Key Operation Instruction; How To Set Parameters - Inkbird ITC-306T User Manual

ITC-306T User Manual

4. Key Operation Instruction

4.1 How to set parameters

When the controller is working normally, press "SET" key for over 3 seconds to enter
parameters set up mode. "SET" indicator lamp will on. PV window displays the first menu
code "TS1", while SV window displays according setting value. Press "SET" key to go to
" key or " " key to set current
next menu and display according menu code, press"
parameter value.
After setting done, press"SET" key for 3 seconds at any time to save the parameters
change and return to normal temperature display mode. During setting, if there is no
operation for 10 seconds, the system will quit setting mode and return to normal
temperature display mode without saving the parameters change.
6
