Installing the Device
2.5.2 Connecting Low DC Power
16
2
1
3
Positive Terminal
1
Negative Terminal
2
Surge Ground Terminal
3
Braided Ground Cable
4
Figure 2.6
Terminal Block Wiring - Single DC Power Supply Inputs
4
RUGGEDCOM RS940G
Equipment Manual, 10/2023, C79000-G8976-1036-09
