 16 Installation expenses (material & labor) are the sole responsibility of the customer. Generally, it is advisable to engage the services of professional commercial kitchen equipment specialists, a licensed electrician, and/or a qualified HVAC contractor to manage the specifics of an installation. You may call Giles Technical Support @ 800.554.4537, if assistance is required.
  • Page 17 Damage to appliance, or accessories, caused by poor work practices or improper use of material handling equipment shall not be covered by the factory Warranty. Giles shall not be liable for personal injury or property damage which may be incurred during installation of this equipment.
  • Page 18 All work should be performed by a qualified professional electrical contractor and must comply with all local building code requirements. Giles shall not be responsible for code compliance in regard to installation and use of this appliance. 1. As needed, install appropriate circuit breaker(s) in the main electrical panel. See Section 2.4.
  • Page 19 Installation Electric Fryer GBF-70 2.5.1 Electrical Connection Diagram Disconnect Main Switch Box Breaker (Optional Panel Recommended) Flexible Conduit Connect flex conduit for incoming power supply at this opening. Ground Lug Distribution Block: Supply power connects this side. Each fryer unit in a banked battery system requires a completely separate electrical service, connected in like manner. Ventilation NOTE: Guidelines and code requirements for ventilation in commercial cooking establishments can differ from locale to...
  • Page 20 Electric Fryer Installation GBF-70 Fryer Options - Added to Purchase 2.7.1 Bulk Oil Management System Connections • Fryer equipped with this option is ready for connection to a customer supplied bulk Oil Management System ... either fresh oil, waste oil or both options may be purchased.
  • Page 21 Finalizing Installation Every effort is made to ensure that new GILES equipment is in perfect operating condition when received; each unit has passed rigorous quality control testing prior to shipment. To ensure that it has been properly installed and will operate as expected when placed into service, we recommend that after installation is completed, the following steps be completed to check basic functionality of fryer systems and prepare the appliance for its first use.
  • Page 22 • As applicable, on control panel(s) set switches (POWER, HEAT, PUMP, LIFT) in the [OFF] position • Confirm that drain valve(s) are [CLOSED]. • If any ot these tests fail to produce indicated results, consult Section 6, Troubleshooting, or contact GILES Technical Service at 800.554.4537 for assistance.
  • Page 23 Installation Electric Fryer GBF-70 2.9.2 Heat Test...
  • Page 24 Electric Fryer Installation GBF-70 2.9.3 Filter Pump Test The following test confirms that the filter system pump is operating properly. 1. Open cabinet door (unit with filter pan on banked system). If needed, disconnect and remove the filter pan from the unit. 2.
  • Page 25 DO NOT use cleaners that are abrasive or contain caustic chemicals. 2.9.6 Optional KITCHENTRAC® Remote Equipment Monitoring If your new equipment is factory­equipped with optional Giles’ KITCHENTRAC™ remote monitoring, an account must first be created before the feature can be used. A monthly server hosting fee (per controller monitored) is required to use the service.
  • Page 26 Electric Fryer Overview GBF-70 3. Overview A brief overview of the components, features and accessories associated with the Giles GBF‐70 Electric Fryer. Please review this section completely before using the appliance. Basket & Elevator Assembly Section 3.4 Control Panel Section 3.1 Lower Cabinet Figure 3.2...
  • Page 27 Electric Fryer Overview GBF-70 Control Panel...
  • Page 28 Overview Electric Fryer GBF-70 Control Panel - continued Item Description Function Turns appliance power ON/OFF. Pressing top of switch turns power ON, POWER Switch pressing bottom turns power OFF. Place switch in [HEAT] position to enable heating elements. If actual oil temperature is lower than the controller setpoint, elements will be turned ON HEAT Switch and cooking oil will begin heating.
  • Page 29 Electric Fryer Overview GBF-70 Lower Cabinet Main Unit Banked Add­on Unit...
  • Page 30 Overview Electric Fryer GBF-70 Lower Cabinet - continued Item Description Function Directs oil flow to a particular vat from either the fryer filter pump, a bulk oil OIL RETURN Valve management system pump, or the oil top­off pump. THESE VALVES SHOULD REMAIN CLOSED UNLESS IN USE.
