Introduction

Pneumatic-Pneumatic positioner series IP5000 is to be mounted to pneumatic operated actuator.
Pneumatic pilot valve is operated by the signal pressure from adjustment device and accurately
control the motion of actuator.
1.Specofocations
Type
Item
Supply pressure
Input pressure
Standard stroke
Sensitivity
Linearity
Hysteresis
Repeatability
Output flow rate
Note1
Air consumption
Note2
Ambient and using fluid
Temperature
Thermal coefficient
Air connection port
Material
Mass
Size
Note1：Refer to Fig. 1 for details of the output flow rate.
Note2：Refer to Fig. 2 for details of the air consumption.
＊ Standard air temperature(JIS B0120) : 20°, Absolute pressure : 101.3KPa,Relative humidity :
65%
Fig.1 Output flow rate characteristic
Table 1

Specifications

IP5000
Lever type lever
Single action Double action
10～85mm
Within 0.1%F.S.
Within ±
1%F.S.
Within
0.75%F.S.
80 L /min (ANR) or more (SUP.=0.14MPa)
200 L /min(ANR) or more (SUP.=0.4MPa)
Within 5 L /min (ANR) (SUP.=0.14MPa)
Within 11 L /min (ANR) (SUP.=0.4MPa)
Aluminum diecast, Stainless steel, Brass, Nitrile rubber
Approx. 1.4kg
118×102×86(Body)
- 5 -
Single action
0.14～0.7MPa
0.02～0.1MPa
Within 0.5%F.S.
Within ±2%F.S.
Within 1%F.S.
Within ±0.5%F.S.
-20℃～80℃ (Standard)
Within 0.1%F.S./℃
Rc1/4 (Standard)
118×92×77.5(Body)
Fig.2 Air consumption characteristic
IP5100
Rotary type cam
Double action
60°～100°
Approx. 1.2kg
