Installation, Operating, and Servicing
Instructions
Opus 800 Electric Heated Tilting Bratt Pan
OE8802-A003
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 583 ECN 4477
Page 1 of 14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lincat Opus 800
Summary of Contents for Lincat Opus 800
- Page 1 Installation, Operating, and Servicing Instructions Opus 800 Electric Heated Tilting Bratt Pan OE8802-A003 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 583 ECN 4477 Page 1 of 14...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned, and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. Strip plastic coating and clean the appliance before use. During operation parts may become hot - avoid accidental contact. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Checklist Of Enclosures
CHECK LIST OF ENCLOSURES Warranty card Instructions manual INSTALLATION AND COMMISSIONING This appliance must only be used by qualified professionals. An equipotential bonding terminal is provided to allow cross bonding with other equipment. Install this appliance on a level surface ensuring all air vents are unobstructed. Any partitions, walls or furniture must be of non-combustible material. - Page 5 This appliance must be earthed. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance.
-
Page 6: Starting The Appliance
STARTING THE APPLIANCE Start the appliance following the instructions for use. Check the heating devices are working correctly. Raise and lower the tank. Ensure that the cut out operates when the tank is raised, and that power is restored when the tank is lowered into the working position again. In the event of a malfunction, this appliance is equipped with a safety thermostat that interrupts the supply. - Page 7 Bratt Pan The bratt pan is fitted with control knob, (see figure 2) power indicator lamp, heating indicator lamp, a hand wheel for tilting the pan and a button for filling with water. The control knob (a) sets the temperature of the tank and the elements operate when switched to the on position.
-
Page 8: Cleaning
Emptying the tank Prepare a suitable vessel beneath the discharge spout of the tank. Lift the lid. Slowly raise the tank by turning the wheel clockwise.. Take care not to create ‘surge’ of liquid contents by attempting to raise the tank too quickly. CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. - Page 9 Replacing components with spares IMPORTANT: Before making any repairs disconnect the appliance from the electrical supply. Energy regulator Remove hand wheel. Remove control knob and facia panel. Unscrew the fixing screws and disconnect the wiring. Remove. Replace. Electronic Controller Remove hand wheel. Remove front lower facia panel.
-
Page 10: Fault Finding
Rewire replacement contactor Re-clip contactor. Replace flame controller. Replace all removed parts in reverse order FAULT FINDING Please refer to the Service Help Desk number on the final page of this manual. POTENTIAL TROUBLESHOOTING AND SOLUTIONS Even during correct use of the appliance, malfunctions and breakdowns may occur. Common situations are listed below, and checks an installer should make before contacting the technical support centre are indicated. - Page 11 EC10 Electronic controller EN10 Energy regulator HA112 Hand wheel KN511 Control knob NE46 Neon - green NE47 Neon - amber SO27 Solenoid SP92 Lid spring SW80 Green button SW82 Switch TH61 Safety cut out thermostat TS03 Trapezoidal screw X54900 Micro-switch X59200 Terminal block IS 583 ECN 4477...
- Page 12 IS 583 ECN 4477 Page 12 of 14...
-
Page 13: Accessories
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights. - Page 14 Damage due to incorrect installation, modification, unauthorised service work or damage due to scale, food debris build-up, etc. The manufacturer disclaims any liability for incidental, or consequential damages. Attendance is based on reasonable access to the appliance to allow the authorised technician to carry out the warranty work.
