BUTTONS FUNCTIONS
WINDOWS SHORTCUT
| FN + F1 | My computer |
| FN + F2 | |
| FN + F3 | Search |
| FN + F4 | Home Page |
| FN + F5 | Multimedia Player |
| FN + F6 | Play/Pause |
| FN + F7 | Previous Track |
| FN + F8 | Next Track |
| FN + F9 | Calculator |
| FN + F10 | Mute |
| FN + F11 | Volume - |
| FN + F12 | Volume + |
| FN + I | Insert |
| FN + WIN | Lock Win-key |
| FN + R_CTRL (HOLD 3S) | Menu |
MAC SHORTCUT
| FN + F1 | Screen Brightness - |
| FN + F2 | Screen Brightness + |
| FN + F3 | Task |
| FN + F4 | Control Pad |
| FN + F5 | F5 |
| FN + F6 | F6 |
| FN + F7 | Previous Track |
| FN + F8 | Play / Pause |
| FN + F9 | Next Track |
| FN + F10 | Mute |
| FN + F11 | Volume - |
| FN + F12 | Volume + |
FUNCTION KEY COMBINATIONS
| FN + 1! | Short Press to Switch to BTI; Long Press to Pair Devices |
| FN + 2@ | Short Press to Switch to BT2; Long Press to Pair Devices |
| FN + 3# | Short Press to Switch to BT3 Long Press to Pair Devices |
| FN + 4$ | Short Press to Switch to 2.4G Mode; Long Press to Pair Devices |
| FN + ESC (HOLD 3S) | Reset the Keyboard to the Factory Setting |
| FN + 5% | Wired Mode |
| FN + W | Swap WASD and Arrow keys |
| FN + BACKSPACE | Battery Check |
LIGHT EFFECTS
| FN + HOME | RGB Effects 1-5 |
| FN + PGUP | RGB Effects 6-10 |
| FN + END | RGB Effects 11-15 |
| FN + PGDN | RGB Effects 16-20 |
| FN + \| | Toggle Backlight colors |
| FN + L | Turn on/off Backlights |
| FN + L_CTRL | Toggle Sidelight Effect and Off |
| FN + L_ALT | Toggle Sidelight Colors |
| FN + ↑ | Backlights Brightness - |
| FN + ↓ | Backlights Brightness + |
| FN + ← | Dynamic light direction to left |
| FN + → | Dynamic light direction to right |
| FN + -_ | Backlights Speed- |
| FN + =+ | Backlights Speed + |
| FN + Z | Toggle Sidelight Brightness |
| FN + X | Toggle Sidelight Speed |
CHANGE RGB EFFECTS
Press Fn + Home/PgUp/End/PgDn to switch the RGB effects of your Epomaker Aura75 keyboard.
PAIRING
PAIRING BLUETOOTH
- Hold Fn+l! / 2@ / 3# for 3-5 seconds till the indicators flashes fast in red/green/yellow the keyboard is ready to pair in Bluetooth.
- Turn on your Bluetooth device and find 'Aura75 BT3.0' or 'Aura75 BT5.0-1/2/3', then connect. When the keyboard is connected to the Bluetooth device, the light on the 1!/ 2@ / 3# key stops flashing and the connection is done.
- Press Fn+1! / 2@ / 3# to toggle between the Bluetooth devices 1/2/3.
PAIRING WIRELESS 2.4GHZ
- Press Fn+4$ the indicator flashes in green, the keyboard is under the 2.4G mode;
- Continue to hold Fn+4S for for 3-5 seconds till the 4$ indicator flashes fast, the keyboard is ready to pair;
- Insert the 2.4G dongle to your device, the 4$ key stops flashing and the connection is done.
WIRED MODE
Press Fn+5%, the keyboard goes to the wired mode successfully.
KNOB
Clockwise: Volume -/Backlight Brightness -
Counterclockwise: Volume +/Backlight Brightness +
Press knob: Toggle the knob function between volume or backlight brightness control.
CHECK BATTERY
Hold Fn+Backspace, the keys from 1! to 0) lights up to show the battery percentage; for example, if the keys from 1! to 6^ light up when holding Fn + Backspace, it means that the battery life is currently 60%; if keys of 1!-0) light up, battery life is 100%.
INDICATOR LIGHT
Charging: Red light stays for 2 seconds then off
Charged: Green light stays for 2 seconds then off
Win-lock: When the Win key light up, the key is disabled
SPECS
| KEYS AMOUNT: | 82 Keys + 1 knob |
| STABILIZER TYPE: | Plate-mounted |
| CASE MATERIAL: | ABS Plastic |
| PLATE MATERIAL: | Steel |
| PCB TYPE: | 3/5-pin Hotswap PCB |
| BATTERY CAPACITY: | 3000mAh |
| CONNECTIVITY: | Type-C Wired, 2.4 & Bluetooth Wireless |
| ANTI-GHOST KEY: | NKRO in all modes |
| COMPATIBILITY: | WINDOWS/MAC |
| DIMENSION: | 330 X 145 X 39 mm |
| WEIGHT: | Around 0.7kg |
REPLACING KEYCAPS AND SWITCHES
Before installing switches, be sure the pins are clean and straight.
Push Straight Down
Please be gentle. Be sure the pins are aligned with the slots.
Mechanical Switch
Example of a switch as seen from top after you remove the keycap to prepare for switch removal.
The Switch Puller tool aligns Vertically to the Switch to unclip the plastic securing the switch to the plate.
Included Tools
Remove Switches
- Grab your Switch Removal Tool and align the gripping teeth vertically (on the Y-Axis) at the center of the switch, as shown in the example graphic above.
- Grab the switch with the Switch Puller and apply pressure until the switch releases itself from the plate.
- Using firm but gentle force pull the switch away from the keyboard using a vertical motion.
Install Switches
- Check that all the switch metallic pins are perfectly straight and clean.
- Align the switch vertically to have the Gateron logo facing north. The pins should align themselves to the keyboard PBC.
- Press the switch down until you hear a click. This means your switch clips have attached themselves to the keyboard plate.
- Inspect the switch to ensure it's properly attached to your keyboard, and test it.
Note: If the key doesn't work its possible you may have bent one of the switches while installing it. Pull the switch out and repeat the process.
Pins may be damaged beyond repair and need replacement if this process is not done correctly. Never apply excessive force when replacing keycaps or switches. If you cannot remove or install keycaps or switches please contact customer service as soon as possible to avoid damage to the keyboard due to operating errors.
TECHNICAL ASSISTANCE
For technical assistance, please email to support@epomaker.com with your purchase order number and a detailed description of your issue.
We normally respond to enquiries within 24 hours. If you purchased your keyboard from a distributor or not from any official store of Epomaker, please contact them directly for any additional help.
COMMUNITY FORUMS
Join our community and learn together with other keyboard enthusiasts.
https://discord.gg/2q3Z7C2
https://www.reddit.com/r/Epomaker/
Manufacturer: Shenzhen Changyun Technology Co., Ltd.
Address: Seventh Floor, Kai Daer Building, No.168 Tongsha Road, Xili Street, Nanshan District, Shenzhen, Guangdong, CN
Email: support@epomaker.com
Web: www.epomaker.com
APEX CE SPECIALISTS LIMITED
Unit 3d North Point House, North Point Business Park, New Mallow Road Cork, T23 AT2P, Ireland
Contact: Wells
Tel: +353212066339
APEX CE SPECIALISTS LIMITED
89 Princess Street, Mancheste, M1 4HT, UK
Contact: Wells
E-mail: info@apex-ce.com
