Mini-ITX SBC Supports Intel® Celeron® J6412 on-board SoC with
HDMI, DP, iDPM, Dual 2.5GbE LAN, M.2, PCIe x4 Slot, SATA 6Gb/s,
Quick Installation Guide
Package List
KINO-EHL2-J6412 package includes the following items:
1 x KINO-EHL2-J6412 single board computer
1 x SATA cable
1 x I/O shielding
1 x QIG
COM, USB 3.2 Gen 2, 12V~28V and RoHS
KINO-EHL2-J6412
Version 1.0
July 26, 2023
©2023 Copyright by IEI Integration Corp.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology KINO-EHL2-J6412
Summary of Contents for IEI Technology KINO-EHL2-J6412
- Page 1 COM, USB 3.2 Gen 2, 12V~28V and RoHS KINO-EHL2-J6412 Quick Installation Guide Version 1.0 July 26, 2023 Package List KINO-EHL2-J6412 package includes the following items: 1 x KINO-EHL2-J6412 single board computer 1 x SATA cable 1 x I/O shielding ...
-
Page 2: Specifications
Specifications CPU: Intel® Celeron® J6412 on-board SoC (up to 2.6GHz, quad-core, 1.5M cache, TDP=10W) Memory: 1 x 260-pin 3200 MHz DDR4 SO-DIMM (system max. 32GB) BIOS: AMI UEFI BIOS Dual BIOS for boot & recovery Graphics Engine: Intel®... - Page 3 Audio: Realtek ALC888S HD Audio codec 3 x Audio jack (Line-in, Line-out, Mic-in) 1 x Analog audio (2x5 pin, p=2.54) Front Panel: 1 x Front panel (2x7 pin, p=2.54; power LED, HDD LED, power button, reset button) Expansions: 1 x M.2 2230 A key (PCIe x1 / USB 2.0 signal) 1 x M.2 3052/3042/2242/2280 B key with SIM slot...
-
Page 4: Ordering Information
VGA converter board (for IEI iDPM slot) IEI Resource Download Center All the drivers and utility for the https://download.ieiworld.com KINO-EHL2-J6412 are available on IEI Resource Download Center. Type KINO-EHL2-J6412 and press Enter to find all the relevant software, utilities, and documentation. -
Page 5: Jumpers Setting And Connectors
Jumpers Setting and Connectors LABEL FUNCTION J_CMOS2 Clear CMOS button J_ATX_AT1 AT/ATX power mode setting switch J_BIOS1_1 BIOS1/BIOS2 select jumper J_DNX1 DNX mode setting jumper J_FLASH1 Flash descriptor override setting jumper FRONT-PANEL1 Audio connector ATX power connector BAT1 Battery connector Buzzer connector CHASSIS1 Chassis intrusion connector... - Page 6 TPM1 TPM module connector JUSB3, JUSB4 Internal USB 2.0 connectors M2_A_KEY M.2 A-key slot M2_B_KEY M.2 B-key slot PCIEX4_1 PCIe x4 slot (x1 signal) SIM slot (solder side) IDPM1 IEI iDPM slot External DC input jack AUDIO_CN1 External audio jacks External 2.5GbE and USB 3.2 Gen 2 combo LAN1_USB1 connector...
- Page 7 J_BIOS1_1: BIOS1/BIOS2 Select Jumper PIN NO. DESCRIPTION Short 1 - 2 BIOS1 (default) Short 2 - 3 BIOS2 J_DNX1: DNX Mode Setting Jumper PIN NO. DESCRIPTION Open Normal (default) Short Enable DNX Boot J_FLASH1: Flash Descriptor Override Setting Jumper PIN NO. DESCRIPTION Short 1 - 2 Disable (default)
- Page 8 BZ1: Buzzer Connector DESCRIPTION DESCRIPTION PC_BEEP CHASSIS1: Chassis Intrusion Connector DESCRIPTION DESCRIPTION -CASEOPEN DIO1: Digital Input/Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DOUT5 DOUT4 DOUT3 DOUT2 DOUT1 DOUT0 DIN5 DIN4 DIN3 DIN2 DIN1 DIN0 CPU_FAN1: Fan Connector PIN NO. DESCRIPTION PIN NO.
- Page 9 F_PANEL1: Front Panel Connector DESCRIPTION DESCRIPTION PWR_LED+ SPKR+ SPKR PWR_LED- PWR_BTN+ SPKR- PWR_BTN- HDD_LED+ Reset+ RESET HDD_LED- Reset- COM3, COM4: RS-232 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION COM5, COM6: RS-232/422/485 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION...
- Page 10 S_ATA1, S_ATA2: SATA 6Gb/s Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX‐ SATA_TX+ SATA RX+ SATA_TX‐ SATA_PWR1, SATA_PWR2: SATA Power Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION I2C1: I C Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION I2C_CLK I2C_DATA SMB1: SMBus Connector PIN NO.
- Page 11 JEC1: EC Debug Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EDICLK EDICS EDIDI EDIDO TPM1: TPM Module Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION TPM_SPI_CS0_N DEDI_PROG_RST_N TPM_SPI_CS1_N +V3P3A SPI_CLK_TPM SPI_TPM_DQ2 TPM_SPI_DQ3 TPM_SPI_MISO SPI_TPM_HOLD_R_N TPM_SPI_MOSI SPI_TPM_CS2_R TPM_WP# SPI_TPM_INT_N +V3.3A_1.8A_SPI_CON PLT_RST_N +V3.3A_1.8A_SPI_CON JUSB3, JUSB4: Internal USB 2.0 Connectors PIN NO.
- Page 12 Module Key Module Key Module Key PCIE_TX4+ PCIE_TX4- PCIE_RX4+ PCIE_RX4- CLK_M2_A+ CLK_M2_A- BTWIFI_SUS_CLK WLAN_PERST# +V3.3A_WLAN +V3.3A_WLAN +V3.3A_WLAN PEWAKE# +V3.3A +V3.3A...
- Page 13 M2_B_KEY: M.2 B-key Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION WWAN_CONFIG3 +3.3V_WWAN +3.3V_WWAN WWAN_FCP_OFF USB_D+ WWAN_DISABLE USB_D- Module Key Module Key Module Key Module Key Module Key Module Key Module Key PSE_I2S1_SCLK Module Key WWAN_CONFIG0 PSE_I2S1_TXD PCIE_WAKE# PSE_I2S1_RXD SAR_DPR_WWAN GNSS_DISABLE_N PCIE_RXN7 WWAN_UIM_RST PCIE_RXP7...
- Page 14 WWAN_RST WWAN_SUSCLK DET_OS-PCIE/ +3.3V GND-SATA +3.3V +3.3V WWAN_CONFIG2 CN4: SIM Card Slot (on solder side) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SIM_VCC SIM_RST SIM_CLOCK SIM_DATA LAN1_USB1 External USB 3.2 Gen 2 Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX-...
- Page 15 LAN2_USB2 External USB 2.0 Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ 2.5GbE RJ-45 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_MDI0P LAN1_MDI2P LAN1_MDI0N LAN1_MDI2N LAN1_MDI1P LAN1_MDI3P LAN1_MDI1N LAN1_MDI3N COM1: External Dual RS-232 Connector PIN NO. DESCRIPTION PIN NO.
- Page 16 Board Layout: Jumper and Connector Locations (Unit: mm)
