Microtek ScanMaker 3700 Supplementary Manual page 8

Note: If the Scanner lamp Assembly Connector is too difficult to remove manually
use a set of needle nose pliers to remove it. (See illustration below.)
4. Once the florescent lamp connector has been disconnected you need to remove the
lamp assembly. Flip the scanner carriage lamp over to locate the Philip screws that hold
lamp assembly in place. Remove the two Philip head screws. (See illustration below.)
Scanner Lamp Assembly is
held by two phillip screws.
8
Needle Nose
pliers pulling
the Scanner
Lamp
assembly
connector off
the circuit
board.
