HDMI Video Processor
CUSTOMER
SUPPORT
INFORMATION
SC-CSV-HDMI
Composite & S-Video
Order toll-free in the U.S. 800-959-6439
FREE technical support, Call 714-641-6607 or fax 714-641-6698
Mail order: Hall Research, 1163 Warner Ave. Tustin, CA 92780
Web site: www.hallresearch.com E-mail: info@hallresearch.com
To
UMA1173 Rev. NC
Advertisement
Related Manuals for Hall Research Technologies SC-CSV-HDMI
Summary of Contents for Hall Research Technologies SC-CSV-HDMI
- Page 1 SC-CSV-HDMI Composite & S-Video HDMI Video Processor UMA1173 Rev. NC CUSTOMER Order toll-free in the U.S. 800-959-6439 FREE technical support, Call 714-641-6607 or fax 714-641-6698 SUPPORT Mail order: Hall Research, 1163 Warner Ave. Tustin, CA 92780 INFORMATION Web site: www.hallresearch.com E-mail: info@hallresearch.com...
- Page 3 VGA / HDTV Video Processor TRADEMARKS USED IN THIS MANUAL Hall Research and its logo are trademarks of Hall Research. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment generates, uses, and can radiate radio...
- Page 4 Model SC-CSV-HDMI Contents 1. Introduction..........3 1.1 General..............3 1.2 Features .............. 3 2. Installation..........4 2.1 Connections............4 2.2 Connection Block Diagram ........4 3. Configuration & Operation...... 5 3.1 Input and Output..........5 3.2 Menus and Adjustments ........5 4.
- Page 5 VGA / HDTV Video Processor 1. Introduction 1.1 General The SC-CSV-HDMI has the ability to scale the analog video signal from Composite and S-Video sources into a digital HDMI output with a wide range of HDTV and PC resolutions; up to 1080p.
- Page 6 Model SC-CSV-HDMI 2. Installation 2.1 Connections Connect the video source to the Composite and/or S-VIDEO video input connectors. Connect the audio source to the analog L/R input connectors or use the TOSLink connecter if using an optical fiber audio input.
- Page 7 VGA / HDTV Video Processor 3. Configuration & Operation 3.1 Input and Output Figure 2 - Input Figure 3 - Output 3.2 Menus and Adjustments Pressing the Menu button will bring up the OSD menu controls on the screen. Use the up and down arrows to select the desired item, and then press MENU to select and enter into that items sub menu.
- Page 8 Model SC-CSV-HDMI FINETUNE When selected, a sub menu of input signal capture adjustments will appear. HUE – (default = 48) SATURATION – (default = 63) SHARPNESS – (default = 20) NOISE REDUCTION - (default = off) COLOR When selected, a sub menu of input signal capture adjustments will appear.
- Page 9 VGA / HDTV Video Processor OUTPUT Use arrows to adjust output mode. Refer to Section 5.2 below for a list of all available modes. The default output resolution after a factory reset is “NATIVE” with the input source set to “AV”. The unit has non-volatile memory and memorizes all your settings before power off and recalls those settings on the next power on.
- Page 10 (or you have no picture output), please first try to reset to factory default settings. 4.1 Contacting Hall Research If you determine that your SC-CSV-HDMI is malfunctioning, do not attempt to repair the unit. Contact the Hall Research Technical Support department at 714-641-6607.
- Page 11 VGA / HDTV Video Processor 5. Specifications 5.1 General Input ports (1) RCA (CV) (1) S-VIDEO (1) TOSLink (Optical Fiber Input) (2) RCA (Audio L/R) Output ports (1) HDMI Output (1) 3.5mm Analog Audio Output (1) TOSLink (Optical Fiber Output) Power Supply 5V/2.6A DC (CE/FCC/UL certified) Dimensions...
- Page 12 Model SC-CSV-HDMI...
- Page 13 VGA / HDTV Video Processor...
- Page 14 Model SC-CSV-HDMI...
- Page 16 © Copyright 2009. Hall Research, Inc. All rights reserved. CUSTOMER Order toll-free in the U.S. 800-959-6439 FREE technical support, Call 714-641-6607 or fax 714-641-6698 SUPPORT Mail order: Hall Research, 1163 Warner Ave. Tustin, CA 92780 INFORMATION Web site: www.hallresearch.com E-mail: info@hallresearch.com...
