To set the temperature for the GILES GEF-560 fryer:

1. Press and hold the Program Key for approximately 5 seconds until the red LED above the key is illuminated.
2. The Main Display will read "PROG," and the Scrolling Display will read "Choose Menu."
3. Select the desired Menu Key to program or edit.
4. Use the Up & Down Arrow Keys to cycle through the available menu item labels.
5. Adjust the temperature setpoint as needed.

For specific functions:
- Idle Mode: Temperature setpoint changes to 275°F automatically.
- Boil Out Mode: Press the Boil button for 5 seconds, and the temperature setpoint changes to 200°F for a 30-minute cycle.

Ensure you follow the manual instructions for proper operation.

This answer is automatically generated

Summary of Contents for GILES GEF Series

Page 1 GEF Series Operations & Service Manual GEF-VH Series Models: GEF-400 GEF-560 GEF-720 Models: GEF-400-VH GEF-560-VH GEF-720-VH ISO 9001 Registered • Committed to Quality 2750 Gunter Park Drive West • Montgomery, AL 36109 USA Toll Free: 800.554.4537 Other: 334.272.1457 (USA & Canada Only) Fax: 334.239.4117 •...
Page 3 • During the Limited Warranty period, Giles will replace or recondition, at its factory, any part or parts of this unit which Giles inspectors judge defective, provided the unit has been properly installed, subjected to normal usage, and operated and maintained in accordance with specified procedures.
Page 4: Table Of Contents
Table Of Contents GEF & GEF-VH Series Fryers Safety Safety Overview ................vii Specific Safety Precautions .
Page 5 GEF Series Table Of Contents GEF-VH Series Fryer Operation ..........35 Computer Cooking Controller .
Page 6 Table Of Contents GEF & GEF-VH Series Fryers 7.2.2 Quarterly Hood Cleaning ............. . 78 7.2.3 Semi-Annual Fire Suppression System Inspection &...
Page 8: Safety
The instructions contained in this manual have been prepared to aid in learning the proper procedures for installing, operating and servicing the Giles Model GEF or GEF-VH Series Electric Fryer. Throughout the manual, safety precautions are identified by a hazard alert symbol and key words such as DANGER, WARNING or CAUTION.
Page 9: Specific Safety Precautions
GEF Series Safety GEF-VH Series Specific Safety Precautions: For your safety, please observe the following precautions when operating or servicing the GEF or GEF-VH Electric Fryer. Adhering to the following important safety precautions will help Users to avoid personal injury and/or damage to the equipment.
Page 10 GEF Series Safety GEF-VH Series • The appliance must remain in an upright position. • Exercise care when removing the unit from shipping pallet. • DO NOT operate the appliance, unless its components and their intended functions are fully understood (see Section 3).
Page 11 GEF Series Safety GEF-VH Series • Components exposed on the Control Panel surface are impact-sensitive. To avoid damage and maintain proper operation, exercise care when working around or using carts/rolling tables near the appliance. • DO NOT install the unit near combustible walls and materials. Failure to maintain safe distance may result in fire.
Page 12: Introduction
GEF & GEF-VH Series Fryers Introduction THANK YOU for purchasing the Giles Model GEF or GEF-VH Series Electric Fryer, manufactured by GILES Food Service Equipment; Montgomery, Alabama (USA), hereafter referred to as "Giles". Every unit is thoroughly inspected and tested prior to shipment in efforts to ensure that it will operate flawlessly when received. With proper care and maintenance the appliance will provide years of trouble-free service.
Page 13: Specifications
Introduction GEF & GEF-VH Series Fryers Specifications 1.3.1 Overall Dimensions: GEF Models 61 1/2 MAX WITH DOOR OPEN 1561.91 38 15/16 988.24 24 1/16 611.58 Inches {mm}...
Page 14: Overall Dimensions For Gef-400-Vh, Gef-560-Vh, Gef-720/Vh
Introduction GEF & GEF-VH Series Fryers 1.3.2 Overall Dimensions: GEF-VH Models 0 CLEARANCE TO CEILING 24 3/8 DOOR SWING Inches {mm} NOTE: The appliance is equipped with an exhaust air diverter. Requires [0”] clearance to ceiling, or overhead obstructions. It is recommend that some adequate space be provided to allow for easy movement of the appliance, if need.
Page 15: Regulatory Listings
