Nordson 64B Customer Product Manual

15:1 aluminum

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

64B Pump

15:1 Aluminum

Customer Product Manual

Document Number

104321-08

– English –

Issued 10/24

For parts and technical support, call the Industrial Coating

Solutions Customer Support Center at (800) 433-9319 or

contact your local Nordson representative.

This document is subject to change without notice.

Check

http://emanuals.nordson.com

for the latest version.

NORDSON CORPORATION • 100 NORDSON DRIVE, AMHERST, OHIO 44001• USA

Table of Contents

Troubleshooting

Need help?

Do you have a question about the 64B and is the answer not in the manual?

Questions and answers

Summary of Contents for Nordson 64B

Page 1 For parts and technical support, call the Industrial Coating Solutions Customer Support Center at (800) 433-9319 or contact your local Nordson representative. This document is subject to change without notice. Check http://emanuals.nordson.com for the latest version. NORDSON CORPORATION • 100 NORDSON DRIVE, AMHERST, OHIO 44001• USA...
Page 2 Nordson Corporation welcomes requests for information, comments, and This is a Nordson Corporation publication which is protected by copyright. inquiries about its products. General information about Nordson can be found on Original copyright date 1982. No part of this document may be photocopied,...
Page 3: Table Of Contents
Table of Contents Table of Contents Quick Reference − 64B 15:1 Aluminum Pump ................Introduction ............................ Specifications ..........................Dimensions and Weight ........................ Operating Sound Levels ....................... Air and Fluid Specifications ......................Fluid Hoses ........................... Part Number Quick Reference ....................... Pump and Subassemblies ......................
Page 4 Disassembly ..........................Cleaning, Inspection, and Parts Replacement................Ball Check Test ..........................Packing Gland Replacement ......................Type-G Packing Rebuild or Conversion ..................Assembly ............................Connecting the Air Motor and Hydraulic Section ................Returning the Pump to Service..................... 104321-08 ©2024 Nordson Corporation...
Page 5 Type G Packing Gland Service Kit ..................... 10-6 Options ............................10-7 Siphon Accessory Group ......................10-7 Siphon Accessory Group ......................10-8 Drawings ............................11-1 64B Air Motor Parts ........................11-2 64B Air Valve Parts ........................11-3 64B 15:1 Aluminum Hydraulic Section Parts ................11-4 104321-08 ©2024 Nordson Corporation...
Page 6: Change Record
Change Record Change Record Revision Date Change 10/24 Updating Parts List PNs, Drawings PNs, and Manufacturer Address 104321-08 ©2024 Nordson Corporation...
Page 7: Quick Reference − 64B 15:1 Aluminum Pump
Safety Section 1 Quick Reference − 64B 15:1 Aluminum Pump Introduction Use this section for quick reference for the following information on the 64B 15:1 Aluminum pump: • specifications • service kits and packing glands • recommended spare parts • adhesives, sealants and lubricants used for service •...
Page 8: Air And Fluid Specifications
Use high pressure airless hose with an inside diameter (ID) of: 5, 6, or 10 mm (3/16, 1/4, or 3/8 in.). WARNING: Use Nordson or equivalent nylon or PTFE fluid hoses, with electrical continuity between fittings. Hoses must be capable of withstanding the maximum output pressure of the pump.
Page 9: Packing Glands And Kits
