UM3418
Hardware layout and configuration
Figure 5.
NUCLEO-WL33CCx bottom view
LVDO 3V3
LDO 5V
(U4)
(U3)
Embedded STLINK V3
Switch external/internal
power source (SW1)
®
USB-C
connector (CN15)
Figure 6.
NUCLEO-WL33CCx mechanical dimensions (in millimeters)
UM3418 - Rev 1
page 10/39
