SKYLOONG GK68 / SK68 / AK68 - USB Wired Mechanical Keyboard Manual

Tips

fn tips: Unlock/Lock the WIN key, prevent windows start pop-ups in the game.
fn tips: fn+space ON/OFF the BT mode, link to USB mode.
Bluetooth condition: Z, X, C one of blue led is flashing, the keyboard is connecting the BT equipment.
fn tips: If you are not sure which mode the keyboard is in now, press [n key and observe what LED is on ln confirm

fn/fnx tips:
The default in function is not so good? Set your own fnx Function
For example, in new winmode:
fn + 7 = F7,
fn + 8 = F8,
fn + 9 = F9,
fnx + 7 =
fnx + 8 =
fnx + 9 =

Fn function description

(Double-click FN to light FN's white LED, FN function is held, click FN again to escape from holding status).

Define mode

Key	Function
Standard mode	Standard mode, all buttons cannot be user-defined. User can customize your own personality keyboard by the following 4 modes. On-board mode 1/2/3 is strongly recommended.(Note: In the custom mode, except FN key, other keys can be redefined key values, some of the FN + " x " function can be also modified, except the backlight, bluetooth and system control. The FN button cannot be moved, but user can define your own FNX at any key in the custom mode.
FN + W Onboard mode 1 WIN mode	FN + W, onboard mode layer 1, " W" lights white LED, no need to run and connect the driver. The keyboard works in the custom key functions and user can modify the key functions and macro Settings by the driver and these. Settings can be downloaded and saved to the keyboard. The reference setting: WIN mode setting to realize the habitual operation of win users.
FN + E Onboard mode 2 MAC OS mode	FN + E, onboard mode layer 2, " E " lights white LED. The reference Setting keyboard of MAC OS, the "control, option, command" key will be in the original position, user can modify the Settings by the driver, download and save to the keyboard, no need to run and connect the driver when use the Mac's function settings. Press FN + 7& again, back to the standard mode.
Driver mode	Drive mode: Keyboard needs to be run and connected the driver in USB wired mode when realizes key function and light affects, some special function(for example: You may assign a macro of more than 32 bytes to a key in the driver mode while it's unavailable in those onboard mode layer). You must need keep the driver running and the keyboard connect with the driver.
FNX setting Onboard mode 3	FNX setting: If you don't like the FN position and FN combination key function, you can set your own FNX position and FN combination key function, some special function keys, or combination keys, or macro keys, these settings of this mode can be called by the FN key in layer 1& layer 2, all settings in these mode can be modified and saved to the keyboard.

Backlight settings

(Can not modify)

Key	Function
FN +	Light effect pause/play
FN + \|	Backlight ON/OFF
FN + ]}	Backlight mode 1 - 5 (Can modify)
FN + [{	Backlight mode 6- 9
FN + ↓	Backlight brightness -
FN + ↑	Backlight brightness +
FN + ←	Backlight Effect Speed -
FN + →	Backlight Effect Speed +

Bluetooth settings

(Only for bluetooth mode, cannot modify)

Key	Function
FN + Space	Bluetooth ON/OFF switch Link to USB mode or the last BT equipment.
FN + Z	1 Long press: The red & green LED of Z keycap will flash. The 1 bluetooth equipment can be paired. Press: The keyboard will connect the 1 BT equipment or disconnect.
FN + X	2 Long press: The red & green LED of X keycap will flash. The 2 bluetooth equipment can be paired. Press: The keyboard will connect the 2 BT equipment or disconnect.
FN + C	3 Long press: The red & green LED of C keycap will flash. The 3 bluetooth equipment can be paired. Press: The keyboard will connect the 3 BT equipment or disconnect.

System Control

(Cannot modify)

	Long press the (label at the bottom of the Bluetooth dual-mode optical keyboard for 3 seconds to turn on/off keyboard, wired version doesn't have this function.
FN + Tab	Long press FN+Tab 3 seconds to on/off the Bluetooth dual-mode mechanical keyboard, wired version doesn't have this function.
FN + alt	Turn off/on the charging indicator, low voltage alarm, the wired version does not have this function.
FN + control	Keyboard's sleep time setting, white LED on O:never sleep, 1:5 minutes, 2:10 minutes... 9:45 minutes to sleep

Fn function

(Reference Settings, can be modified by driver)

Key	Mac mode function		Win mode function
FN + 1	Screen brightness — for Mac		F1
FN + 2	Screen brightness + for Mac		F2
FN + 3	for Mac		F3
FN + 4	for Mac		F4
FN + 5	One click call Siri for Mac		F5
FN + 6	Screenshot for Mac		F6
FN + 7	Previous		F7
FN + 8	Play/Pause		F8
FN + 9	Next		F9
FN + 0	Mute		F10
FN + -	Volume -		F11
FN + =	Volume +		F12
FN + delete	delete		delete
FN + pgup	home		home
FN + pgdn	end		end
FN + win	Lock/Unlock Win key
FN + insert	fn Lock/Unlock fn koy
FN + Esc	'	FN + Shift + Esc	~
