IN230700185V01_UK_821-010V70
EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION
ULTÉRIEURE.
ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS.
PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE.
DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
IT _ IMPORTANTE! CONSERVARE IL PRESENTE MANUALE PER FUTURO RIFERIMENTO E
LEGGERLO ATTENTAMENTE.
IN230700185V01_UK_821-
US_CA
US_CA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HOMCOM 821-010V70
Summary of Contents for HOMCOM 821-010V70
- Page 1 IN230700185V01_UK_821- IN230700185V01_UK_821-010V70 EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION ULTÉRIEURE. ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS. PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE. DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN. IT _ IMPORTANTE! CONSERVARE IL PRESENTE MANUALE PER FUTURO RIFERIMENTO E LEGGERLO ATTENTAMENTE.
- Page 3 Thank you for choosing our Dehumidifier to provide you and your family with your home comfort needs. This owner's manual will provide you with valuable information necessary for the proper care and maintenance of your new dehumidifier. Please take a few moments to read the instructions thoroughly and familiarize yourself with all the operational aspects of this dehumidifier.
-
Page 4: Safety Warnings
SAFETY WARNINGS When using the unit, please observe the following safety precautions: 1. Unplug the power supply cord before cleaning or storage . 2. The appliances can be used indoor but not in laundry rooms. 3. Do not set the unit close to heat-generating devices or near flammable and dangerous materials. - Page 5 WARNING Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). Do not pierce or burn.
-
Page 6: Product Diagram
C Technical Data SPECIFICATIONS Model D015R2A-10L D015R2A-12L Power Supply 220V-240V～50Hz Refrigerant/charge R290/45g R290/50g The dehumidification capacity is rated at a room temperature of 30℃ with a relative humidity of 80%. If specifications are improved after this pointing, the product nameplate will reflect the new specifications. - Page 7 LED INDICATORS 1. POWER 2. CHILD LOCK 3. UP/DOWN 4. TIMER/ HUMIDITY DISPLAY 5. TIMER/ HUMIDISTAT SETTING 6. FAN SPEED (LOW/ HI) Humidity Level & Timer 2 digit display The indicator features 3 functions:。 1. when the unit is plugged in, it will indicate the room humidity level. 2.
- Page 8 DRAINING THE COLLECTED WATER When the drainage tank is full, the tank full indicator light will turn on, the operation will stop automatically and the buzzer will beep 15 times to alert the user, that the water need to be emptied from the drainage tank. Emptying the Drainage Tank 1.
- Page 9 NOTE 1. Do not remove the float from the water tank. The water full sensor will no longer be able to detect the water level correctly without the float and water may leak from the water tank. 2. If the drainage tank is dirty, wash it with cold or lukewarm water. Do not use detergent, scouring pads, chemically treated dust cloths, gasoline, benzene, thinner, or other solvents, as these can scratch and damage the tank and cause water leakage...
-
Page 10: Maintenance
MAINTENANCE Cleaning the Dehumidifier To clean the Body Wipe it with a soft damp cloth. To Clean the Air Filter 1.Open the inlet grill firstly and remove the air filter 2. Clean the air filter Run a vacuum cleaner lightly over the surface of the air filter to remove dirt. If the air filter is exceptionally dirty, wash it with warm water and a mild cleanser and dry thoroughly. - Page 11 3. Attach the air filter Insert the filter into the grill smoothly, and place the inlet grill into right place. Storing the Dehumidifier When the unit is not being used for a long period of time and you want to store it note the following steps: 1.
-
Page 12: Troubleshooting
TROUBLESHOOTING If a condition listed below occurs, please check the following items before calling customer service. Problem Possible Cause Solution Has the power cord been Plug the power cord disconnected? into the outlet. Is the tank full indication Empty the water in the lamp blinking? (The tank drainage tank and then The unit doesn't... - Page 13 NOTE FOR MAINTENANCE WORK 1.Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised.For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
- Page 14 8.Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and components inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with.
- Page 15 13.Leak detection methods The following leak detection methods are acceptable for systems containing flammable refrigerant. Electronic leak detectors shall be used to detect flammable refrigerants, but the sensitivity may not be adequate, or may need recalibration (Detection equipment shall be calibrated in a refrigerant-free area.) Ensure that detector is not a potential source of ignition and is suitable for the refrigerant used.
- Page 16 all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to reuse of reclaimed refrigerant. It is essential that electrical power is available before the task is commenced.
- Page 17 The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery units and especially not in cylinders. If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant.