  • Page 31 Electric Fryer Overview GBF-70 Filter Pan Assembly...
  • Page 32 Overview Electric Fryer GBF-70 Filter Pan Assembly - continued Item Description Function Helps contain oil splash and spatter as oil is being drained into the filter pan Filter Pan Cover from the vat(s) ... helps minimize clean­up required for floor and/or cabinet interior.
  • Page 33 Electric Fryer Overview GBF-70 Basket, Elevator Assembly, & Oil Saddle Tank Not Shown...
  • Page 34 Overview Basket, Elevator Assembly, & Oil Saddle Tank - continued Item Description Function Attaches to the auto­basket lift and holds basket in proper position as lift Basket Carrier (2) operates. Easily removed for cleaning. (OPTIONAL) Contains product while cooking. Equipped with front spring handle for easier Basket (2) handling.
  • Page 35 Overview Electric Fryer GBF-70 Accessories Provided Part Description/Part Number Function Kettle Drain Brush Use to clean excessive crumbs and P/N 71025 residue from the vat drain tube. Stirring Utensil Use to stir cooking oil and product in P/N 77775 the pot as it is cooked. Pot Brush Heat­resistant brush for cleaning vat P/N 71100...
  • Page 36 Electric Fryer Overview GBF-70 Accessories Provided - continued Part Description/Part Number Function L­Bend Teflon Brush, Use to clean under and around the P/N 93609 heating elements. Cook Basket Holds product while cooking. P/N 70420 Located in vat above the heating elements to prevent excessive accumulation of crumbs and cooking Fry Screen...
  • Page 37 DOWN THE COOK VAT! Accessories Not Provided Part Description/Part Number Function A portable oil disposal container with capacity of 80­lbs of liquid Giles Oil Caddy shortening. P/N 79187 Intended to handle only warm, filtered oil, containing no crumbs or debris.
  • Page 38 P/N 72004 soluble impurities. Fryer cleaner/degreaser ... add to water for a fryer boil­out cleaning procedure. Giles Fryer Boil­Out Typical fryer requires (2) packets. P/N 72003 Can be used as an overnight fryer Case of (24) pre­measured 6­oz Packets cleaning soak.
  • Page 39 Overview Electric Fryer GBF-70 Accessories Not Provided - continued Part Description/Part Number Function Pot Cover Lid to cover oil in vat. P/N 98995 Tool Caddy/Splash Shield Tool storage & protection from P/N 72068 splashing oil. Splash Shield Protection from splashing oil. P/N 72095 Notes:...
  • Page 40 Electric Fryer Fryer Operation GBF-70 4. Fryer Operation The GBF‐70 fryer is manufactured as either a single unit or a banked system of (2) or (3) fryer wells and features a computer cooking controller. Optionally, units can be configured with convenient Oil Level Top‐Off capability, which utilizes an on­board fresh oil supply (jug‐In‐box or saddle tank) or a customer­provided bulk oil management system.
  • Page 41 Fryer Operation Electric Fryer GBF-70 Computer Controller This section explains the functions, features, and programming and operating procedures for the dual­timer cooking controller. It has been designed to be user­friendly and when working with it many instructions and prompts will be shown on the Upper Display (blue) to help guide you through each process.
  • Page 42 Electric Fryer Fryer Operation GBF-70 4.1.1 Keys & Functions - continued MENU Key: Action key which is pressed in combination with other keys to access programmed menu item presets. Fifty (50) different programmable presets are available. EDIT Key: Action key which is pressed in combination with other keys to enter edit mode for changing or creating menu item preset settings.
  • Page 43 Fryer Operation Electric Fryer GBF-70 4.1.2 Controller - General Overview The following is general operational information only. Detailed procedures and instructions are discussed in later sections. During operation, instructions and prompts will be shown on the upper display screen to help guide you through certain processes.
  • Page 44 Electric Fryer Fryer Operation GBF-70 4.1.3 Setting the Cooking Temperature Cooking temperature setpoint must be input manually, as menu item presets do not include temperature settings. Instruction prompts will be shown on the upper display to help guide you through the process. Use keypad to enter cooking temperature setpoint (°F).
