SSL 2+ MKII User Guide – SSL Support
SSL 2+ MKII is a USB-powered audio interface that enables you to get
studio-quality audio into and out of your computer with minimal fuss and
maximum creativity. On Mac, it's class-compliant - this means that you don't
need to install any software audio drivers. On Windows, you'll need to install
our SSL USB Audio ASIO/WDM driver, which you'll find on our website -
see the Quick-Start section of this guide for more information on getting up
and running. Once you've done this, you'll be ready to start connecting your
microphones and musical instruments. The signals from these inputs will be
sent into your favourite music creation software / DAW (Digital Audio
Workstation). The outputs from the tracks in your DAW session (or indeed
your favourite media player) can be sent out of the monitor and headphone
outputs, so you can hear your creations in all their glory, with stunning
clarity.
Features
2 x SSL-designed microphone preamps with unrivalled EIN
performance and huge gain range for a USB-powered device.
Switchable Mic/Line, +48V phantom power & high-pass filter per
input
Auto-detect Instrument (DI) input per input
Per channel Legacy 4K switches - analogue colour enhancement
for any input source, inspired by the 4000-series console
2 x professional-grade, independent headphone outputs with
separate volume controls & plenty of power
32-bit / 192 kHz AD/DA Converters - capture and hear all the detail
of your creations
Easy-to-use Monitor Mix Control for critical low-latency monitoring
tasks
4 x balanced outputs, with stunning dynamic range. The outputs are
DC-coupled, making them suitable for controlling CV input instruments
& FX
Stereo Loopback virtual input for podcasting, content creation and
streaming
SSL Production Pack Software Bundle: including SSL Native
Vocalstrip 2 and Drumstrip DAW plug-ins, plus much more!
USB 2.0, bus-powered audio interface for Mac/PC - no power
supply required
MIDI 5-Pin DIN Inputs & Outputs
K-Lock Slot for securing your SSL 2+
