ST Nucleo-64 STM32WL3 Series User Manual page 9

RF SMA antenna
ST morpho
(CN3)
RF shield
ARDUINO® Power
(CN5)
ARDUINO® Analog
(CN7)
IDD jumper
5V source selector
User push-buttons
(B1, B2, and B3)
5V LED (LD4)
RX_WAKEUP connection (C3 OFF)
IPD (integrated passive device)
48 MHz HSE crystal (X2)
UM3418 - Rev 1
Figure 3.
(JP2)
(JP1)
Figure 4. NUCLEO-WL33CCx PCB details of the MCU RF board
RF SMA antenna
NUCLEO-WL33CCx top view
UM3418
Hardware layout and configuration
ST morpho
(CN4)
ARDUINO® Digital
(CN6)
ARDUINO® Digital
(CN8)
ST-LINK COM status LED
(LD6)
ST-LINK power status LED
(LD5)
User LEDs
(LD1, LD2, and LD3)
Reset push-button (B4)
32.768 kHz LSE crystal (X1)
STM32WL33CCV6 (U1)
SMPS block
page 9/39
