WamBam WESTPORT BL19105 Assembly Instructions Manual

4 ft vinyl privacy fence (4'h x 6'w)

Advertisement

Quick Links

ASSEMBLY INSTRUCTIONS
WESTPORT
4 FT VINYL
PRIVACY FENCE
Approximate assembly time
Want to see a video on how to
assemble this product?
Scan the QR code
WWW.WAMBAMFENCE.COM
WWW.WAMBAMFENCE.COM
(4'H X 6'W)
60 MIN
ASSEMBLY
INSTRUCTIONS
BL19105
BL19105
VER. 043021
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WESTPORT BL19105 and is the answer not in the manual?

Questions and answers

Summary of Contents for WamBam WESTPORT BL19105

  • Page 1 BL19105 ASSEMBLY INSTRUCTIONS WESTPORT ASSEMBLY INSTRUCTIONS 4 FT VINYL BL19105 PRIVACY FENCE (4’H X 6’W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM VER. 043021 WWW.WAMBAMFENCE.COM...
  • Page 2 BL19105 ASSEMBLY INSTRUCTIONS GENERAL INFORMATION MISSING DAMAGED PARTS? Visit Our Website so we can help you right away! parts.nychbrands.com You can also reach us via phone or email. Weekdays 9am-5pm EST Hours of Operation To better help you, Your product number (BL19105) please have the following Your original product box...
  • Page 3 BL19105 ASSEMBLY INSTRUCTIONS AVOID THESE PITFALLS! HAVE YOU CONTACTED You must call your local utilities before you start installing your fence to avoid puncturing any unseen underground YOUR LOCAL UTILITIES? utilities, especially electrical or gas lines. Fortunately, this is made easy for you. Simply call 811 in the US or visit www.call811.com.
  • Page 4 BL19105 ASSEMBLY INSTRUCTIONS WARNING! If your yard has a severe slope or an elevation change greater than approximately 3” to 4” over one panel of fence, you will not be able to install this fence. Your post will not be long enough to accommodate this slope.
  • Page 5 BL19105 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS Pipe Anchor Detail 4in x 4in Post 48 in 24 3/4 in 24 3/4 in 3 in Ground 72” Inside of pipe to inside of pipe 35 in 74” center of pipe to center of pipe Ground 1 5/8 in Galvanized Pipe INSTALL ONE COMPLETE PANEL OF FENCE FIRST.
  • Page 6 BL19105 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: Post Cap (1) Post (1) 4” x 4” x 53” Rails (2) Boards (6) Bracket (4) 1½” x 3½” x 69¾” 1/2” x 12” x 423/8” Donut and gear Pipe Anchor (1) Channel (2) ¾”...
  • Page 7 BL19105 ASSEMBLY INSTRUCTIONS TIPS Run a string line to help establish the post location(s). To space the pipe anchors more easily, use a piece of wood measuring 717/8” in length from the inside gear to the next pipe anchor. After you have installed the first two posts and have checked your spacing, temporarily remove the vinyl posts to create an unobstructed string line.
  • Page 8 BL19105 ASSEMBLY INSTRUCTIONS INSTALL PIPE ANCHORS AND POSTS STEP 2: STEP 2.1 Drive your first Pipe Anchor into the ground until the bottom donut touches the ground. Check for level every 12”. String line Donut Note: If you are using a post pounder, remove the top donut Your and slide it up over the pipe.
  • Page 9 BL19105 ASSEMBLY INSTRUCTIONS STEP 2.2 Identify the location of your second pipe anchor and drive it into the ground. 71 7/8” 74” Note: The distance between the inner plastic gears (not donuts) to the pipe should be 717/8” (or center to center of pipe at 74”). STEP 2.3 If you removed the upper donut, slide it back down over the inner gear.
  • Page 10 BL19105 ASSEMBLY INSTRUCTIONS STEP 2.4 STEP 2.5 Adjust the bottom and top donuts Slide the Posts down over the donuts. to compensate for a crooked pipe anchor. Note: Pull the donut tabs out and lift up to remove and adjust the donut Recommended: On flat ground, bury position.
  • Page 11 BL19105 ASSEMBLY INSTRUCTIONS STEP 3.2 Place the second bracket over the opposite end of the Rail and slide the rail down into the bracket on the opposing side. Note: There could be a slight conflict between the head of the exposed screw and the end of the rail in a tight fitting application.
  • Page 12 BL19105 ASSEMBLY INSTRUCTIONS STEP 3.3 Use a level on the top of the bottom rail to determine the height of the opposing bracket, and mark for installation. STEP 3.4 Temporarily remove the bottom rail and install the lower brackets using (4) total 3/4” screws. WWW.WAMBAMFENCE.COM...
  • Page 13 BL19105 ASSEMBLY INSTRUCTIONS STEP 3.5 Insert the bottom rail into the lower brackets and secure the rail with (4) total 3/4” screws. STEP 3.6 Step 1: Center and install your Channel using (3) 3/4” screws per channel. Step 2: Align your final brackets flush on top of the channels.
  • Page 14 BL19105 ASSEMBLY INSTRUCTIONS INSTALL BOARDS AND POST CAPS STEP 4: STEP 4.1 Install the Boards by sliding the outer boards through the brackets and channels. The inner boards link together with their own track system. Note: Ensure that boards 1 are pushed to the back of the track.
  • Page 15 BL19105 ASSEMBLY INSTRUCTIONS INSTALL BOARDS AND POST CAPS STEP 4: STEP 4.2 Install top rail and secure with (4) ¾” screws through the pre-drilled holes in the rail brackets. STEP 4.3 Trim down the tops of the posts if necessary, and install the Post Caps (A).
  • Page 16 BL19105 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 hmmm@wambamfence.com 704-892-5222 877-778-5733 WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM...