Introduction GEF & GEF-VH Series Fryers 1.3.3 Agency Certifications 1.3.4 Basket Sizes Basket Size Volume Model Diameter: in[mm] Depth: in[mm] Cubic inch [Cu m] GEF-400 & 400-VH 12-3/8 [314.2] 10-1/4 [260.4] 1,231.8 [.020] GEF-560 & 560-VH 14-3/4 [374.7] 10-1/4 [260.4] 1,751.5 [.029] GEF-720 &...
Page 16: Installation
GEF & GEF-VH Series Fryers Installation This section provides a summary of procedures necessary for proper installation of the Giles Model GEF or GEF-VH Series Fryer. To avoid potential for personal injury and/or equipment damage, please be sure the steps and procedures are followed.
Page 17: Unpacking
IMPORTANT! Be aware that the GEF-VH model is somewhat top-heavy. IMPORTANT! Giles shall not be liable for damages to the unit caused by improper use of material handling equipment or poor work practices. Giles shall not be liable for personal injuries or property damage which may be incurred during installation of this equipment.
Page 18: Electrical Requirements
Installation GEF & GEF-VH Series Fryers Electrical Requirements • Fryers must be properly grounded accordance with local code, or in the absence of local code, with the National Electrical Code, ANSI/NFPA 70. Improper grounding may result in electrical shock to Users. Check local electrical code to ensure that proper grounding techniques are used.
Page 19 Installation GEF & GEF-VH Series Fryers Table 2.3 Electrical Requirements - continued Amps Breaker Model Voltage Required 15.0 15.0 15.0 GEF-560 15.0 14.8 15.0 15.4 15.4 15.4 GEF-560-VH 15.4 14.8 15.4 20.0 20.0 GEF-720 20.0 19.2 20.0 20.4 20.4 GEF-720-VH 20.4 19.6 20.4...
Page 20: Electrical Connections
Electrical installation materials (breakers, conduit, fittings, wire, etc.) and installation labor shall be supplied by the customer. Work should be performed by a qualified electrician, or service technician. Installation must comply with local code requirements. Giles is not responsible for code compliance with regard to installation and use of this appliance.
Page 21: 2.4.2 Service Box Connections
Installation GEF & GEF-VH Series Fryers 2.4.2 Service Box Connections Service Entrance Box Terminal Blocks Power Wires from Main DETAIL A Breaker Panel Ventilation of Non-Ventless Fryer NOTE: Guidelines and codes for ventilation system requirements differ from locale to locale. Always consult the local Authorities Having Jurisdiction (AHJ) to ensure compliance.
Page 22: Ventless Hood Fire Suppress System
Installation GEF & GEF-VH Series Fryers Ventless Hood Fire Suppression System The fire suppression system in Ventless Hood Fryers is an Ansul® R-102 Restaurant Fire Suppression System (UL197 Listed). The system is designed and UL-listed to provide fire protection for cooking appliances such as fryers. It is a mechanically activated system which automatically provides constant protection against accidental fire.
Page 23: Fire Extinguisher Nozzle And Tank Locations
All extinguisher system discharge nozzles have been factory installed and aligned in the proper position. DO NOT MOVE OR ADJUST, except on advice of a fire protection specialist. Plenum Nozzle Giles P/N 46426 Appliance Nozzle Giles P/N 46426 Appliance Nozzle...
Page 24: Fire Alarm Connection
Installation GEF & GEF-VH Series Fryers 2.10 Fire Alarm Connection Connects fire suppression system to the building fire alarm system for sending signal in the event that the fire extinguishing system is activated. Fire Alarm Connection: Remove Cover on Fire Alarm Tie-In Box and install appropriately sized conduit and wire to the facility’s fire alarm system.
Page 25: Changing The Door Swing
Installation GEF & GEF-VH Series Fryers 2.11 Changing the Door Swing Certain situations may require that the door swing direction be reversed to allow easier access to the lower cabinet. This procedure is described below. 1. Disconnect power. ① 2. Remove (4) screws on the left side of the lower cabinet.
Page 26: Overview
GEF & GEF-VH Series Fryers Overview The following section is a brief overview of the components, functions, and accessories of Giles GEF and GEF-VH Series Electric Fryers. Please review this section carefully before attempting to operate the appliance. Ventless Hood Section 3.5...
Page 27: Control Panel
Overview GEF & GEF-VH Series Fryers Control Panel Ventless Hood (VH) Models Only...
Page 28 Overview GEF & GEF-VH Series Fryers Control Panel Item Description Function Turns Fryer power ON/OFF. Press top portion to place in [ON] position Power Switch for operation. 3-Position switch selects operation mode ... [COOK-OFF-FILTER PUMP]. Heating elements will only operate when switch is in [COOK] position. Selector Switch Switch is placed in the [FILTER PUMP] position to run the Filter Pump.
