HOMCOM 821-024V70 Instruction Manual page 13

Model No:
Power Supply:
Dehumidity Capacity:
Rated Input Power:
Rated Input Current:
Water Tank Capacity:
Dimensions:
Room Temperature:
Refrigerant:
Fuse:
The specification may be subject to change without notice for purpose of improvement .
Check the following for repairs:
Malfunction
Check to see if the power plug
is disconnected.
Check to see if the water tank
is full of water.
No operation
Check to see if the water tank
is in the correct position.
Check to see if all the flaps are
closed.
Check if the filters are dirty.
Check to see if the air openings
are blocked.
Dehumidified
volume is small
Check to see if the
dehumidifier is in 'air clean'
mode.
Check to see if the unit is
Loud sounds
installed properly.
while operating
Check to see if the room
Operation
temperature is higher than the
stops during
set opeating temperature.
spot
dehumidifying
821-024V70 (FDD16 - 5291ZFUR5)
220V-240V~ 50Hz
16L/ Day( 30°C /80 %)
350W
1.80A
5.5 L
Height 600mm, Length 355mm, width 200mm
5 °C-32 °C
R290/ 55g
AC250V 3.15A
Points to be checked Measures to be taken
Firmly insert the plug into an
electric outlet.
Empty the tank.
Ensure the tank is firmly in place.
Open one of the flaps.
Clean the filters as specified.
Remove obstacles from the air
openings.
Change the operation mode to the
'dehumiditying' mode.
Install the unit on a level and stable
ground.
The dehumidifying operation will
start automatically when the
temperature lowers.
13