Safety Packing Glands and Kits 64B pumps are shipped with Type F packings, which are suitable for most finishing applications. Refer to the Pump Packing and Solvent Chamber Fluid Guide included with this manual for packing and solvent chamber fluid applications. Contact your Nordson representative for additional information.
Page 10: Adhesives, Sealants, And Lubricants
Refer to Air Motor and Air Valve Parts for the kit parts list. Kit contains siphon hose, rod, and strainer, plus fittings for ACCESSORY GROUP, siphon, 64B, 15:1, 498552 both siphon and high-pressure outlet ports. Refer to Air Motor 30:1, standard and Air Valve Parts for the kit parts list.
Page 11: Safety
Intended Use Use of Nordson equipment in ways other than those described in the documentation supplied with the equipment may result in injury to persons or damage to property. Some examples of unintended use of equipment include: •...
Page 12: Personal Safety
• Make sure the spray area is adequately ventilated. To prevent injury, be aware of less- obvious dangers in the workplace that often cannot be completely eliminated, such as hot surfaces, sharp edges, energized electrical circuits, and moving parts that cannot be enclosed or otherwise guarded for practical reasons. 104321-08 © 2024 Nordson Corporation...
Page 14: Fire Safety
Chlorine “Chloro-” Bromine “Bromo-” Iodine “Iodo-” Check your material SDS or contact your material supplier for more information. If you must use halogenated hydrocarbon solvents, contact your Nordson representative for information about compatible Nordson components. 104321-08 © 2024 Nordson Corporation...
Page 15: Action In The Event Of A Malfunction
• Disconnect and lock out system electrical power. Close hydraulic and pneumatic shutoff valves and relieve pressures. • Identify the reason for the malfunction and correct it before restarting the system. Disposal Dispose of equipment and materials used in operation and servicing according to local codes. 104321-08 © 2024 Nordson Corporation...
Page 16: Safety Labels
Do not use halogenated hydrocarbon solvents in this pumps system, it contains aluminum parts and may explode. only) Cleaning agents, coatings, paints or adhesives may contain halogenated hydrocarbon solvents. Don’t take chances, consult your material supplier to be sure system. 104321-08 © 2024 Nordson Corporation...
Page 17 Safety 3 (Aluminum Pumps Only) Figure 2-1 Safety Labels Figure 2-2 Atex/Ex Labels 104321-08 © 2024 Nordson Corporation...
Page 19: Description
The information in this section is common for both the aluminum and stainless steel versions of the 64B pump. All illustrations in this manual show the aluminum version of the pump. The stainless steel versions look different, but have the same basic components and operate the same.
Page 20: Packings
Optional packings are available for use with other coating materials and solvents. Refer to the Packing Gland Material Guide and Packing Gland Selection Chart in Quick Reference − 64B 15:1 Aluminum Pump, to select and order the correct packing glands for your coating material.
Page 21 3. Air valve spool 9. Lower cylinder head 15. Siphon ball check 4. Mufflers 10. Hydraulic plunger 16. Hydraulic section 5. Upper cylinder head 11. Solvent chamber 17. Air motor 6. Air motion piston 12. Upper packings 104321-08 © 2024 Nordson Corporation...
Page 22: Pressure Stroke
Options Refer to Options in Quick Reference − 64B 15:1 Aluminum Pump, for information on the following options: • Air Motor Accessory kit, consisting of an air filter, regulator, gauge, and lubricator, along with fittings, mounting brackets, fasteners, and lubricating oil.
Page 23: Installation
