Rimage 360i
d. If your USB cable was secured with a tie wrap as shown below, secure it now.
i. Ensure that the USB cable is connected to the USB adaptor.
ii. Thread a tie wrap through the middle hole as shown below.
iii. Hold the USB cable on the drive housing near the tie wrap.
iv. Secure the USB cable with the tie wrap.
v. Trim the tie wrap with scissors or side cutters.

2. Reassemble the Rimage 360i.

a. Install the recorder access cover.
Important: When you install the
recorder access cover, place
the top of the cover over the
hooks as shown.
b. Use the T10 Torx screws to secure
the recorder access cover.
c. Close the front cover to secure the
latch.
3. Connect the power cord.
4. Press the power switch to power on the Rimage 360i. The Rimage 360i is ready for use.
4
Tie Wrap
© 2006, Rimage Corporation
Cover Latch
Recorder
Access Cover
T10 Torx Screws
112104_C