Page 29: Lower Cabinet Area
Overview GEF & GEF-VH Series Fryers Lower Cabinet Area Due to continuing improvements and product enhancements, illustrations might differ slightly from actual unit.
Page 30 Overview GEF & GEF-VH Series Fryers Lower Cabinet Area Item Description Function Directs Filter Pump discharge to either the Cook Pot or to the Waste Oil Diverter Valve Handle Discharge Hose. Quick Disconnect for Fitting for connecting the Waste Oil Discharge Hose for removing waste Oil Discharge Hose oil from the Fryer.
Page 31: Filter Pan Assembly
Overview GEF & GEF-VH Series Fryers Filter Pan Assembly Not included, Optional Item Due to continuing improvements and product enhancements, illustrations might differ slightly from actual unit.
Page 32 One (1) piece of paper media must Filter Paper be used for proper filtering. A filter aid such as Giles Filter Powder should also be used to recondition the oil. Hold Down Levers (4) Locks the Hold Down Frame in position.
Page 33: Basket And Elevator Assembly
Overview GEF & GEF-VH Series Fryers Basket & Elevator Assembly Due to continuing improvements and product enhancements, illustrations might differ slightly from actual unit.
Page 34 Overview GEF & GEF-VH Series Fryers Basket & Elevator Assembly Item Description Function Covers the Fry Pot while product is cooking. When used as intended, Pot/Basket Cover prevents hot cooking oil from splashing or splattering from pot. Attaches the Fry Basket to Basket Lift shaft; holds it in the proper Basket Carrier position for lowering, cooking and raising.
Page 35: Ventless Hood (Vh Model Only)
Overview GEF & GEF-VH Series Fryers Ventless Hood (VH Model Only)
Page 36 NEVER attempt to clean the Charcoal Filter; it is NOT renewable. It is advisable to keep a spare filter Charcoal Filter on hand (Giles #30248) for quick exchange when needed! NOTE: Filter may not completely eliminate cooking aromas. Electrostatic Air Cleaner removes grease vapors and smoke generated while cooking.
Page 37: Accessories (Included)
Overview GEF & GEF-VH Series Fryers Accessories (Included) Description/ Part Function Part Number Kettle Drain Brush Use for cleaning the Fry Pot and Pot P/N 71025 Drain in the event of clogging. Use for stirring hot oil and to agitate Stirring Utensil product while cooking to prevent P/N 77775...
Page 38 Overview GEF & GEF-VH Series Fryers Accessories (Included) Description/ Part Function Part Number Use for cleaning between L-Shaped Brush Heating Elements and the space P/N 73233 between the pot wall and the elements. Use for removing waste cooking oil Waste Oil from Fryer.
Page 39: Accessories (Not Included, Purchased Separately)
Overview GEF & GEF-VH Series Fryers Accessories (Not Included, Purchased Separately) Description/ Part Function Part Number Filter Paper Paper filter media for the Filter Pan. P/N 60810 Filter Powder Filtering aid to help clean the cooking P/N 72004 oil during the filtering cycle. Removes soluble impurities from oil.
Page 40 Provides same filtering performance as paper media. Portable, waste oil disposal container with capacity for 80 lbs of waste cooking oil. Giles Oil Caddy Does not need electricity; manually P/N 79187 operated pump. Note: For use with filtered, warm oil...
Page 41 Overview GEF & GEF-VH Series Fryers Notes:...
Page 42: Pre-Operation Checkout
Pre-Operation Checkout Giles takes pride in quality of workmanship. Every effort has been made to ensure that a new unit is in perfect operating condition when received; each unit must pass rigorous quality control testing prior to shipment. To further ensure that the appliance operates to expectations, it is recommended that a brief operational checkout be performed prior to using it for the first time.
Page 43: Power Test
Pre-Operation Checkout GEF & GEF-VH Series Fryers Power Test The following test confirms that the unit is properly receiving power. 1. Set up unit as described in Section 4.1. 2. Be sure the main circuit breaker powering the unit is ON. ①...
Page 44: Filter Pump Test
Pre-Operation Checkout GEF & GEF-VH Series Fryers Filter Pump Test The following test confirms that the Filter Pump is operating properly. 1. Follow steps in Section 4-1. ① 2. Place the Power Switch in the [ON] position. Wait until Controller powers-up, then press [ALARM] key to silence alarm.
