Rimage 360i
2. Remove the recorder.
a. If the USB cable on your unit is secured as
shown, carefully remove the tie wrap using
scissors or side cutters.
Important! Do not damage or cut the
cable.
b. Disconnect the DC cable.
c. Disconnect the USB adaptor and
attached cables.
d. While pressing the indentation on the right
side of the recorder, slide the recorder and
the attached brackets out the back of the
Rimage 360i to remove them.
2
Tie Wrap
USB Adaptor and
attached cables
Indentation
© 2006, Rimage Corporation
DC Cable
112104_C
