7. TECHNICAL SPECIFICATIONS

7.1.

TECHNICAL CHARACTERISTICS

Accuracy indicated as [%reading + (number of digits*resolution)] at 23°C±5°C, <80%RH
AC TRMS current (Autorange)
Range
30.00A
300.0A
3000A
(*) Accuracy referred to a conductor placed in the middle of the jaws, absence of electric or magnetic fields and reference
temperature

7.1.1. Reference standards

Safety:
EMC:
Insulation:
Pollution level:
Measurement category:
Max operating altitude:

7.1.2. General characteristics

Mechanical characteristics
Size (L x W x H):
Weight (batteries included):
Length of flexible jaws:
Max. cable diameter for clamp:
Mechanical protection:
Power supply
Battery type:
Low battery indication:
Battery duration:
Auto Power OFF:
Display
Characteristics:
Out-of-range indication:

7.2. ENVIRONMENT

7.2.1. Environmental conditions for use

Reference temperature:
Operating temperature:
Operating humidity:
Storage temperature:
Storage humidity:
This instrument satisfies the requirements of Low Voltage Directive 2014/35/EU
This instrument satisfies the requirements of European Directive 2011/65/EU (RoHS)

7.3. ACCESSORIES

7.3.1. Standard accessories

• Carrying bag
Resolution
0.01A
0.1A
1A
(LVD) and of EMC Directive 2014/30/EU
and 2012/19/EU (WEEE)
• Batteries (not inserted)
EN - 9
Bandwidth
50Hz  400Hz
IEC/EN61010-1, IEC/EN61010-2-032
IEC/EN61326-1
double insulation
2
CAT IV 600V, CAT III 1000V to earth
2000m (6562ft)
280 x 125 x 25mm (11 x 5 x 1in)
190g (7ounces)
254mm (10in)
110mm (4in)
IP40
2x1.5V batteries type AAA LR03
" "
symbol on the display
ca.15g(backlight OFF), ca.10g (backlight ON)
after 15 minutes' idling
4 LCD, 3000 dots plus decimal point and
backlight
" "
symbol OL on the display
23°C ± 5°C (73°F ± 41°F)
5°C ÷ 40°C (41°F ÷ 104°F)
<80%RH
-20°C ÷ 60°C (-4°F ÷ 140°F)
<80%RH
• User manual
F3000
Accuracy (*)
(3.0%rdg + 8digits)
(3.0%rdg + 5digits)