Page 45: Clean Filter Pan & Accessories
Pre-Operation Checkout GEF & GEF-VH Series Fryers Clean Filter Pan & Accessories Thoroughly clean the Filter Pan to remove dirt/debris that may have accumulated during shipment, or residue remaining from manufacturing processes. See Section 6.2, Cleaning the Filter Pan and Replacing Filter Paper after Boil Out. Wash accessory items (Cook Baskets, Basket Carriers, Support/Fry Screens, Stirring Utensil, Crumb Shovel, etc) in warm soapy water, rinse and dry thoroughly.
Page 46: Fryer Operation
GEF & GEF-VH Series Fryers Fryer Operation The following section describes operational procedures for Giles Model GEF & GEF-VH Electric Fryers. • Turn off the Fryer power switch and the supply power at main electrical panel, or remove plug for receptacle before cleaning or performing maintenance.
Page 47: Computer Cooking Controller
Fryer Operation GEF & GEF-VH Series Fryers Computer Cooking Controller The following sections explain the functions, features, programming, and operational procedures for the Computer Cooking Controller. 5.1.1 Keys and Functions Numeric Keypad: Used for entering Fryer settings and to edit preset Menu Item cooking parameters.
Page 48 Fryer Operation GEF & GEF-VH Series Fryers 5.1.1 Keys and Functions - continued MENU Key: Action key which is pressed in combination with other keys to access programmed menu presets. Fifty (50) different Menu Item cooking presets can be programmed. EDIT Key: This is an action key which is pressed in combination with other keys to enter edit mode for changing or creating Menu preset settings.
Page 49: General Operation - Fryer Controller
Fryer Operation GEF & GEF-VH Series Fryers 5.1.2 General Operation - Fryer Controller The following is general operational information only. Detailed procedures and instructions are covered in subsequent sections. During operation, certain instructions and prompts will be shown on the Upper OLED Display to step Users through processes.
Page 50: Manually Setting A Cook Time & Cooking Temperature
Fryer Operation GEF & GEF-VH Series Fryers 5.1.3 Manually Setting a Cook Time & Cooking Temperature The following explains the process for manually entering a cooking time and temperature. Before setting a Temperature, be sure the Selector Switch is in the [OFF] position and that Pot is filled with cooking oil..
Page 51: Working With Menu Item Presets
Fryer Operation GEF & GEF-VH Series Fryers 5.1.4 Working with Menu Item Presets Fifty (50) Menu Item Preset cook settings are stored in the Controller, each includes: ● Menu # - Sequential ID number ● Menu Name - Name of the food item assigned to the preset. ●...
Page 52: Editing A Menu Preset
Fryer Operation GEF & GEF-VH Series Fryers 5.1.4.1 Editing a Menu Preset A. Edit [NAME] - Method 1: Enter NAME letter by letter. Scroll to NAME as explained on left. Use numeric keypad [2] & [8] (up/down) to scroll through letters.
Page 53 Fryer Operation GEF & GEF-VH Series Fryers 5.1.4.1 Editing a Menu Item Preset - continued C. Edit COOKING TIME: Scroll to and select [TIME] as explained on Page 41. Use numeric keypad to enter TIME (mm:ss) D. Edit SETPOINT TEMPERATURE: Scroll to and select [TEMP] as shown on Page 41. Use numeric keypad to enter TEMP (°F) NOTE: TEMP unit can be changed to (°C) in USER SETTINGS, see Section 5.01.7...
Page 54 Fryer Operation GEF & GEF-VH Series Fryers 5.1.4.1 Editing a Menu Item Preset - continued E. Edit STIR OVERRIDE Setting: Certain food products may or may not require stirring during the cook cycle, regardless of the global [STIR ALARM] setting in USER SETTINGS (Section 5.1.7). [STIR OVERRIDE] is provided so that [STIR ALARM] can be individually set for particular Menu Items.
Page 55: 5.1.4.2 Selecting A Menu Preset For Cooking
Fryer Operation GEF & GEF-VH Series Fryers 5.1.4.2 Selecting a Menu Preset for Cooking Before selecting a Menu Preset, be sure the Selector Switch is in the [OFF] position and that Pot is filled with cooking oil.. A. Direct Entry Method - Desired Menu # is B.
Page 56: Cooking Cycle - General Overview
Fryer Operation GEF & GEF-VH Series Fryers 5.1.5 Cooking Cycle - General Overview COOKING TEMPERATURE, MENU NAME, COOKING TIME, STIR OVERRIDE & FISH FILTER settings are shown on the Upper Display for each Menu Item Preset. A READY message indicates that the cooking oil is at temperature and the Fryer is ready for cooking.
