Num'axes PROTECTION PIE1076 User Manual page 22

Operating time
Photo or video
Photo resolution
Video resolution
Multi-shot
Video length
Audio recording
PIR sensitivity
OFF | ON
Each day, the device can operate 24 hours a day
(parameter set to OFF) or only during the time slot
defined by the user (parameter set to ON).
Select "ON" then press OK to set the start time and end
time of the desired working period.
Example: with the timer set to Start 15 : 00 – End 18 : 00;
each day, the camera will work only between 15h00
(03:00 PM) and 18h00 (06:00 PM).
Photo | Video | Photo + Video
− Photo: the camera shoots only photos.
− Video: the camera shoots only videos.
− Photo + Video: upon the same trigger event, the
camera shoots photo(s) first then a video.
2 MP | 4 MP | 8 MP | 16 MP | 20 MP | 24 MP | 32 MP |
36 MP | 42 MP | 48 MP
Higher resolution produces better quality photos but
creates larger files that take up more of the memory card
capacity (fills up faster).
720P | 1080P | 2.7K | 4K
Higher resolution produces better quality videos but
creates larger files that take up more of the memory card
capacity (fills up faster).
1 photo | 2 photos | 3 photos | 4 photos | 5 photos
Programmable from 1 up to 5 photos per trigger
Default video length: 10 seconds
Programmable from 05 seconds up to 10 minutes
ON | OFF
Allows you to activate or deactivate the audio recording
on the videos.
Low | Medium | High
With the PIR sensitivity set to High, the PIR sensor:
‒ is more sensitive to movements by smaller subjects;
‒ offers longer detection distance;
‒ can more easily detect a difference between body
heat and outdoor temperature;
‒ can more easily trigger the camera.
Guide PIE1076 – Septembre 2024 – ind. B - 22/88