  • Page 45 Fryer Operation Electric Fryer GBF-70 4.1.4 Manually Setting the Cook Time IMPORTANT! If PASSCODE is enabled, cooking time cannot be manually input without entering the required password. Without a password you will be restricted to only choosing from the available Menu Item Presets, see Section 4.1.5, Working with Menu Presets.
  • Page 46 Electric Fryer Fryer Operation GBF-70 4.1.5 Working with Menu Item Presets NOTE: Menu Item Presets stored in the controller do not include cooking temperature settings. Temperature must always be input manually, see Section 4.1.3, Setting the Cooking Temperature. Fifty (50) Menu Item Preset cook settings are stored in the controller. Each includes: ●...
  • Page 47 Fryer Operation Electric Fryer GBF-70 4.1.5.1 Editing a Menu Item Preset Method 1 Enter NAME letter by letter Choose NAME setting as described at the left. A flashing cursor will appear at Use arrow keys [2] UP • [8] the first letter of the current DOWN to scroll through list to name.
  • Page 48 Electric Fryer Fryer Operation GBF-70 4.1.5.1 Editing a Menu Item Preset - continued Edit COOKING TIME: After entering EDIT, select TIME to edit as shown on previous page. Current time setting is displayed. Using numeric keypad enter new TIME (mm:ss) NOTE: All digits must be entered, e.g.
  • Page 49 Fryer Operation Electric Fryer GBF-70 4.1.5.1 Editing a Menu Item Preset - continued Edit FISH FILTER Setting: To minimize potential for flavor transfer, establishments that cook seafood may wish to force operators to filter oil after only cooking one (1) batch of a product. When FISH FILTER is set to [ON], the unit will enter FILTER MODE after completing one load of a specific item.
  • Page 50 Electric Fryer Fryer Operation GBF-70 4.1.5.2 Selecting a Menu Item Preset for Cooking Direct Entry: If you know the menu no. of the item that you want to cook, either of the methods below can be used to select it. Method (B) Method (A) Enter desired Menu No.
  • Page 51 Electric Fryer Fryer Operation GBF-70 4.1.5.2 Selecting a Menu Item Preset for Cooking - continued Scroll Method: If a menu no. is not known, you can scroll through the list of Menu Presets to select the desired item ... the current settings will appear on the upper display screen. Use numeric keypad [2] •...
  • Page 52 Electric Fryer Fryer Operation GBF-70 4.1.6 Cooking Cycle General Overview TEMP SETPOINT, MENU NAME & COOKING TIME currently assigned to each basket are shown on the upper display screen. When in READY state, temperature setpoint is shown on the lower display screen. The READY message in the upper left corner of upper screen indicates that cooking oil is at temperature and the fryer is ready for cooking.
  • Page 53 Fryer Operation Electric Fryer GBF-70 4.1.6 Cooking Cycle General Overview - continued 4.1.7 Manually Operating Optional Basket Lifts (if Equipped) Press the [BASKET] key once Use keypad [2] UP [8] DOWN keys to select raise or & lower basket lift. Press [CLEAR] to Cancel the operation.
  • Page 54 Electric Fryer Fryer Operation GBF-70 4.1.8 Cool Mode COOL MODE is an energy­saving feature that lowers the oil temperature setpoint value, placing fryer into an idle standby state during periods of inactivity. Enter COOL MODE by pressing the [COOL] key. The temperature setpoint changes to the COOL TEMP setting specified in user settings (Section 4.1.10).
  • Page 55 Fryer Operation Electric Fryer GBF-70 4.1.10 User Settings To access the User Press Press Enter on Settings menu and edit [START] key [TIME] key keypad The table below details available User settings ... Settings and factory set Defaults. Keypad [4] & [6] (left/right) will scroll through the available settings ... current setting values are shown on the upper controller display.
  • Page 56 Electric Fryer Fryer Operation GBF-70 4.1.10 User Settings - continued NAME DESCRIPTION RANGE DEFAULT English­Spanish­ LANGUAGE Sets the controller language English French If [ON], selecting a MENU # will automatically begin the cooking COOK ON MENU cycle. Reduces the number of keystrokes needed to start a cook ON ­...
  • Page 57 GUARD BAND EXCEEDED value. Allow oil to cool, or heat, to within range. Factory default is 900°F ... This error should not occur. An error occurred while saving settings to the EEPROM. Call Giles ER37 EEPROM Error Tech Service (800.554.4537).