Page 57: 5.1.6.2 Cool Mode
Fryer Operation GEF & GEF-VH Series Fryers 5.1.6.2 COOL Mode COOL Mode is an energy-saving feature that changes oil temperature setpoint to a lower value. Use to put Fryer into an idle (standby state) during downtime periods. To enter COOL MODE, press the COOL key. The temperature setpoint will be changed to the COOL TEMP specified in USER SETTINGS, see Section 5.1.7, Edit User Settings.
Page 58: User Settings - Access & Edit
Fryer Operation GEF & GEF-VH Series Fryers 5.1.7 User Settings - Access & Edit NOTE: The message “TOO LOW” or “TOO HIGH” will be displayed if a Press the Press the value being entered is outside the TIME key START key allowable range and would cause Use numeric keypad [4] - [6] (left/right) to scroll through list until a Controller error for the current...
Page 59: Password Protection
User Settings Menu. If you desire to have Password protection enabled, or have questions concerning this feature, call Giles Technical Services at 800.554.4537 to request the passcode and instructions as to how to enable this feature.
Page 60: 5.1.9.2 Start-Up Ventless, Gef-Vh
Fryer Operation GEF & GEF-VH Series Fryers 5.1.9.2 Start-up Ventless, GEF-VH NOTE: ⑥ Pressing the [ALARM] key will silence alarm tones. Alarm also silences automatically after a preset time expires. See USER SETTINGS.
Page 61: Controller Errors & Alarms
Fryer Operation GEF & GEF-VH Series Fryers 5.1.10 Controller Errors & Alarms Certain conditions, which can cause unsafe operation or damage to the unit, such as open valves, low oil level, high temp, etc. will activate error OLED codes and sound an alarm tone. Error Codes will display on the Lower 7-Segment Display;...
Page 62: 5.1.10.1 Resolving Controller Errors & Alarms
Internal ADC Error from thermocouples is not working. MCB1 board must be replaced. Contact Giles Tech Service (800.554.4537). 5.1.10.1 Resolving Controller Errors & Alarms DRAIN OPEN (Error Code OPEN) - If the pot Drain Valve is open (even slightly) while Fryer power is ON, an alarm tone sounds, Lower 7-Segment Display shows “OPEn”, and the Upper OLED Display reads “ERROR...
Page 63 Heating Elements are disabled until the condition is corrected. Clean/check the EAC Cell; the error will clear when the condition is resolved. See Section 7.1.6 through 7.1.9, EAC Filter Operation & Cleaning. NOTE: If an error condition cannot be resolved, please contact a factory-authorized service agent, or call 800.554.4537 for Giles Technical Support.
Page 64: Cooking Procedures
Fryer Operation GEF & GEF-VH Series Fryers Cooking Procedures This section explains cooking procedures for the both GEF and GEF-VH Series Fryers ... The procedures in most cases assume beginning with an empty, clean Fryer with Basket Lift in the raised position. 1.
Page 65 Fryer Operation GEF & GEF-VH Series Fryers Cooking Procedure - continued Cooking oil will be extremely HOT! Always wear thermal protection, such as oven mitts, when stirring hot oil. 9. As the cooking oil heats, use the provided Stirring Utensil to frequently stir oil from the pot bottom up. Doing so will prevent formation of cool zones, promote more even heating and help prevent occurrence of a false HI-LIMIT alarm while heating.
Page 66 Fryer Operation GEF & GEF-VH Series Fryers Cooking Procedure - continued 14. Manually input Temp/Time settings ... OR ... Menu Item Preset settings selected in Step-7 will be shown on the ⑬ Upper Display along with message “[START] TO COOK”. “READY” message indicates Fryer is ready for cooking.
Page 67 Fryer Operation GEF & GEF-VH Series Fryers Cooking Procedure - continued STIR ALARM NOTE: Step #17 applies only when USER SETTINGS are as follows: • Global STIR ALARM=[ON] & STIR OVERRIDE setting for the Menu Item=[NORMAL]. - OR - • Global STIR ALARM=[OFF] & STIR OVERRIDE setting for the Menu Item=[FORCE].
Page 68: Filtering Cooking Oil
Filter Media is installed correctly (1 sheet of Filter Paper). 6. Distribute approx. 5 oz. of Filter Powder (1-pack, Giles #72004) over filter media surface. It is important that a suitable filter aid be used for removal of soluble impurities and reconditioning of the oil.
Page 69 Fryer Operation GEF & GEF-VH Series Fryers Filtering Cooking Oil - continued The next steps require that cooking oil be drained from the Fry Pot into the Filter Pan, thus exposing the heating elements. Failure to place the Selector Switch in the [OFF] position prior to draining could result in fire.
