What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Top CF Star Ring
Bottom CF Star Ring
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
CF Carbon Fiber Star Ring for Handheld Gimbal
Camera Stabilizers & Body Support Rigs
A s s e m b l y M a n u a l
4 x Allen Bolts
(Size: 4 x 20)
2 x L-type Allen key
(Size:- 5mm, 3mm)
1 x T-type Allen key
(Size:-2.5mm)
All rights reserved.
statutes or in writing by the Publisher.
4 x Allen Bolts
4 x Allen Bolts
(Size: 4 x 16)
(Size: 3 x 12)
(P-STRG-CF)
4 x Allen Bolts
(Size:-3 x 10)
Bag Packing
1
Advertisement
Related Manuals for PROAIM P-STRG-CF
Summary of Contents for PROAIM P-STRG-CF
- Page 1 CF Carbon Fiber Star Ring for Handheld Gimbal Camera Stabilizers & Body Support Rigs (P-STRG-CF) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 FUNCTION Quick Release Adapter Underslung and over-slung mode using the quick- release adapter with M3 and M4 threads Wide compatibility movi & R2 Quick release plate with additional accessory security, control over your 2-axis and 3-axis gimbals with the adapter Scalling Index Marking Index marking to...
- Page 3 Setup CF Carbon Fiber Star Ring • Attach the top CF & bottom CF Star Ring. NOTE: The portable and travel-friendly design can be detached into two pieces to ensure comfortable carriage to different shooting locations. • After attaching the Star Ring, tighten the allen bolts it using the 2.5mm Allen key, as shown in the image.
- Page 4 Feature: Its robust spool clamps effortlessly attach to most body support rigs, such as Proaim Hawk Body Support, Hawk Lite Body Support, Gimbal Bird Body Support, and Flycam Flowline Camera Gimbal Tilt Control Kit.
- Page 5 Quick Release Adapter Assembly Inside • To straighten the quick-release adapter on the Top CF Star Ring, loosen all its bolts using the Allen key. • Detach the quick-release adapter as shown. • Attach the quick-release plate from the bottom side of the Top CF Star Ring. •...
- Page 6 • Insert the bolt in the quick-release plate. NOTE: It can be used in both underslung and over-slung mode using quick-release adapters with M3 and M4 threads, to which the MOVI quick-release plate and R2 quick-release plate can be mounted, respectively. •...
- Page 7 YOUR PROAIM CF CARBON FIBER STAR RING FOR HANDHELD GIMBAL CAMERA STABILIZERS & BODY SUPPORT RIGS ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase.
