Lincat Opus 800 Series Installation, Operating, Servicing And Conversion Instructions
Gas open top oven ranges
Hide thumbs
Also See for Opus 800 Series:
Table of Contents
Advertisement
Quick Links
Installation, Operating, Servicing and
Conversion Instructions
Opus 800 Gas Open Top Oven Ranges
OG8002-A003
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS654 ECN 4259
Page 1 of 24
Advertisement
Table of Contents
Related Manuals for Lincat Opus 800 Series
Summary of Contents for Lincat Opus 800 Series
- Page 1 Installation, Operating, Servicing and Conversion Instructions Opus 800 Gas Open Top Oven Ranges OG8002-A003 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS654 ECN 4259 Page 1 of 24...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS It is mandatory that all appliances are installed, commissioned and serviced by a qualified and competent person as defined by the regulations in force in the country of installation. Failure to comply will invalidate the warranty. WARNING! This appliance must be installed by a competent installation engineer in accordance with the installation instructions, and should conform to the following requirements: Do not obstruct or block the appliance flue. -
Page 4: Technical Data
TECHNICAL DATA Model OG8002 Dimensions Height (mm) Width (mm) Depth (mm) Weight (kg) Hob Cooking Surface w x d (mm) 900 x 600 Useable Oven Capacity w x d x h (mm) 715 x 540 x 400 Oven Shelf w x d (mm) 715 x 540 Connection and Operating Pressures Pressuresimensions ¾”... -
Page 5: Checklist Of Enclosures
Pan Supports Oven Shelves SERIAL NUMBER Each appliance manufactured at Lincat has a unique identifying number found in NOTE the top right hand corner of the data plate attached at the rear of the appliance. Please record that number in the space provided should it be required for future reference. -
Page 6: Installation
INSTALLATION Site this appliance beneath an extraction canopy for the removal of combustion products. When making the gas connection, fit an isolating cock into the supply line close to the appliance for emergency shutdown or servicing purposes. Installation must include sufficient ventilation to prevent the occurrence of unacceptable concentrations of substances harmful to health in the room of installation. - Page 7 GAS SUPPLY AND CONNECTION Connection is at the rear of the unit via a R ½ (½" BSP) Connection shall comply with local regulations. The hose shall be periodically examined and replaced as necessary. When making the connection to the appliance an isolating cock should be fitted into the supply line close to the unit, for emergency shutdown or servicing purposes.
-
Page 8: User Instruction
USER INSTRUCTION APPLIANCE USE This appliance is only for professional use and should only be used by qualified personnel. Ensure that the person responsible understands how to light, safely operate, clean and shutdown the appliance and is made aware of the position and operation of the gas isolating cock in the event of an emergency. - Page 9 If the appliance has stood unused for any length of time it may be necessary to purge the burner feed pipes of air. To purge the burner feed pipes of air depress and rotate a control knob to the full on position. Maintain the knob in the depressed position for 20- 30seconds and then light the gas at the burner.
-
Page 10: Cleaning
CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. Dry with a soft cloth. It is important that users of the appliance systematically check and clean down as necessary areas of the hob and oven cavity that have accumulated oils, fats and other combustible debris from previous cooking. - Page 11 The Pan Supports can be cleaned with a mild detergent and hot water solution using a soft bristled brush. Rinse and dry thoroughly with a dry cloth. Burner Cap – Remove from the appliance taking care not to damage the thermocouple which protrudes from the support.
- Page 12 Oven Compartment – Open the oven doors and leave the drip tray P in situ. Oven Components Part Description Thermostat Phial Oven Drip Tray The sides, top and back panels can be cleaned with a mild detergent and hot water solution using a soft bristled brush.
-
Page 13: Servicing And Maintenance
SERVICING AND MAINTENANCE All servicing, maintenance and component replacement on this appliance should be carried out by one of our recommended service engineers. SERVICE ACCESS To access and service the gas control valves Remove the control knobs D and fascia panel C to gain access to the valves. ... -
Page 14: Component Replacement
COMPONENT REPLACEMENT Hob Thermocouple Remove the control knobs D, pan supports F and fascia panel C. Remove the top thermocouple lock nut. Remove thermocouple nut from valve body BB. Withdraw the thermocouple. Fit the new thermocouple and re-assemble in the reverse order. Oven Thermocouple Remove the control knobs D and fascia panel C. - Page 15 Remove the ignitor retaining screw and nut. Replace the ignitor. Check that the ignitor is replaced correctly and ignites the pilot flame upon operation. Piezo Ignitor Remove facia panel C. Disconnect the ignitor and ignitor earth leads. Remove the retaining nut and withdraw from unit. Replace and fit in reverse order.
-
Page 16: Conversion
CONVERSION Conversion of Gas Type – Injector Changes Model Inlet Pressure Injector Mark Part No. 1.96 JE273 x 6 20 mbar 1.10 JE275 x 6 OG8002 2.30 JE28 x 1 25 mbar 0.74 JE250 x 1 1.34 JE281 x 6 0.74 JE250 x 6 OG8002... - Page 17 DETAIL A Oven Thermostat Bypass Injector Remove the bypass injector GG from the oven thermostat valve FF. Replace the bypass injectors applicable to the required gas type. Screw fully home but do not over tighten. Re-fit the igniter lead, fascia panel F and control knobs D. Oven Thermostat Components Part Description...
-
Page 18: Fault Finding
FAULT FINDING Please refer to the Service Help Desk number on the final page of this manual. Piezo oven ignitor not sparking. Check for a short in the high tension lead Replace lead Check electrode for fracture Replace electrode Replace piezo ignitor ... -
Page 19: Spare Parts List
SPARE PARTS LIST Part number Part description OG8002 BU55 Door bush BU78 Oven burner BU103 Burner cap BU104 Burner body BU106 Injector housing BU107 Elbow BU108 Venturi CO113 Copper Washer CA143 125mm braked swivel castors CA145 125mm un-braked swivel castors DO211 Door catch assembly HA77... -
Page 20: Accessories
ACCESSORIES Part Number Description Used on OA8902 Splashback/Shelf IS654 ECN 4259 Page 20 of 24... -
Page 21: Service Information And Guarantee
SERVICE INFORMATION For help with the installation, maintenance and use of your Lincat equipment, please contact our service department: UK: 01522 875520 For non-UK customers, please contact your local Lincat dealer All service work, other than routine cleaning MUST be carried out by qualified personnel and a record kept of any remedial actions taken and at least cover the requirements of the service schedule of this document. - Page 22 For Information IS654 ECN 4259 Page 22 of 24...
- Page 23 IS654 ECN 4259 Page 23 of 24...
- Page 24 IS654 ECN 4259 Page 24 of 24...