NOTE: The information in this section is common for both the aluminum and stainless steel versions of the 64B Pump. All illustrations in this manual show the aluminum version of the pump. Suitable for installation in Zone 1, Zone 2, or normal usage areas.
Page 24: Compressed Air Connection
Air Inlet Port: 3/8 in. NPT. Use a flexible air hose to supply air to the pump and act as a vibration damper. Minimum hose ID is 10-mm (3/8 in.). See Figure 4-1 for optional Air Motor Accessory kit installation, and Quick Reference − 64B 15:1 Aluminum Pump for the kit part number.
Page 25: Siphon And High Pressure Fluid Connections
Failure to use grounded hoses could result in a fire or explosion. Refer to Quick Reference − 64B 15:1 Aluminum Pump for high pressure hose recommendations, and optional siphon accessory and circulation kit part numbers.
Page 26: Installation Guidelines
• Ground all system components, waste containers, and coating supplies. The only exception to this rule is electrostatic systems where the coating supply is charged at the supply rather than at the spray device. 104321-08 © 2024 Nordson Corporation...
Page 27 7. Lubricator 12. High-pressure fluid hoses 3. Drain valve 8. Air hose 13. Fluid filter 4. Air shut off valve (self-relieving) 9. Coating supply 14. Spray gun 5. Air filter 10. Siphon rod and strainer 104321-08 © 2024 Nordson Corporation...
Page 28 4. Air shut off valve (self-relieving) 11. Siphon hose 18. Drain hose and rod 5. Air filter 12. High-pressure fluid hoses 19. Waste container 6. Regulator and gauge 13. Fluid heater 7. Lubricator 14. Fluid filter 104321-08 © 2024 Nordson Corporation...
Page 29: Operation And Maintenance
The information in this section is common for both the aluminum and stainless steel versions of the 64B pump. All illustrations in this manual show the aluminum version of the pump. The stainless steel versions look different, but operate the same.
Page 30: System Check
Frequency Flush the pump or system • before putting it into service for the first time • before and after rebuilding the hydraulic section • when changing coating material • before a long term shutdown 104321-08 © 2024 Nordson Corporation...
Page 31: Cleaning Solution For Flushing
9. Stop the pump, relieve the system pressure, and install the spray device nozzles. 10. Start the pump and trigger the spray devices to purge any remaining air in the system. When the nozzles stop spitting, you can resume production. 104321-08 © 2024 Nordson Corporation...
Page 32 8. Spray device 14. High-pressure hose 3. Air pressure regulator and gauge 9. Fluid heater 4. Lubricator 10. Circulation valve 5. Coating or cleaning solution supply 11. Drain valve 6. Siphon rod and strainer 12. Drain rod 104321-08 © 2024 Nordson Corporation...
Page 33: Routine Startup
The more the circulation valve is opened, the more potential there is for fan pattern collapse or “wink” at the spray device when the pump changes direction or shifts. Open the circulation valve just enough to maintain the required fluid temperature and agitation in the circulation loop. 104321-08 © 2024 Nordson Corporation...
Page 34: Routine Shutdown
If the system will be shut down for more than a few days, flush it and leave it filled with cleaning solution. 4. Perform daily maintenance as described in Operation and Maintenance in this section. 104321-08 © 2024 Nordson Corporation...
Page 35: Maintenance
A small amount of leakage is normal. If the solvent filler cup fills quickly and overflows, the packings are worn and need to be replaced. Both upper and lower packings should be replaced at the same time. 104321-08 © 2024 Nordson Corporation...
Page 36: Weekly
