For specifications on the available copper Ethernet ports, refer to "Copper Ethernet
Port Specifications" (Page 26).
4.2 Fiber Optic Ethernet Ports
Fiber optic Ethernet ports are available with either LC (Lucent Connector) and SC
(Standard or Subscriber Connector) connectors. Make sure the Transmit (Tx) and
Receive (Rx) connections of each port are properly connected and matched to
establish a proper link.
1
1
2
Figure 4.4
For specifications on the available fiber optic Ethernet ports, refer to "Fiber Optic
Ethernet Port Specifications" (Page 26).
4.3 SFP Transceivers
The RUGGEDCOM RS940G features four Small Form-Factor Pluggable (SFP)
transceiver sockets, which are compatible with a wide array of SFP transceivers
available from Siemens.
LEDs
Each socket features an LED that indicates its link state.
Green (Solid)
Green (Blinking)
Off
Compatible SFP Transceivers
The following SFP transceivers are compatible with the RUGGEDCOM RS940G.
For more information, including installation/removal instructions and ordering
information, refer to the
support.industry.siemens.com/cs/ca/en/view/109482309]".
RUGGEDCOM RS940G
Equipment Manual, 10/2023, C79000-G8976-1036-09
2
Tx Connector
Rx Connector
LC Port
State
"RUGGEDCOM SFP Transceiver Catalog [https://
4.2 Fiber Optic Ethernet Ports
1
Tx Connector
1
Rx Connector
2
Figure 4.5 SC Port
Description
Link established
Activity
No link detected
