Summary of Contents for OLIMEX ESP32-P4-DevKit
- Page 1 ESP32-P4-DevKit User Manual olimex.com Rev.1.0 December 2024...
-
Page 2: Table Of Contents
Table of Contents What is ESP32-P4-DevKit.........................3 Order codes for ESP32-P4-DevKit and accessories:................4 HARDWARE.............................5 ESP32-P4-DevKit layout:........................6 ESP32-P4-DevKit POE connector:.......................8 ESP32-P4-DevKit CSI connector:......................9 ESP32-P4-DevKit MIPI connector:....................10 ESP32-P4-DevKit UEXT connector:....................11 ESP32-P4-DevKit EXT1 and EXT2 connectors:................12 UEXT connector:..........................13 ESP32-P4-DevKit schematics:......................14 SOFTWARE:............................15 Revision History............................16... -
Page 3: What Is Esp32-P4-Devkit
• All GPIOs available on two 0.1″ 2.54 mm 20 pin DIL headers • four mounting holes 3.3mm diameter • Dimension 72x30mm ESP32-P4-DevKit is Open Source Hardware, all CAD files and firmware and available, so people can study and modify. -
Page 4: Order Codes For Esp32-P4-Devkit And Accessories
Order codes for ESP32-P4-DevKit and accessories: ESP32-P4-DevKit ESP32-P4 development board with Ethernet UEXT-PQ pUEXT to UEXT adapter pUEXT-CABLE 1mm step pUEXT cable with 50, 100 and 200mm lenght POEv3 PoE add-on board allowing board to be powered by Ethernet POE... -
Page 5: Hardware
HARDWARE... -
Page 6: Esp32-P4-Devkit Layout
ESP32-P4-DevKit layout: Ethernet MIPI-CSI BOOT MIPI-DSI button USB-C JTAG RESET buttoon Power LED UEXT connector... - Page 7 GPIO connector 2 GPIO connector 1 SPI flash Micro SD card...
-
Page 8: Esp32-P4-Devkit Poe Connector
ESP32-P4-DevKit POE connector: PW+ and PW- come from the LAN transformer. POEv3 external board have POE negotiator and DCDC step down circuit which produce 5V/3A which is feed back to the ESP32-P4-DevKit. -
Page 9: Esp32-P4-Devkit Csi Connector
ESP32-P4-DevKit CSI connector: MIPI-CSI connector is with standard Raspberry Pi 1,2,3 and 4 camera FPC layout. So you can connect standard Rpi camera to it. -
Page 10: Esp32-P4-Devkit Mipi Connector
ESP32-P4-DevKit MIPI connector: MIPI-DSI is Raspberry Pi DSI connector layout:... -
Page 11: Esp32-P4-Devkit Uext Connector
ESP32-P4-DevKit UEXT connector: ESP32-P4-DevKit is very compact board so standard UEXT connector is impossible to be used, this is why pUEXT connector is used: pUEXT is 1.0 mm step connector: UEXT-PQ is adapter which allow pUEXT connector to be wired to standard UEXT. -
Page 12: Esp32-P4-Devkit Ext1 And Ext2 Connectors
ESP32-P4-DevKit EXT1 and EXT2 connectors:... -
Page 13: Uext Connector
UEXT connector can be in different shapes. The original UEXT connector is 0.1” 2.54mm step boxed plastic connector. All signals are with 3.3V levels. Olimex has developed number of MODULES with this connector. There are temperature, humidity, pressure, magnetic field, light sensors. Modules with LCDs, LED matrix, Relays, Bluetooth, Zigbee,... -
Page 14: Esp32-P4-Devkit Schematics
ESP32-P4-DevKit schematics: ESP32-P4-DevKit latest schematic is on GitHub... -
Page 15: Software
SOFTWARE: ESP32-P4-DevKit can be programmed with ESP-IDF versipon 5.4 or later. You can learn how to install it here. -
Page 16: Revision History
Revision History Revision 1.0 December 2024...