2. Ball stem Every Four to Six Months Rebuild the air valve. As Needed Flush the pump and system with a compatible cleaning solution. Change the solvent chamber fluid regularly. Clean the exterior of the pump. 104321-08 © 2024 Nordson Corporation...
Page 37: Troubleshooting
This section contains troubleshooting procedures. These procedures cover only the most common problems that you may encounter. If you cannot solve the problem with the information given here, contact your local Nordson representative for help. Problem Page...
Page 38: Troubleshooting
Lower heater thermostat setting. triggered Worn or clogged ball Flush the pump and system with a compatible cleaning solution. check valve If the problem continues, rebuild the ball check valves. Worn packings Replace the packings. Continued... 104321-08 © 2024 Nordson Corporation...
Page 39: Pump Operates But Flow Is Restricted, Or Pump Surges
Use a correctly sized siphon hose. Check the strainer screen. If hose ID too small, or the strainer screen is clogged with pigment, use a coarser mesh strainer screen too fine screen or a strainer without a screen. Contact your Nordson for coating material representative for advice. Coating material supply Fill the supply container.
Page 40: Preventing Air Valve Freezing
• Install an air dryer to remove moisture from the air supply. • Install larger mufflers. • Remove the mufflers and install plumbing to exhaust the air to the outside of the building. 104321-08 © 2024 Nordson Corporation...
Page 41: Air Valve And Air Motor Repair
• small and large adjustable wrenches • English hex wrench set • flat-bladed screwdrivers • Molybdenum disulfide grease • O-ring lubricant (Parker O-Lube or equivalent) • Replacement parts or kits (refer to Air Motor and Air Valve Parts) 104321-08 © 2024 Nordson Corporation...
Page 42: Air Valve Removal
65. Screws (4) 14. Elbow 62. Screws (3) 66. Muffler covers (2) 31. Air valve 63. Muffler boxes (2) 67. Screws (6) 32. Screws (4) 64. Lock washers (4) A. Nipple (Air motor accessory group) 104321-08 © 2024 Nordson Corporation...
Page 43: Air Valve Disassembly
32. Screws (4) 41. Valve body 48. O-ring 33. Lock washers (4) 45. End plate washers (2) 49. Gaskets (2) 34. Snapper bracket 46. Screws (4) 51. Left-hand seal retainer 35. Gasket 47. Right-hand seal retainer 104321-08 © 2024 Nordson Corporation...
Page 44 Figure 7-3 Air Valve Repair (2 of 2) 36. Arm 40. O-rings (2) 43. O-rings (2) 37. Screws (3) 41. Valve body 44. Poppets (2) 38. End brushing 42. Poppet guide 50. Crankshaft 39. O-ring 104321-08 © 2024 Nordson Corporation...
Page 45: Snapper Rebuild
Tighten the screw and nut securely. Apply molybdenum disulfide grease before installing. Figure 7-4 Snapper Repair 34. Bracket 55. Screw 58. Spacer 52. Ball Stem 56. Washer 59. Lock washer 53. Spring 57. Snapper 60. Nut 54. Fork 104321-08 © 2024 Nordson Corporation...
Page 46: Air Valve Assembly
2. Cover (61) on air motor. 3. PTFE tape on nipple (A) threads, then screw nipple into elbow fitting. 4. Muffler boxes (63) on air valve seal retainers. 5. Muffler covers (66) on muffler boxes. 104321-08 © 2024 Nordson Corporation...
Page 47: Air Motor Repair
• container for solvent chamber fluid • O-ring lubricant (Parker O-Lube or equivalent) (Nordson part 900223) • Loctite 242 Removable thread adhesive or equivalent (Nordson part 900464) • Replacement parts or kits (refer to Air Motor and Air Valve Parts) Preparation 1.
Page 48: Separating The Air Motor And Hydraulic Section
6. Cylinder from lower cylinder head. 7. Piston assembly (A) from lower cylinder head. 8. Retaining ring (24), seal (25), and O-ring (26) from lower cylinder head. 9. Square O-ring (12) from lower cylinder head. 104321-08 © 2024 Nordson Corporation...
