Installation, Operating and Servicing
Instructions
Opus 800 Electric Pasta Boiler
OE8701
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 596 ECN 3905
Page 1 of 14
Advertisement
Table of Contents
Related Manuals for Lincat Opus 800
Summary of Contents for Lincat Opus 800
- Page 1 Installation, Operating and Servicing Instructions Opus 800 Electric Pasta Boiler OE8701 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 596 ECN 3905 Page 1 of 14...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING Install this appliance on a level surface ensuring all vents are unobstructed. Any partitions, walls or furniture must be of non-combustible material. Minimum distances A 100mm B 1000mm – see Fig 1. Fig 1 Do not install adjacent to any appliance with hot oil or similar, such as a fryer. Install this appliance beneath an extraction canopy. - Page 5 Electrical connection This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. Cable colours are as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance.
-
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Only qualified or trained personnel should use this appliance. Before first use Ensure the water drain tap is closed. Clean the tanks thoroughly with a warm mild detergent solution. Drain the tanks, rinse the tanks, drain taps and pipes and dry. Close the drain taps. A Water inlet B Water level marker C Heater control... - Page 7 REVISION No Error: No reference Error: No reference : No reference TITLE Error: No reference Error: No reference ALL DIMENSIONS IN mm © 2016 LINCAT LTD, UNLESS OTHERWISE Error: No referen DRG No CREATED STATED 09/05/2016 STILL WHISBY ROAD, LINCOLN, LN6 3QZ...
- Page 8 the desired setting – the amber neon will illuminate indicating power to the element. There is a range of 1-6 settings, with constant power position beyond the ‘6’ setting. When the set temperature is reached, the element will cycle on and off to maintain temperature.
- Page 9 Safety thermostat resets Drain tap (Shown in the closed position). Fig 4 Draining the tank Isolate the appliance from the supply and allow the water to cool to a maximum of 55 Deg C. Open the drain tap (Fig 4) and allow the water to drain. Close the drain tap ready for further use.
-
Page 10: Cleaning
- allow the appliance to cool before carrying out inspection for scale. De-scale regularly using an approved de-scaling compound such as can be supplied by Lincat (Code DP10). Do not use hydrochloric acid based de-scaling compounds on stainless steel. -
Page 11: Servicing, Maintenance And Component Replacement
Your Lincat product has a manufacturer’s warranty. This requires you to maintain and care for your product and follow maintenance instructions. If you fail to maintain your unit or damage components Lincat may charge you for a warranty repair. Please check the website for terms and conditions. -
Page 12: Fault Finding
Remove element and sealing gasket from inside of tank. Fit new element and reassemble in reverse order. Important: When tightening element mounting nuts ensure that they are tightened to a torque figure of 1N/m. Over-tightening will distort the gasket, resulting in a non-watertight seal. FAULT FINDING Appliance will not heat Is the green neon illuminated... -
Page 13: Spare Parts List
SPARE PARTS LIST Part Number Description CO166 Swirl inlet fitting CO168 Compact tee inlet CO215 Contactor EL208 Element EN10 Energy regulator FZ101771 Solenoid FZ401101 Drain tap HA73 Door handle HA78 Lid handle KN500 Water control knob KN511 Control thermostat knob LE37 NE46 Green neon... -
Page 14: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