Page 70 Fryer Operation GEF & GEF-VH Series Fryers Filtering Cooking Oil - continued ⑩ 11. After approx. 5 mins, turn the Drain Valve Handle to the [CLOSE] position (vertical). Allow the Pump to run until the Fry Pot refills. 12. When oil has been completely pumped back to the Fry ⑪...
Page 71: Removing Used Waste Cooking Oil From Fryer
In this section a Giles Oil Caddy (not included) is referenced as the waste oil disposal container. DO NOT attempt to pump or filter cold, congealed oil. The Filter Pump can clog and be damaged.
Page 72 6. Connect the Oil Discharge Hose to the Discharge Hose Coupling ⑨ 7. Place the discharge Wand end into a Waste Oil Disposal Container (Giles Oil Caddy shown, not provided). ⑩ 8. Turn the Oil Diverter Valve to the [TO DISCHARGE HOSE] position (horizontal).
Page 73 Fryer Operation GEF & GEF-VH Series Fryers Removing Used Waste Cooking Oil from Fryer - continued 10. After waste oil is removed from the Filter Pan, ⑫ place the Selector Switch and Power Switch ⑬ in the [OFF] position. ⑭ 11.
Page 74: Normal Shutdown
Fryer Operation GEF & GEF-VH Series Fryers Normal Shut-Down ① 1. Place the Selector Switch in the [OFF] position. ② 2. Place the Power Switch in the [OFF] ③ position, the Power Light will turn OFF. 3. To completely remove power from the appliance, turn OFF the circuit breaker in the main electrical panel providing power to the unit.
Page 75: Cleaning
Boil-Out powder to the water. Stir gently to mix. If using a cleaner other than Giles Boil-Out closely follow the manufacturer’s usage instructions. Many commercially available cleaners contain caustic chemicals, which require special precautions.
Page 76 Cleaning GEF & GEF-VH Series Fryers Boil Out Procedure - continued ③ 5. Place the Power Switch in the [ON] position. ④ 6. Place the Selector Switch in [COOK] position. 7. Controller will power-up. When alarm sounds, press [ALARM] key ... Fryer enters PREHEAT. Upper Display shows message “PRESS [BOIL] - GO TO BOIL-OUT”.
Page 77 Cleaning GEF & GEF-VH Series Fryers Boil Out Procedure - continued 13. Dry the Fry Pot with clean dry sanitized towels. Be sure all surfaces and heating elements are completely dry before adding fresh cooking oil. ⑧ 14. Slowly turn the Drain Valve Handle to the [CLOSE] vertical position.
Page 78: Cleaning The Filter Pan & Replacing Filter Media
Cleaning GEF & GEF-VH Series Fryers Cleaning Filter Pan & Replacing Filter Media This section describes the procedure for cleaning the Filter Pan and replacing the Filter Media. This should be performed after each Boil-Out Procedure (Section 6.1) and as part of the daily cleaning routine. Wear thermal hand protection as safeguard from hot parts.
Page 79 Cleaning GEF & GEF-VH Series Fryers...
Page 80: Ventless Hood
Ventless Hood GEF-VH Series Fryers Only Ventless Hood The following section applies ONLY to GEF-VH Ventless Hood Fryers. It describes operation and maintenance of the Fryer Integral Ventless Hood System. It is important that all Filters are properly installed, and that the Filter Access Cover is in place and securely latched before attempting to operate the appliance.
Page 81: Baffle Filter Removal
Ventless Hood GEF-VH Series Fryers Only 7.1.2 Baffle Filter Removal 1. Lift rear edge of Filter enough to clear the support channel. 2. Slide Filter toward the rear of Hood. 3. Drop the front edge down to clear the Front Panel. 4.
Page 82: Baffle Filter Installation
Ventless Hood GEF-VH Series Fryers Only 7.1.3 Baffle Filter Installation Switch arm must be actuated by the Baffle Filter when installed, as shown 1. Insert back edge of Filter into Hood to the Back Wall. 2. Lift front edge up. 3.
Page 83: Baffle Filter Cleaning
Ventless Hood GEF-VH Series Fryers Only 7.1.4 Baffle Filter Cleaning The Baffle Filter has sharp exposed edges, which may cause cuts; use due caution when handling and cleaning. Use of heavy duty rubber gloves is advised. Typically, the Baffle Filter needs to be cleaned daily. Wash Filter in sink with a mild degreaser and warm water. Rinse and dry thoroughly;...
Page 84: Eac Filter Installation
Ventless Hood GEF-VH Series Fryers Only 7.1.6 EAC Filter Cell Installation Pin must align with 1. Ensure the airflow indicator arrow points UP. hole in rear of Filter 2. Align Cell in the guide Channels and slide into the Cell. chamber.
