4. ESP32-GATEWAY schematics and dimensions

ESP32-GATEWAY was designed with KiCAD (free and open-source CAD tool). ESP32-GATEWAY
schematics and sources can be found at GitHub here:
https://github.com/OLIMEX/ESP32-GATEWAY/tree/master/HARDWARE
There are also PDF exports if you don't want to install KiCAD.
Board dimensions can be found here:
https://www.olimex.com/Products/IoT/ESP32/ESP32-GATEWAY/resources/ESP32-GATEWAY-

5. ESP32-GATEWAY pinout description:

The board's pinout can be seen here:
https://www.olimex.com/Products/IoT/ESP32/ESP32-GATEWAY/resources/ESP32-GATEWAY-
GPIOs-Rev.F-up.pdf
The ESP32 chip has very good multiplexer so you can set the free GPIO pins for alternative functions
via software means.
The SD card interface is in 1-bit eMMC mode.
By default GPIO17 is not lead to the CON1 header to reduce noise on the Ethernet clock line. You can
solder together the pads of jumper GPIO17_E1 if you wish to lead it to the CON1 header.
