Device Management
This section describes how to connect to and manage the device.
3.1 Connecting to the Device
The following describes the various methods for accessing the RUGGEDCOM RS940G
console and Web interfaces on the device. For more detailed instructions, refer to the
"RUGGEDCOM RS940G Configuration Manual" for the RUGGEDCOM RS940G.
Ethernet cables should be only be connected/disconnected in a non-hazardous area,
or when the device is not energized.
RS232 Serial Console Port
Connect a PC or terminal directly to the serial console port to access the boot-time
control and RUGGEDCOM RS940G text="family"/> ROS console interface.
The serial console port is intended to be used only as a temporary connection during
initial configuration or troubleshooting, and should only be used in a safe area (as
defined by IEC 60079-0, Edition 6.0).
The serial console port implements RS-232 DCE (Data Communication Equipment) on
a DB9 connector. Use the following settings to connect to either port:
Speed
Data Bits
Stop Bit
Parity
Flow Control
Terminal ID
RUGGEDCOM RS940G
Equipment Manual, 10/2023, C79000-G8976-1036-09
NOTICE
NOTICE
57600 baud
8
1
None
Off
VT100
