Siemens SIMATIC NET RUGGEDCOM RS940G Equipment Manual page 44

61000-4-6
61000-4-8
61000-4-29
61000-4-11
61000-4-12
61000-4-16
61000-4-17
60225-27
RUGGEDCOM RS940G
Equipment Manual, 10/2023, C79000-G8976-1036-09
Test
IEC Induced (Conducted) RFI
IEC Magnetic Field
IEC Voltage Dips and Interrupts
IEC
IEC Damped Oscillatory
IEC Mains Frequency Voltage
IEC Ripple on DC Power Supply
IEC Dielectric Strength
HV Impulse
6.2 EMC and Environmental Type Tests
Description
DC Power
Ports
AC Power
Ports
Signal Ports
D.C Power
Ports
AC Power
Ports
Earth
ground Ports
Enclosure
Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
DC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Test Levels
± 2 kV line-to-earth,
± 1 kV line-to-line
± 4 kV line-to-earth,
± 2 kV line-to-line
10 V
10 V
10 V
10 V
40 A/m continuous,
1000 A/m for 1 s
30% for 0.1 s, 60% for
0.1 s, 100% for 0.05 s
30% for 1 period,
60% for 50 periods
100% for 5 periods,
100% for 50 periods
2.5 kV common, 1 kV
differential mode @ 1 MHz
2.5 kV common, 1 kV
differential mode @ 1 MHz
2.5 kV common, 1 kV
differential mode @ 1 MHz
30 V Continuous,
300 V for 1 s
30 V Continuous,
300 V for 1 s
10%
2 kVAC (Fail-
Safe Relay output)
2 kV
2 kV
5 kV (Fail-Safe
Relay Output)
5 kV
5 kV
Certification
Severity
Levels
3
4
3
3
3
3
3
3
3
4
4
3
35
