Black Projector Ceiling Mount
SKU: MOUNT-VP01B
Instruction Manual
ASSEMBLY VIDEO AVAILABLE:
Follow along step-by-step with our video walk through by scanning
the QR code with your mobile device or by following the product
link: vivo-us.com/products/mount-vp01b
www.vivo-us.com
help@vivo-us.com
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VP01B
Summary of Contents for Vivo MOUNT-VP01B
- Page 1 Black Projector Ceiling Mount SKU: MOUNT-VP01B Instruction Manual ASSEMBLY VIDEO AVAILABLE: Follow along step-by-step with our video walk through by scanning the QR code with your mobile device or by following the product link: vivo-us.com/products/mount-vp01b www.vivo-us.com help@vivo-us.com 309-278-5303...
- Page 2 7AM - 7PM Monday-Friday Give us a Call: Chat Us: Email Us: 309-278-5303 www.vivo-us.com help@vivo-us.com We’re Here for You! Our customer-minded support team is here for YOU, Monday-Friday 7am-7pm CST. We offer immediate assistance with rapid response times from customer service agents and product techncians to...
-
Page 3: Weight Capacity
Returns | Product Didn’t Work Out? We offer a hassle-free 30 day return on all products. Contact customer support at 309-278-5303 or help@vivo-us.com. Please note: For items ordered in error or no longer needed, the return shipping charges will be at the buyer’s expense. -
Page 4: Package Contents
Outside Diameter CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR CEILING CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 5: Assembly Steps
ASSEMBLY STEPS STEP 1: Cable Management OPTION A: Above Ceiling Cable Management If cables will be hidden above the ceiling, route cables through large opening in Ceiling Mount (A). OPTION B: Below Ceiling Cable Management If cables are located below ceiling, route cables through the side of Ceiling Mount (A). Ceiling Mount... - Page 6 STEP 2: Installing the Ceiling Mount OPTION A: Wood Ceiling Joist Installation Align holes in Ceiling Mount (A) with wood ceiling joist and mark drilling locations. Use of a stud finder is recommended for finished ceilings. Drill 55mm (2.2”) deep holes using 4.5mm or 3/16” drill bit.
- Page 7 STEP 3: Securing the Projector Align arms on Mounting Bracket (B) with mounting holes in projector, and secure to projector using Screws (M-A through M-D) and Washers (M-E through M-H) most appropriate for your projector. If your projector has 3 mounting holes, simply remove one of the arms. M-A, M-B, M-C, M-D M-E, M-F, M-G, M-H M3x8mm...
- Page 8 STEP 5: Securing the Mount Secure Mounting Bracket (B) using M5x12mm Screws (M-I), M5 OD-10 Washers (M-J) and M5 OD- 10 Plastic Washers (M-K). Tighten with 4mm Allen Wrench (T-A). M5x12mm Screw M5 OD-10 Washer M5 OD-10 Plastic Washer...
- Page 9 STEP 6: Positioning the Mount Adjust angle and rotation of projector using 4mm Allen Wrench (T-A). -15° 15° +15° -15° 4mm Allen Wrench...
- Page 10 WHO WE ARE VIVO is more than a brand of ergonomic office furniture. We are a team of creative and innovative indivuduals working together to offer high quality, affordable ergonomic solutions. We think and work outside of the box to serve...
-
Page 11: Need Assistance
Call Us: 309-278-5303 Average Resolution Time: 5m 4s Chat Us: www.vivo-us.com Average Resolution Time: < 15m Email Us: help@vivo-us.com Average Resolution Time: 1HR 8M 23% within < 15m 38% within <... - Page 12 LOVE YOUR NEW VIVO SETUP? Ready to share that new amazing setup? Want to brag about that amazing new ergonomic solution? Tag us in your photo! VIVO-us @vivo_us FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM LAST UPDATED: 06/28/2022 REV1LF...
