ASSEMBLY INSTRUCTIONS
NANTUCKET
VINYL PICKET
GATE WITH WITH
STAINLESS STEEL
HARDWARE
(48"H X 48"W)
Approximate assembly time
Want to see a video on how to
assemble this product?
Scan the QR code
WWW.WAMBAMFENCE.COM
WWW.WAMBAMFENCE.COM
60 MIN
ASSEMBLY
INSTRUCTIONS
BL19102
BL19102
1
VER. 043021
