Installation, Operating, and Servicing
Instructions
Opus 800 Gas Solid Top Range
OG8005-A002
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS644 ECN 4259
Page 1 of 20
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lincat Opus 800
Summary of Contents for Lincat Opus 800
- Page 1 Installation, Operating, and Servicing Instructions Opus 800 Gas Solid Top Range OG8005-A002 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS644 ECN 4259 Page 1 of 20...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned, serviced and converted by a qualified person in accordance with national and local regulations in force in the country of installation. Strip plastic coating and clean the appliance before use. During operation parts may become hot - avoid accidental contact. Parts protected by the manufacturer shall not be adjusted by the user. -
Page 4: Technical Data
TECHNICAL DATA Model OG8005 Dimensions Height (mm) Width (mm) Depth (mm) Weight (kg) 158.4 Hob Cooking Surface w x d (mm) 900 x 600 Useable Oven Capacity w x d x h (mm) 715 x 540 x 400 Oven Shelf w x d (mm) 715 x 540 Heat Input (Gross) Total - Natural... -
Page 5: Installation And Commissioning
INSTALLATION AND COMMISSIONING Site this appliance beneath an extraction canopy for the removal of combustion products. When making the gas connection, fit an isolating cock into the supply line close to the appliance for emergency shutdown or servicing purposes. Installation must include sufficient ventilation to prevent the occurrence of unacceptable concentrations of substances harmful to health in the room of installation. - Page 6 ACCESS The overall depth of the appliance (including door handles) is 832mm. This can be reduced further to an overall depth of 760mm by the following steps. If this is still not sufficient the hob & oven can be separated (see step 4). Step 1 - Removal of Flue (Overall depth 802mm) ...
- Page 7 Step 3 - Removal of Fascia (Overall depth 760mm) Remove control knobs CC. Undo the two fascia fixing screws EE. Remove the fascia panel BB. Care should be taken when removing the fascia panel as the oven ignitor & earth lead will be attached to the ignitor.
- Page 8 SITING The installer must ensure that all regulations are met and that there is an unobstructed minimum distance of 1000mm from the top of the flue to the ceiling, which must be of non-combustible material. The appliance should be installed on a level surface ensuring the unit is stable and firmly located.
-
Page 9: Operating Instructions
OPERATING INSTRUCTIONS This appliance is only for professional use and should only be used by qualified personnel. Ensure that the person responsible understands how to light, safely operate, clean and shut down the appliance and is made aware of the position and operation of the gas isolating cock in the event of an emergency. -
Page 10: Cleaning
Your Lincat product has a manufacturer’s warranty. This requires you to maintain and care for your product and follow maintenance instructions. If you fail to maintain your unit or damage components Lincat may charge you for a warranty repair. Please check the website for terms and conditions. - Page 11 The Shelves and Side Hangers can be cleaned with a mild detergent and hot water solution using a soft bristled brush. For stubborn deposits a de-greasing agent may be used. Rinse and dry thoroughly with a dry cloth. Oven Drip Tray - Open the oven doors and remove the drip tray from the appliance. The Oven Drip Tray can be cleaned with a mild detergent and hot water solution using a soft bristled brush.
-
Page 12: Servicing, Maintenance And Component Replacement
SERVICING, MAINTENANCE AND COMPONENT REPLACEMENT All servicing, maintenance and component replacement on this appliance should be carried out by one of our recommended service engineers. SERVICE ACCESS To access and service the gas control valves - Recommended every 6 months Remove the control knobs CC and facia panel BB (see page 7) to gain access to the valves. - Page 13 Control Valve Remove the control knobs CC and fascia panel BB (see page 7). Remove the nut from the gas output at the valve. Remove the thermocouple nut from the valve. Remove clamp screws K from the valve. Free the valve from the manifold G. Fit the new valve and re-assemble reverse order.
- Page 14 Hob Valve Bypass Injectors Remove control knobs CC and fascia panel BB (see page 7). Remove the bypass injector J from the hob burner control valves H. Replace the bypass injector applicable to the required gas type. Screw fully home, but do not over tighten.
- Page 15 Oven Burner injector Remove the oven base tray and shelves. Disconnect the ignition lead and remove thermocouple T by undoing lock nut V. Undo the flexi hose from the coupling O and remove coupling O from burner. Remove the injector, fibre washer W and copper washer X. Replace the injector applicable to the required gas type including the new washers supplied.
-
Page 16: Conversion
CONVERSION Conversion of Gas Type – Injector Changes Model Inlet Pressure Injector Mark Part No. 2.20 JE103 x1 JE275 x1 OG8005 20 mbar 2.30 JE28 x1 JE250 x1 1.50 JE218 x1 JE250 x1 OG8005 37 mbar 1.51 JE45 x1 JE251 x1 Hob Valve Bypass Injectors ... - Page 17 Oven Thermostat Bypass Injector Remove the bypass injector L from the oven thermostat valve M. Replace the bypass injectors applicable to the required gas type. Screw fully home, but do not over tighten. Re-fit the ignitor lead, facia panel BB and control knobs CC. Oven Thermostat Components Part Description...
-
Page 18: Fault Finding
FAULT FINDING Please refer to the Service Help Desk number on the final page of this manual. Piezo oven ignitor not sparking. Check for a short in the high tension lead Replace lead Check electrode for fracture Replace electrode Replace piezo ignitor ... -
Page 19: Spare Parts List
SPARE PARTS LIST Part number Part description OG8005 BE21 Bulls eye BU55 Door bushes BU72 Door bushes BU78 Oven burner BU103 Burner cap BU104 Burner body BU106 Injector housing BU107 Elbow BU108 Venturi CO113 Copper Washer CA143 125mm braked swivel castors CA145 125mm un-braked swivel castors CO113... -
Page 20: Service Information And Guarantee
Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. DECLARATION All Lincat products capable of burning gaseous fuels, satisfy the requirements of the Gas Appliance Regulations 2016/426.