Page 49 28. Connecting tube 4. Spool support 12. Square O-rings (2) 29. Lower cylinder head 5. Spool carrier guide 15. Cylinder 20. Tie rods (4) 6. U-cup 24. Retainer ring A. Piston assembly 7. Guard 25. Seal 104321-08 © 2024 Nordson Corporation...
Page 50: Piston Repair
5. Remove the special nut, upper jam nut, and washer (18) from the screw. Figure 7-7 Piston Assembly Repair 4. Spool support 20. Lower jam nut 16. Special nut 21. Screw 17. Upper jam nut 22. Connecting rod 18. Washer 23. O-ring 19. Piston 104321-08 © 2024 Nordson Corporation...
Page 51: Piston Assembly
9. Guard (7), lock washers (9), and nuts (8) on tie rods. NOTE: Tighten the nuts in a criss-cross pattern, evenly and securely. 10. Perform the steps in “Air Valve Removal” on page 7-2 in reverse to install the air valve, cover, and mufflers. 104321-08 © 2024 Nordson Corporation...
Page 52: Connecting The Air Motor And Hydraulic Section
2. Connect the pump ground, air supply, siphon and high-pressure fluid hoses, and circulation valve, if used. Refer to Installation. 3. Fill the solvent chamber with the appropriate solvent chamber fluid. Refer to Operation and Maintenance. 4. Refer to Routine Startup in Operation and Maintenance. 104321-08 © 2024 Nordson Corporation...
Page 53: Hydraulic Section Repair
• large, clean work surface resistant to solvents • container for solvent chamber fluid • Parker O-Lube or equivalent (Nordson part 900223) • Loctite 242 Removable thread adhesive or equivalent (Nordson part 900464) • Parts and kits to replace damaged components. Refer to Hydraulic Section Parts). 104321-08...
Page 54: Preparation
3. Use two wrenches to unscrew the connecting rod (A) from the plunger (10). Apply Loctite 242 Removable threads adhesive to last few threads before installing. Figure 8-1 Separating the Air Motor and Hydraulic Section 10. Plunger 29. Lock washers (4) 28. Screws (4) A. Connecting rod 104321-08 © 2024 Nordson Corporation...
Page 55: Disassembly
Ball Check service kit. Figure 8-2 Hydraulic Section Disassembly 1. Solvent Chamber 20. Siphon housing 24. O-ring 2. Housing retainer 21. Guide 25. Siphon ball seat 3. Lock washers (4) 23. Ball 26. Pressure housing 4. Screws (4) 104321-08 © 2024 Nordson Corporation...
Page 56 13. O-ring 19. O-ring 7. Back-up ring 14. Pressure ball seat 19A. Back-up ring (30:1 only) 8. O-ring 15. Spacer 20. Siphon housing 10. Plunger 16. Lower packing gland 26. Pressure housing 11. Cage 17. O-ring 104321-08 © 2024 Nordson Corporation...
Page 57: Cleaning, Inspection, And Parts Replacement
• Install the U-cups with the lips facing toward the pressurized area of the pump. • Install the retaining rings (5D, 16D) with the sharp edge of the rings away from the spacers (5C, 16C). 104321-08 © 2024 Nordson Corporation...
Page 58: Assembly
Ball (12) on seat, then cage (11) over ball. If cage fits loosely on seat, bend cage legs in slightly. c. Seat/ball/cage assembly into plunger. 6. Plunger through lower packing gland: a. Lubricate plunger with thin film of O-ring grease. b. Drive plunger through lower packing gland with rubber mallet. 104321-08 © 2024 Nordson Corporation...
Page 59: Connecting The Air Motor And Hydraulic Section
Install the circulation kit, if used, and connect the siphon and high-pressure fluid hoses. Connect the air supply hose to the air motor. Refer to Installation, for connections and circulation valve installation. Flush the pump with a compatible cleaning solution and resume production. 104321-08 © 2024 Nordson Corporation...
Page 61: Air Motor And Air Valve Parts
A dash (—) is used when the part number applies to all parts in the illustration. The number in the Part column is the Nordson Corporation part number. A series of dashes in this column (- - - - - -) means the part cannot be ordered separately.