Page 85: Eac Filter Cell Cleaning
Ventless Hood GEF-VH Series Fryers Only 7.1.8 EAC Filter Cell Cleaning The EAC Filter Cell must be cleaned DAILY to maintain peak hood performance. Take care not to bend the collection fins or break the ionizer wires when handling and cleaning the Cell.
Page 86: Eac Filter Cleaning Timer
Ventless Hood GEF-VH Series Fryers Only 7.1.9 EAC Filter Cleaning Timer GEF-VH Fryers produced after Feb 2016 are equipped with an E.A.C. Filter Cleaning Timer. This feature was developed to help Users adhere to the proper Filter Cell cleaning routine. Timely cleaning is necessary to ensure the Hood section continues to effectively clean the air.
Page 87: Charcoal Filter Removal & Installation
Never attempt to clean the Charcoal Filter; damage to the equipment could result. Typical replacement cycle is 30 to 40 days, depending on usage. Replace the Charcoal Filter with Giles Part No. 30248. Failure to use Giles OEM Replacement Parts and Filters may void the factory warranty.
Page 88: Filter Alarm Chart
Ventless Hood GEF-VH Series Fryers Only 7.1.12 Filter Alarm Chart The following table explains various Filter Alarms which may occur. When an alarm condition occurs, an audible alarm tone will sound. It will be a continuous tone or an intermittent (beeping) tone, depending on the type of the alarm.
Page 89: Maintenance
Inspection and testing of interlock function should be performed MONTHLY as described below. Check the appropriate box in the Service Log to indicate completion of a test. If problems are detected, contact a Giles authorize kitchen equipment service company to have the problem evaluated and repaired.
Page 90: Semi-Annual Fire Suppression System Inspection & Service
Ventless Hood GEF-VH Series Fryers Only 7.2.3 Semi-Annual Fire Suppression System Inspection & Service Inspection, servicing and maintenance of the Fire Suppression System must be performed by a qualified fire protection equipment service company, having credentials acceptable to local authorities having jurisdiction (AHJ). As a minimum, field inspection of the system shall be performed every six (6) months.
Page 91: 7.2.6 Maintenance & Service Log
Ventless Hood GEF-VH Series Fryers Only 7.2.6 Maintenance & Service Log Check Initial/Date Check Initial/Date RGS 1/15/10 5 6* 5 6* 5 6* 7* 5 6* 7* 5 6* 5 6* 5 6* 7* 5 6* 7* 5 6* 5 6* 5 6* 7* 5 6* 7* EAC Filter Check...
Page 92: Troubleshooting
Troubleshooting GEF & GEF-VH Series Fryers Troubleshooting IMPORTANT! This section describes basic troubleshooting procedures for GEF Model Electric Fryers. Some simple operational issues may be corrected by the User, however most in-depth troubleshooting, and repair, should be performed only by qualified service technicians. Temperature Control System Problem Probable Cause...
Page 93 Troubleshooting GEF & GEF-VH Series Fryers Temperature Control System - continued Problem Probable Cause Corrective Action FRYER WILL NOT HEAT: A. Baffle Filter missing Check, install Baffle Filter (VH Model Only) Power Light is ON Check, reinstall, or properly align Selector Switch is in COOK B.
Page 94 Troubleshooting GEF & GEF-VH Series Fryers Temperature Control System - continued Problem Probable Cause Corrective Action FRYER HEATS SLOWLY: Consult Operations Manual for proper A. Improper cooking procedures Slow heat recovery procedures Heat Light remains ON constantly B. One or more heating elements Check/replace faulty element(s) faulty C.
Page 95: Oil Filtration System
Troubleshooting GEF & GEF-VH Series Fryers Oil Filtration System Problem Probable Cause Corrective Action OIL NOT PUMPING BACK TO FRY A. Selector Switch not in [FILTER Place Switch in proper position POT: PUMP] position B. Air leak in the system (hoses, Check &...
Page 96: Parts List
Website: Email: Our goal at Giles is to provide the highest possible quality of service and assistance. To help us accomplish this, please have the following information readily available when calling, along with a brief description of the problem being experienced. Please record the unit information in the table below for quick reference.
Page 97: Control Panel & Front Header
Parts List GEF & GEF-VH Series Fryers Control Panel & Front Header Panel Front Front Header Not Shown...
