  • Page 1 Installation, Operating, Servicing and Conversion Instructions Opus 800 Gas Open Top Oven Ranges OG8001-A003 Please make a note of your product details for future use: Date Purchased: _________________________ Model Number: __________________________ Serial Number: __________________________ Dealer: _________________________________ _______________________________________ IS668 ECN 4259 Page 1 of 20...

  • Page 2: Table Of Contents

    WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips.

  • Page 3: Warnings And Precautions

    WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned, serviced and converted by a qualified person in accordance with national and local regulations in force in the country of installation. Strip plastic coating and clean the appliance before use. During operation parts may become hot - avoid accidental contact. Parts protected by the manufacturer shall not be adjusted by the user.

  • Page 4: Technical Data

    TECHNICAL DATA Model OG8001 Dimensions Height (mm) Width (mm) Depth (mm) Weight (kg) Hob Cooking Surface w x d (mm) 600 x 600 Useable Oven Capacity w x d x h (mm) 480 x 540 x 400 Oven Shelf w x d (mm) 480 x 540 Connection and Operating Pressures ¾”...

  • Page 5: Checklist Of Enclosures

    CHECK LIST OF ENCLOSURES Model OG8001 Tick Warranty card Instructions manual Pan Supports Oven Shelves INSTALLATION AND COMMISSIONING Site this appliance beneath an extraction canopy for the removal of combustion products. When making the gas connection, fit an isolating cock into the supply line close to the appliance for emergency shutdown or servicing purposes.

  • Page 6: Sitting, Gas Supply, Supply Pressure

    SITING The installer must ensure that all regulations are met and that there is an unobstructed minimum distance of 1000mm from the top of the flue to the ceiling, which must be of non-combustible material. The appliance should be installed on a level surface ensuring the unit is stable and firmly located.

  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS This appliance is only for professional use and should only be used by qualified personnel. Ensure that the person responsible understands how to light, safely operate, clean and shut down the appliance and is made aware of the position and operation of the gas isolating cock in the event of an emergency.

  • Page 8: Cleaning

    CLEANING Your Lincat product has a manufacturer’s warranty. This requires you to maintain and care for your product and follow maintenance instructions. If you fail to maintain your unit or damage components Lincat may charge you for warranty repair. Please check the website for terms and conditions.
  • Page 9 Oven Shelves & Side Hangers – Open the oven doors and remove the shelves and hangers. To remove shelves, tilt up the rear and slide shelf forward. To remove side hanger, lift hanger up and then pull into centre of oven. Fig.

  • Page 10: Servicing, Maintenance And Component Replacement

    SERVICING AND MAINTENANCE All servicing, maintenance and component replacement on this appliance should be carried out by one of our recommended service engineers. SERVICE ACCESS To access and service the gas control valves – Recommended every 6 months  Remove the control knobs D and facia panel C to gain access to the valves.
  • Page 11 COMPONENT REPLACEMENT Hob Thermocouple Remove the control knobs D, pan supports F and facia panel C. Remove the top thermocouple lock nut. Remove thermocouple nut from valve body BB. Withdraw the thermocouple. Fit the new thermocouple and re-assemble in the reverse order. Oven Thermocouple Remove the control knobs D and facia panel C.
  • Page 12 Oven Ignitor Electrode Remove the oven shelves. Remove the ignitor lead at the ignitor. Remove the ignitor retaining screw and nut. Replace the ignitor. Check that the ignitor is replaced correctly and ignites the pilot flame upon operation. Piezo Ignitor Remove facia panel C.

  • Page 13: Conversion

    CONVERSION Conversion of Gas Type – Injector Changes  Model Inlet Pressure Injector Mark Part No. 1.96 JE273 x 6 1.10 JE275 x 6 OG8001 20 mbar 1.90 JE14 x 1 0.74 JE250 x 1 1.34 JE281 x 6 0.74 JE276 x 6 OG8001 37 mbar...
  • Page 14 DETAIL A Oven Thermostat Bypass Injector  Remove the bypass injector GG from the oven thermostat valve FF.  Replace the bypass injectors applicable to the required gas type. Screw fully home but do not over tighten.  Re-fit the igniter lead, facia panel F and control knobs D. Oven Thermostat Components Part Description...

  • Page 15: Fault Finding

    FAULT FINDING Please refer to the Service Help Desk number on the final page of this manual.  Piezo oven ignitor not sparking. Check for a short in the high tension lead Replace lead Check electrode for fracture Replace electrode Replace piezo ignitor ...

  • Page 16: Spare Parts List

    SPARE PARTS LIST Part number Part description OG8001 BU55 Door bush BU86 Oven burner BU103 Burner cap BU104 Burner body BU106 Injector housing BU107 Elbow BU108 Venturi CO113 Copper Washer CA143 125mm braked swivel castors CA145 125mm un-braked swivel castors DO211 Door catch assembly HA77...

  • Page 17: Accessories

    ACCESSORIES Part Number Description Used on OA8901 Splashback/Shelf OG8001 IS668 ECN 4259 Page 17 of 20...

  • Page 18: Service Information And Guarantee

    Type number  Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. DECLARATION All Lincat products capable of burning gaseous fuels, satisfy the requirements of the Gas Appliance Regulations 2016/426.
  • Page 19 For Information IS668 ECN 4259 Page 19 of 20...
  • Page 20 For Information IS668 ECN 4259 Page 20 of 20...