  • Page 58 PREHEAT mode ... Fryer will not heat until key is pressed. NOTE: If an error condition persists and cannot be resolved, it could be an indication of component failure or system malfunction. Please contact a factory‐authorized service agent, or call 800.554.4537 for Giles Technical Support.
  • Page 59 Fryer Operation Electric Fryer GBF-70 Cooking Procedures This section explains procedures for cooking with the GBF‐70 electric fryer and assumes you are beginning with a properly installed, clean, empty fryer. Owner/operator work practices and procedures must also be followed and may supercede the processes presented in this manual.
  • Page 60 Electric Fryer Fryer Operation GBF-70 Cooking Procedures - continued 6. If unit is equipped with optional basket lifts and you wish to use them, place the LIFT switch ⑩ in the [LIFT] position. There is no lift switch on the control panel If basket lifts are not installed. 7.
  • Page 61 Fryer Operation Electric Fryer GBF-70 Cooking Procedures - continued 11. Place the basket support/crumb screen ⑬ into the vat with handles to the side. 12. If optional Basket Lifts are installed, raise both to the UP position as described in Section 4.1.7, Manually Operating the Basket Lifts.
  • Page 62 Electric Fryer Fryer Operation GBF-70 Cooking Procedures - continued A. Fryer WITH Optional Basket Lifts: 14. With basket hanging on a raised basket carrier arm, load fresh uncooked product into 15. Select the appropriate Menu Item Preset (see Section 4.1.5.2), or manually enter a desired cooking time (see Section 4.1.4).
  • Page 63 Fryer Operation Electric Fryer GBF-70 Cooking Procedures - continued STIR ALARM NOTE: Step #18 applies only if user setting “STIR ALARM ENABLE” = [ON] and menu item setting “STIR OVERRIDE” = [NORMAL] for the menu item being cooked. •• OR •• “STIR ALARM ENABLE”...
  • Page 64 Electric Fryer Fryer Operation GBF-70 Optional Oil Level Top-Off Function The optional Oil Level Top‐Off feature makes maintaining oil level in vats virtually hands‐free. Fresh oil is supplied from either an on‐board supply or a “customer‐provided” bulk oil management system. On­board system ...
  • Page 65 Fryer Operation Electric Fryer GBF-70 Filtering Used Cooking Oil Using On-Board System This section explains filtering and reconditioning of used cooking oil using the on‐board oil filtration system. The process involves draining used oil into filter pan, which contains the filter media. A filter aid/conditioner compound is added, then the system pumps the used oil through the filter media and recirculates it back to the vat.
  • Page 66 5. Evenly distribute approximately 5 ozs. of a suitable filter aid over the filter media surface. Use of a good quality filter aid compound is essential for removing soluble impurities and reconditioning the oil. Portion packed Filter Powder is available through Giles’ distributors and equipment dealers ... P/N 72004.
  • Page 67 Fryer Operation Electric Fryer GBF-70 Filtering Used Cooking Oil Using On-Board System - continued B. Filtering Process 9. Complete the filtering procedure as follows. • In the lower cabinet of the unit being filtered, place the OIL RETURN valve handle ⑥ to the [FILL POT] position •...
  • Page 68 Electric Fryer Fryer Operation GBF-70 Filtering Used Cooking Oil Using On-Board System - continued 11. Reassemble and install filter pan under fryer and reconnect hose to the fryer coupling. 12. To continue cooking, see Section 4.2, Cooking Procedure. To discontinue cooking, see Section 4.5, Normal Shut‐Down. Normal Fryer Shutdown Fryer shutdown applies to each unit of a banked system.
  • Page 69 Fryer Operation Electric Fryer GBF-70 Notes:...
  • Page 70 Electric Fryer Cleaning & Maintenance GBF-70 5. Cleaning & Maintenance This section explains cleaning and maintaining procedures for the GBF‐70 fryer that are necessary to keep it in good operating condition. DO NOT wash down fryer interior or exterior with water from a spray hose. Control panels are “liquid‐resistant”, but are NOT washdown safe.