Page 98 Parts List GEF & GEF-VH Series Fryers Control Panel & Front Header Regular GEF Fryer: Item Part Number QTY. Description 22976 AUDIOLARM, CONTINUOUS, 2-12 VDC 23754 THERMOSTAT, HILIMIT, WATLOW, 425DEG, 208/240 21950 HOLDER, FUSE, 300V, 15A, SC 0 TO 15 21900 FUSE, 15-AMP, SC-15 20366...
Page 99: Front Lower Cabinet
Parts List GEF & GEF-VH Series Fryers Front Lower Cabinet Not shown...
Page 100 Parts List GEF & GEF-VH Series Fryers Front Lower Cabinet Item Part Number Description 41699 COUPLING, QUICK DISCONNECT, FEMALE 38888 DIVERTER VALVE HANDLE 96688 DRAIN VALVE HANDLE 21386 SWITCH, LIMIT, SPDT, DRAIN, PREWIRED (BEHIND PANEL) 41900 COUPLING, QUICK-DISCONNECT, FEMALE 20304 TERMINAL BLOCK, GROUND, 4-12 GA WIRE 20303 TERMINAL BLOCK, 4-12 GA WIRE...
Page 101: Fry Pot
Parts List GEF & GEF-VH Series Fryers Fry Pot Not shown...
Page 102 Parts List GEF & GEF-VH Series Fryers Fry Pot Item Part Number Qty. Description 20306 ELEMENT, 6666W, 208V, GEF-720 20309 ELEMENT, 6666W, 240V, GEF-720 ELEMENT, 6666W, 480V, GEF-720 20313 21526 ELEMENT, ROUND, 5000W, 208V, GEF-560 21299 ELEMENT, ROUND, 5000W, 240V, GEF-560 ELEMENT, ROUND,3333W,208V, GEF-400 21527 21298...
Page 103: Rear Lower Cabinet
Parts List GEF & GEF-VH Series Fryers Rear Lower Cabinet Not shown Due to continuing equipment improvements, some actual components may appear different than depicted in this Manual.
Page 104 Parts List GEF & GEF-VH Series Fryers Rear Lower Cabinet Item Part Number Qty. Description 21245 CONTACTOR, 208VAC, 63A (GEF400/1PH, GEF400-560-720/3PH)) 20617 CONTACTOR, 240/480VAC, 63A (GEF400/1PH, GEF400-560-720/3PH) CONTACTOR, 208VAC, 80A (GEF-560) 21260 21261 CONTACTOR, 240VAC, 80A (GEF-560) 20513 BREAKER, CIRCUIT, 277V, 50A, 6 PL (1PH UNITS & 208/240V GEF720) 40770 SHAFT &...
Page 105: Basket Cover And Basket
Parts List GEF & GEF-VH Series Fryers Basket Cover & Basket Due to continuing equipment improvements, some actual components may appear different than depicted in this Manual.
Page 106 Parts List GEF & GEF-VH Series Fryers Basket Cover & Basket Item Part Number Qty. Description 33883 BASKET COVER, ASSY, GEF560/GEF720 33884 BASKET COVER, ASSY, GEF400 38930 BASKET CARRIER, ASSY, GEF-720 97132 BASKET CARRIER, ASSY, GEF-560 39165 BASKET CARRIER, ASSY, GEF-400 91811 BASKET, GEF-720 33703...
Page 107: Filter Pan
Parts List GEF & GEF-VH Series Fryers Filter Pan Assembly 14** Not shown Optional item, not included as standard...
Page 108 Parts List GEF & GEF-VH Series Fryers Filter Pan Assembly Item Part Number Qty. Description 40955 HOSE, 1/2NPT X 15.75 40649 CASTER, SWIVEL, 2-9/16, FILTER PAN 38842 FILTER PAN WELD ASSEMBLY (NOT COMPLETE, PAN ONLY) 30040-4 STUD, FILTER PAN HOLD DOWN FRAME 38841 HANDLE, SUPPORT FRAME, FILTER PAN 44150...
Page 109: Front Ventless Hood (Gef-Vh Only)
Parts List GEF & GEF-VH Series Fryers Front Ventless Hood (GEF-VH Only) Not shown...
Page 110 Parts List GEF & GEF-VH Series Fryers Front Ventless Hood (GEF-VH Only) Item Part Number Qty. Description 90254 FILTER ACCESS PANEL, ASSY 30248 CHARCOAL, FILTER ASSY 20520 FILTER, EAC, 20 IN 42300 FILTER, BAFFLE, 20 X 20 X 2, SS 23200 SWITCH, SNAP ACTION, ROLLER TYPE 21125...
Page 111: Rear Ventless Hood (Gef-Vh Only)
Parts List GEF & GEF-VH Series Fryers Rear Ventless Hood (GEF-VH Only) Hidden Due to continuing equipment improvements, some actual components may differ slightly from illustrations in this Manual.
Page 112 Parts List GEF & GEF-VH Series Fryers Rear Ventless Hood (GEF-VH Only) Item Part Number Qty. Description 39272 TANK, ANSUL, 1.5-GAL SS 23778 SWITCH, SIDE ROTARY, 240V, 30A, W/O ARM 23779 ROD, ADJUSTMENT 90054 ACTUATOR ARM, SWITCH, BAFFLE FILTER 33589 BLOWER, ASSY, VH-FRYERS 46125 DAMPER, FIRE, 10 X 10, 285 DEG LINK...
Page 113 Parts List GEF & GEF-VH Series Fryers Notes:...
Page 115 P.O. Box 210247 • 2750 Gunter Park Drive West • Montgomery, Al 36121-0247 USA Phone 334.272.1457 • Toll-Free 800.554.4537 (USA & Canada Only) • FAX 334.239.4117 • www.gfse.com Form No. 60831 (Rel. Jun.2003; Rev. I, May 2017)

This manual is also suitable for:

Gef-400 Gef-vh series Gef-720-vh Gef-560-vh Gef-400-vh Gef-560 ... Show all

GILES GEF Series Operation & Service Manual

Safety

1 Introduction

2 Installation

3 Overview

4 Pre-Operation Checkout

5 Fryer Operation

6 Cleaning

7 Ventless Hood

8 Troubleshooting

9 Parts List

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GILES GEF Series

Summary of Contents for GILES GEF Series

This manual is also suitable for:

Table of Contents