Page 62: Air Motor Parts
Air Motor Parts See Figure 9-1. Item Part Description Quantity Note — 244768 MOTOR, air, 64B 981182 • SCREW, socket head, #12−28 x 1.75 in., steel 983131 • WASHER, lock, split, #12, steel, zinc 323068 • SPOOL 244192 • SUPPORT, spool 323073 •...
Page 64: Air Valve Parts
B. Included in Crankshaft and Arm Service Kit, part 106314. Refer to page 9-7 for kit parts. C. Included in Air Motor Seal Kit, part 106117. Refer to page 9-7 for kit parts list. AR: As Required NS: Not Shown 104321-08 © 2024 Nordson Corporation...
Page 66: Mufflers, Cover, And Grounding Parts
SCREW, hex head, 1/4−20 x 0.75 in., cap, zinc 323773 COVER, muffler box 981208 SCREW, hex head, 1/4−20 x 0.625 in., cap, zinc 240674 TAG, ground 132154 STUD, ground 132054 RETAINER, wire 65 64 Figure 9-3 Mufflers, Cover, and Grounding Parts 104321-08 © 2024 Nordson Corporation...
Page 67: Air Motor And Air Valve Service Kits
See Figure 9-1 on page 9-3 for air motor parts. Item Part Description Quantity Note − 106117 KIT, seal, air motor, 64B 952450 • U-cup 940470 • O-RING, Buna-N, square, 4.50 x 4.625 in. 940120 • O-RING, hotpaint, 0.375 x 0.50 x 0.063 in. 986709 •...
Page 68: Options
• NIPPLE, extra heavy, 3/8 in. NPT x 2.00 in. long, steel 900215 • OIL, Vitalizer, 1 quart NOTE: Order in one-foot increments. AR: As Required NS: Not Shown Figure 9-4 Air Motor Accessory Group 104321-08 © 2024 Nordson Corporation...
Page 69: Adhesives, Sealants, And Lubricants
Valve and Air Motor Repair for application instructions. Part Description Quantity 900464 ADHESIVE, threadlocking (Loctite Removable 242) 900223 • LUBRICANT, O-ring, Parker (Parker O-Lube), 4 oz 900278 • LUBRICANT, molybdenum disulfide, 1 gallon 900236 • SEALANT, paste, PTFE, 1 pint 104321-08 © 2024 Nordson Corporation...
Page 71: Hydraulic Section Parts
A dash (—) is used when the part number applies to all parts in the illustration. The number in the Part column is the Nordson Corporation part number. A series of dashes in this column (- - - - - -) means the part cannot be ordered separately.
Page 72: Hydraulic Section Parts
983160 • WASHER, lock, split, 3/8 in., steel, nickel 981562 • SCREW, socket head, 3/8−16 x 1.25 in., zinc 245883 • PACKING, upper, 64B, 15:1, aluminum, Type F 940292 • • O-RING, hotpaint, 1.50 x 1.625 x 0.063 in. 954035 •...
Page 74: Replacement Packing Glands
Hydraulic Section Parts 10-4 Replacement Packing Glands Packing Glands for 15:1 Aluminum 64b Pump Packing Gland Type A Type D Type F Type G Type U Upper 503575 (A) 503568 (B) 245883 (A) 240864 (B) 333383 (A) Lower 503580 (A)
Page 75: Hydraulic Section Service Kits
Item Part Description Quantity Note — 106120 SERVICE KIT, ball check, 15:1, 64B 503574 • CAGE, ball 900021 • BALL, 440 stainless steel, 0.688 in., 100 940200 • O-RING, hotpaint, 0.875 x 1.00 x 0.063 in. - - - - - - •...
Page 76: Hydraulic Service Kits For Type A, F, And U Packing Glands
See Figure 10-1 for parts locations. Item Type A Type F Type U Description Quantity Note − 106119 106289 335388 SERVICE KIT, hydraulic, 15:1, 64B, Type __ 503575 245883 333383 • GLAND, packing, upper 503580 245884 335367 • GLAND, packing, lower 941400...
Page 77: Options
Siphon Accessory Group See Figure 10-3. Item Part Description Quantity Note − 498552 ACCESSORY GROUP, siphon, 64B, 15:1, 30:1, standard 972598 • ELBOW, male, 37, 7/8−14 x 3/4 in. NPT, steel 824060 • HOSE, Nylon, 5 ft 972100 • CONNECTOR, male, 37, 7/8−14 JIC x 1/2 in. NPTF 750085 •...
Page 78 Use these adhesives, sealants, and lubricants when repairing the hydraulic section. Refer to Hydraulic Section Repair, for applications. Part Description Quantity 900464 ADHESIVE, threadlocking (Loctite Removable 242) 900223 • LUBRICANT, O-ring, Parker (Parker O-Lube), 4 oz 900236 • SEALANT, paste, PTFE, 1 pint 104321-08 © 2024 Nordson Corporation...