  • Page 71 Cleaning & Maintenance Electric Fryer GBF-70 Removing & Disposing of Waste Cooking Oil - continued 4. Drain oil from vat; ensure that HEAT switch remains [OFF]: • On the unit being drained ... slowly move the drain valve handle ⑦ to the [OPEN] position (fully right to stop).
  • Page 72 5. Use a reputable fryer cleaning & degreasing product and follow the manufacturer’s directions for use. Add recommended amount of product to the water and stir gently to mix. Fryer Boil Out cleaner is available through GILES’ distributors and equipment dealers ... item #72003­1, 8­lb Jar or #72003, case of 4 Jars.
  • Page 73 Cleaning & Maintenance Electric Fryer GBF-70 Boil-Out Procedure - Cleaning the Fry Vat - continued NEVER drain spent boil­out solution into the filter pan or run it through the filter system using the pump. Some fryer cleaning products may be caustic and will damage the pump and/or other system components. Doing this will void the factory warranty! IMPORTANT!! •...
  • Page 74 NOTE: We recommend use of Simple Green® Crystal Foaming Spray Cleaner/Degreaser for general cleaning of fryers and parts. It is readily available from GILES distributors and dealers, as well as many national retail outlets. It is non­toxic, safe for use on all metal surfaces, and is NSF approved.
  • Page 75 Optional Filter Screen Note: When choosing to use the sustainable Stainless Steel Filter Screen, purchased separately from Giles, please follow the usage and cleaning instructions provided with the item. This item is an alternative substitute for filter paper and is NOT to be used in addition to filter paper.
  • Page 76 The most common issues are discussed here. However, if you encounter problems that are not addressed, Giles Technical Service representatives may help identify and resolve the problem... please call 800.554.4537 or email services@gfse.com.
  • Page 77 Electric Fryer Troubleshooting GBF-70 Temperature Control System − continued Problem Probable Cause Corrective Action Fryer heating slowly (slow temp A. Improper cooking procedures. Refer to Operation Manual. recovery). B. Heating element is failing. Call for service. Amber HEAT light remaining ON, does not cycle.
  • Page 78 Troubleshooting Electric Fryer GBF-70 On−Board Oil Filtration Problems Problem Probable Cause Corrective Action Cook vat does not drain. A. Excessive crumbs or residue clogging Use provided round­bristle brush to clear drain. drain. Must manually remove thickened oil from Oil does not circulate or return to refill A.
  • Page 79 Electric Fryer Troubleshooting GBF-70 Oil Top−Off System Problems Problem Probable Cause Corrective Action Top‐Off does not pump oil to vat. A. Fresh oil supply is empty ... Saddle Tank Refill tank with fresh oil or replace J.I.B or Jug‐In‐Box on banked unit. supply jug.
  • Page 80 Troubleshooting Electric Fryer GBF-70 Basket Lift System (if Equipped) Problem Probable Cause Corrective Action Basket Lift will not operate. A. LIFT switch on control panel is in the Place switch in [LIFT] position to enable [OFF] position. lifts. Lifts cannot be operated manually until B.
  • Page 81 Electric Fryer Troubleshooting GBF-70 Notes:...
  • Page 82 Website: www.gfse.com or e­mail services@gfse.com. The goal at Giles is to provide the best service and customer support in the industry. To help us accomplish this, please become familiar with the equipment specification data and refer to it when calling. The information can be found on a data/serial label similar to the one below, which will be attached to a rear cabinet panel or at a location inside the cabinet (each unit of a banked system).
  • Page 83 Electric Fryer Parts List GBF-70 Control Panel - Single Unit & Banked System Main Unit • OR • See Notes about panel configurations • OR • See Notes about panel configurations Not Shown...
  • Page 84 Parts List Electric Fryer GBF-70 Control Panel - Single Unit & Banked System Main Unit - continued ITEM PART DESCRIPTION 21379 CONTROLLER, CC10, DUAL TIMER 21190 SWITCH, ROCKER, ON­OFF, 250V, 20A, DPST 21052 3 / 2 SWITCH, ROCKER ,ON­OFF­ON, 250V, 20A, DPDT 20398 INDICATOR LIGHT, GREEN, 250VAC 20399...
