WamBam NANTUCKET BL19101 Assembly Instructions Manual
Vinyl picket fence with post and no-dig steel pipe anchor kit
Hide thumbs
Also See for NANTUCKET BL19101:
- Quick start manual (3 pages) ,
- Assembly instructions manual (10 pages)
Advertisement
Quick Links
ASSEMBLY INSTRUCTIONS
NANTUCKET
VINYL PICKET FENCE
WITH POST AND
NO-DIG STEEL PIPE
ANCHOR KIT
Approximate assembly time
Want to see a video on how to
assemble this product?
WWW.WAMBAMFENCE.COM
WWW.WAMBAMFENCE.COM
(4'H X 6'W)
60 MIN
Scan the QR code
ASSEMBLY
INSTRUCTIONS
BL19101
BL19101
VER. 043021
1
Advertisement
Related Manuals for WamBam NANTUCKET BL19101
Summary of Contents for WamBam NANTUCKET BL19101
- Page 1 BL19101 ASSEMBLY INSTRUCTIONS NANTUCKET ASSEMBLY INSTRUCTIONS VINYL PICKET FENCE BL19101 WITH POST AND NO-DIG STEEL PIPE ANCHOR KIT (4’H X 6’W) 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM VER.
- Page 2 BL19101 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 BL19101 ASSEMBLY INSTRUCTIONS TIPS Run a string line to help establish the post location(s). To space the pipe anchors more easily, use a piece of wood measuring 70⅜” in length from the inside gear to the next pipe anchor. After you have installed the first two vinyl posts and have checked your spacing, temporarily remove the posts to create an unobstructed string line.
- Page 4 BL19101 ASSEMBLY INSTRUCTIONS AVOID THESE PITFALLS! HAVE YOU CONTACTED You must call your local utilities before you start installing your fence to avoid puncturing any unseen underground YOUR LOCAL UTILITIES? utilities, especially electrical or gas lines. Fortunately, this is made easy for you. k Simply call 811 in the US or visit www.call811.com.
- Page 5 BL19101 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS 1 in 3.46 in 1.5 in Pipe Anchor Detail 1.5 in. 3.5 in 3.5 in. 4in x 4in Post 48 in 33 in 26 in 26in. 3.5 in 3 to 4 in 2 in Ground 68 in...
- Page 6 BL19101 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: Post Cap (1) Post (1) 4” x 4” x 53” Bracket (4) Top Rail (1) Picket (13) 1½” x 3½” x 67¾” ⅞” x 1½” x 44¼” Donut and gear 1” Self-Drilling Stainless Bottom Rail (1) Pipe Anchor (1) Steel Screw (24)
- Page 7 BL19101 ASSEMBLY INSTRUCTIONS INSTALL PIPE ANCHORS AND POSTS STEP 2: STEP 2.1 After establishing your fence lines with string and stakes, drive your first Pipe Anchor into the ground. The bottom of the donut should sit just above the ground when finished. Note: Try to drive the pipe anchor as level as possible.
- Page 8 BL19101 ASSEMBLY INSTRUCTIONS STEP 2.4 STEP 2.5 Adjust the bottom and top donuts Slide the Posts down over the donuts. to compensate for a crooked pipe anchor. Note: The ground can be dug out about 3” to 4” to allow post bottoms to sit below the ground if necessary.
- Page 9 BL19101 ASSEMBLY INSTRUCTIONS STEP 3.3 STEP 3.4 Use a level on the top of the bottom rail Temporarily remove the bottom rail and to determine the height of the opposing install the lower brackets using (4) total 1” bracket, and mark for installation. self-drilling stainless steel screws.
- Page 10 BL19101 ASSEMBLY INSTRUCTIONS INSTALL PICKETS AND POST CAPS STEP 4: STEP 4.1 Install the Pickets by inserting them through the top rail and locking them into the bottom rail. Note: Pickets cannot be removed once inserted. STEP 4.2 Trim down the tops of the posts if neces- sary, and install the Post Caps (A).
- Page 11 BL19101 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 hmmm@wambamfence.com 704-892-5222 877-778-5733 WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM...
