Chapter 2 Backup procedures
5 Change Current User Password
6 Change System Passphrase
7 Create SD Backup
8 Restore SD Backup
9 Reboot
L Logout
Enter Choice : 7
Step 4 To start the manual backup , enter option no 7 Create SD Backup.
The shell prompts you to confirm this action.
Do you want to start backup now?
Step 5 To start the backup, type y.
The backup procedure starts and, when finished, displays "Backup Successful."
Backup Started,
Please wait for backup to complete...
Backup Successful

Backing up a station using Platform Administration

The Platform Administration view performs a complete backup of the connected controller, saved as a .dist
file on your PC. The backup dist contains the entire station folder, the specific NRE config used by the platform,
license(s), certificate(s), pointers to the appropriate NRE core, Java VM, modules, OS and the TCP/IP configu-
ration of the host.
Prerequisites: You are working in EC-Net 4 Pro and are connected to the Supervisor or remote controller.
Step 1 Expand the Platform node in the Nav tree or double-click Platform.
The contents of the Nav Container View opens in the tree or in the main view.
Step 2 Double-click the
The Platform Administration view opens.
Step 3 Click the Backup button.
If the station is running, EC-Net 4 Pro asks you to confirm that you intend to connect to the station to
back it up.
You can perform a backup with a station running on the target host, or when no station is running.
Step 4 If you choose to stop the station, click No, double-click the Application Director, select the station,
click Stop, then go back and click Platform Administration→Backup.
If no station is running on the controller, the platform daemon performs its own offline backup or you
may log in as a station user.
If the station is running, EC-Net 4 Pro uses the station's BackupService to perform an online backup.
In either case, the File Chooser window opens.
10
[y/N]? y
Platform Administration.
EC-BOS-9 Backup and Restore Guide