  • Page 85 Electric Fryer Parts List GBF-70 Front Header Component Box (behind Control Panel of Each Unit)
  • Page 86 Parts List Electric Fryer GBF-70 Front Header Component Box (behind Cntrl Panel of Each Unit)- cont. ITEM PART NO. DESCRIPTION 21592 LIMIT CONTROL, SAFETY, 450­DEG F, DUAL 21203 RELAY, SPDT­NO­NC, 240VAC 37585 DIN RAIL, TERMINAL BLOCK MOUNT, 3.0” 20366 TRANSFORMER, 20VA, 115/230V, 50/60HZ 22976 AUDIOLARM, CONTINUOUS, 2­12 VDC 21509...
  • Page 87 Electric Fryer Parts List GBF-70 Lower Cabinet - Single Unit or Banked System Main Unit *See Note Back Side *NOTE: WASTE valve not present unless unit is equipped with the bulk Waste Oil Handling option.
  • Page 88 Parts List Electric Fryer GBF-70 Lower Cabinet - Single Unit or Banked System Main Unit - continued ITEM PART NO. DESCRIPTION 40784 BALL VALVE, 1/2, S/S w/NON­STICK SEALS 20527 CONDUIT CONNECTOR, 1­1/4 FLEX, STRAIGHT, NON­METAL 97188 DRAIN VALVE HANDLE 21386 DRAIN LIMIT SWITCH, SPDT, PREWIRED 21164 TERMINAL BLOCK, POWER DISTRIBUTION...
  • Page 89 Electric Fryer Parts List GBF-70 Lower Cabinet - Banked System Add-on Unit with J.I.B. Option Brace Back...
  • Page 90 Parts List Electric Fryer GBF-70 Lower Cabinet - Banked System Add-on Unit with J.I.B. Option - cont. ITEM PART NO. DESCRIPTION 40784 BALL VALVE, 1/2, S/S w/NON­STICK SEALS 97188 DRAIN VALVE HANDLE 96173 COVER, ELECTRICAL SERVICE BOX (ORDER NEW LABELS, IF REPLACED) 20527 CONDUIT CONNECTOR, 1­1/4 FLEX, STRAIGHT, NON­METAL 40889...
  • Page 91 Electric Fryer Parts List GBF-70 Plumbing Components - Single Fryer All hose connections require Adapter, Item #3 Bulk oil system 10 w connections F = Fresh • W = Waste 10 w NOTE: • Some components may not be intalled depending on options included on the appliance. •...
  • Page 92 Parts List Electric Fryer GBF-70 Plumbing Components - Single Fryer - continued ITEM PART NO. DESCRIPTION 21440 TRANSDUCER, PRESSURE, 0­50 PSI 21434 PRESSURE SWITCH, 35 PSI, 10A 40889 VAR. ADAPTOR, 1/2­COMPRESS TO 1/2­NPT 41081 HOSE, CORRUGATED, SS, 1/2 NPT X 30” 40909 HOSE, CORRUGATED, SS, 1/2 NPT X 15 BULK OIL SYSTEM CONNECTIONS ONLY: F = Fresh Oil •...
  • Page 93 Electric Fryer Parts List GBF-70 7.6.1 Plumbing Components - Double Bank Fryer All hose connections FRESH BULK OIL CONNECTION require an Adapter, Item #3 J.I.B. OPTION ­ JUG SIDE J.I.B. OPTION...
  • Page 94 Parts List Electric Fryer GBF-70 7.6.1 Plumbing Components - Double Bank Fryer - continued ITEM PART NO. DESCRIPTION 21440 TRANSDUCER, PRESSURE, 0­50 PSI ... CABLE = P/N 21357 (AUTOMATED UNITS ONLY) 21434 PRESSURE SWITCH, 35 PSI, 10A 40889 VAR. ADAPTOR, 1/2­COMPRESS TO 1/2­NPT 41081 HOSE, CORRUGATED, SS, 1/2 NPT X 30”...
  • Page 95 Electric Fryer Parts List GBF-70 Rear Cabinet - Single Unit Not Shown Optional ­ installed with Basket Lift Option only...
