Note
If any item is missing or damaged, contact Siemens for assistance.
2.3 Mounting the Device
The RUGGEDCOM RS940G is designed for maximum mounting and display flexibility.
It can be equipped with connectors that allow it to be installed in a 35 mm (1.4 in)
DIN rail or directly on a panel.
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with either DIN rail or panel hardware installed,
refer to "Dimension Drawings" (Page 28).
2.3.1 Mounting the Device on a DIN Rail
The RUGGEDCOM RS940G can be ordered with a DIN rail adapter preinstalled on the
back of the chassis. Use the adapter to mount the device to a standard 35 mm (1.4
in) IEC/EN 60715 or TS35 DIN rail.
To mount the device to a DIN rail, do the following:
Mounting the Device
To mount the device to a DIN rail, do the following:
1.
RUGGEDCOM RS940G
Equipment Manual, 10/2023, C79000-G8976-1036-09
NOTICE
Hook the top teeth of the adapter onto the DIN rail.
Note
The adapter features a sliding release with a slot at the bottom for a flathead
screwdriver.