Page 80: 64B Air Motor Parts
11-2 Drawings 64B Air Motor Parts Nordson Customer Service: (800) 433-9319 244768 Air Motor 323773 MUFFLER BOX COVER (2) 983140 LOCKWASHERS (4) 244764 981208 MUFFLER BOX SCREW (6) 244763 AIR VALVE 981211 SCREWS (4) 981182 323064 NUT 247690 SCREW COVER...
Page 81: 64B Air Valve Parts
Drawings 11-3 64B Air Valve Parts Nordson Customer Service: (800) 433-9319 244763 Air Valve 984130 NUT 981107 SCREW (4) 983140 LOCKWASHER 983120 LOCKWASHER (8) 323017 SPACER 323020 SNAPPER 983040 WASHER 323016 BRACKET 981203 SCREW 244758 323013 GASKET (KIT A) R.H. SEAL...
Page 82: 64B 15:1 Aluminum Hydraulic Section Parts
11-4 Drawings 64B 15:1 Aluminum Hydraulic Section Parts Nordson Customer Service: (800) 433-9319 503571 SOLVENT CHAMBER 700037 941400 O-RING SOLVENT FILLER 503586 983150 PLUNGER LOCK WASHER 503592 SIPHON 503585 HOUSING PLUNGER ASSEMBLY 981315 SCREW 503574 248675 CAGE HOUSING (KITS A,...
Page 83: Eu Declaration Of Conformity
Amherst, Ohio, USA Nordson Authorized Representative in the EU Person authorized to compile the relevant technical data. Contact: Operations Manager Industrial Coating Systems Nordson Deutschland GmbH Heinrich-Hertz-StraBe 42-44 D-40699 Erkrath Nordson Corporation • 100 Nordson Dr, Amherst, Ohio 44001 • USA DOC13010-07...
Page 84 Industrial Coating Systems Amherst, Ohio, USA Nordson Authorized Representative in the UK Contact: Technical Support Engineer Nordson UK Ltd.; Unit 10 Longstone Road Heald Green; Manchester, M22 5LB. England Nordson Corporation • 100 Nordson Dr, Amherst, Ohio 44001 • USA DOC13041-04...
Page 85: Air Lubricator Adjustments And Oils
1. Fill the lubricator bowl with Nordson Vitalizer oil. NOTE: Use only Nordson Vitalizer oil or an oil recommended by your Nordson representative. Disregard any oil recommendations in the OEM instruction sheet shipped with the air lubricator.
Page 86: Vitalizer Oil Specifications
Issued 1/04 Original copyright date 1991. Nordson and the Nordson logo are registered trademarks of Nordson Corporation. Part 108152−01 E 2017 Nordson Corporation...
Page 87: Instruction Sheet
Medium K, S Aliphatic Petroleum Naphthas High T, Q K, S Mild K, S Chlorinated Solvents Medium High K, S Note 1: Type U packings may swell slightly when exposed to aromatic hydrocarbon solvents. Part 108044G E 2003 Nordson Corporation...
Page 88 NOTE: Type K solvent is highly viscous. At room temperature, it is not appropriate for use in Model 25B or 64B pumps where the solvent must flow through a filler cup and small ID passage into the solvent chamber.
Page 89 4. Add the remaining distilled water to make one gallon, and mix for an additional 15 minutes. NOTE: The mixture may separate after prolonged shelf time. If it does, mix again before using. Part 108044G E 2003 Nordson Corporation...
Page 90 Pump Packing and Solvent Chamber Fluid Guide Issued 10/03 Original copyright date 1990. Nordson and the Nordson logo are registered trademarks of Nordson Corporation. Part 108044G E 2003 Nordson Corporation...
Page 91 64B 15:1 Aluminum Pump Refer to the 64B 15:1 Aluminum Pump manual 104321 for complete service and parts information. Refer to the 64B 15:1 Aluminum Pump manual 104321 for complete service and parts information. For parts and technical support call (800) 433-9319.
Page 92 Air Section Service Kits H - Air Motor Seal Kit 106117 J - Air Valve Seal Kit 106103 K - Air Valve Crankshaft and Arm Kit 106314 900214 Vitalizer Oil (1 pint) ©2009 Nordson Corporation ©2009 Nordson Corporation 104321-QR03...