  • Page 96 Parts List Electric Fryer GBF-70 Rear Cabinet - Single Unit - continued ITEM PART NO. DESCRIPTION 35166 BASKET LIFT ASSEMBLY, COMPLETE (OPTIONAL) 21504 DISTRIBUTION BLOCK, 6­PL, 12­26 AWG, RED 21505 DISTRIBUTION BLOCK, 6­PL, 12­26 AWG, BLACK 21245 CONTACTOR, 60A, 3­PL, 100­250V COIL 37585 RAIL, TERMINAL BLOCK MOUNT, 3”...
  • Page 97 Electric Fryer Parts List GBF-70 Rear Cabinet - Double Bank Unit (with J.I.B. Option) NOTE: Refer to Section 7.6.1 for more plumbing & drain component detail. Optional...
  • Page 98 Parts List Electric Fryer GBF-70 Rear Cabinet - Double Bank Unit (with J.I.B. Option) - continued ITEM PART NO. DESCRIPTION 35166 2 or 4 BASKET LIFT ASSEMBLY, COMPLETE (OPTIONAL) 21504 DISTRIBUTION BLOCK, 6­PL, 12­26 AWG, RED 21505 DISTRIBUTION BLOCK, 6­PL, 12­26 AWG, BLACK 21245 CONTACTOR, 60A, 3­PL, 100­250V COIL 37585...
  • Page 99 Electric Fryer Parts List GBF-70 Fry Vat Assembly (per Vat) Top View Side View...
  • Page 100 Parts List Electric Fryer GBF-70 Fry Vat Assembly (per Vat) - continued ITEM PART NO. DESCRIPTION 21447 ELEMENT, 208 V, 9975 W, FIREBAR 21448 ELEMENT, 240 V, 9975 W, FIREBAR 21449 ELEMENT, 480 V, 9975 W, FIREBAR 21596 THERMOCOUPLE­ J, DUAL, 7­1/2”, UNGROUNDED (HI‐LIMIT PROBE) 20439 THERMOCOUPLE, J­TYPE, 3”, UNGROUNDED...
  • Page 101 Electric Fryer Parts List GBF-70 7.10 Filter Pan Assembly...
  • Page 102 Parts List Electric Fryer GBF-70 7.10 Filter Pan Assembly - continued ITEM PART NO. DESCRIPTION 97930 FILTER PAN COVER ASSEMBLY 97334 CRUMB CATCHER SCREEN 30040­5 HOLD DOWN FRAME WELD ASSEMBLY (WITHOUT LEVERS) 60819 PAPER, FILTER, 16­1/4 X 24­1/4 (TWO [2] SHEETS REQUIRED) 98263 FILTER PAN MEDIA SUPPORT SCREEN 97326...
  • Page 103 Electric Fryer Parts List GBF-70 7.11 Baskets, Panels, & Covers Optional...
  • Page 104 Parts List Electric Fryer GBF-70 7.11 Baskets, Panels, & Covers - continued ITEM PART NO. DESCRIPTION 97212 BASKET CARRIER ASSEMBLY (OPTIONAL) 98997 VAT CRUMB SCREEN 97226 PANEL, CABINET BACK 92795 PANEL, BREAKER ACCESS 97169 PANEL, SIDE, LEFT 97530 CABINET DOOR 70420 COOK BASKET W/ REAR HANDLE 21696...
  • Page 105 Electric Fryer Parts List GBF-70 Notes:...
  • Page 106 Enterprise levels require monthly service fees, but offer enhanced capabilities to remotely edit fryer settings & receive notification of problems via email or text. The Enterprise level even includes extensive monitoring by Giles Technical associates with automatic repair dispatch for warranty equipment.
  • Page 107 Electric Fryer Appendix GBF-70 Connecting WiFi Board to Wireless Router - continued Establishing Communication with KITCHENTRAC® Server...
  • Page 108 Appendix Electric Fryer GBF-70 WiFi Components WIFI boards are located in various locations inside the appliance cabinets, depending on model. An antenna will protude from cabinet near its location. IMPORTANT! Take care not to damage the antenna when cleaning or servicing the equipment.
  • Page 109 GILES Food Service Equipment ISO 9001-2015 Certified 66320 REV-B 2750 Gunter Park Drive West • Montgomery, AL 36109 USA ECO3284 Phone 334.272.1457 • Fax 334.239.4117 • Phone Toll Free 800.554.4537 11/13/2024 Website: www.gfse.com • Email: services@gfse.com PRINTED IN USA...
