- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® ITEM: BDL-550-4-BBZ-MR16-LL 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS VOLT BDL-550-4-BBZ-MR16-LL ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. -
Page 3: Package Contents
PACKAGE CONTENTS A. (1) Housing C. (5) Lock Screws B. (1) Fixture Cover with Gasket PARTS REQUIRED (SOLD SEPARATELY) A. (1) MR16 Bulb PRODUCT DIMENSIONS 5.00” 5.00” 1.20” 1.40” 4.50” 4.50” 5.50” 5.50” 0.20” 0.60” 5.00” 5.00” 4.50” 4.50” 5.50” 5.50”... -
Page 4: Wire Connection
INSTALLATION INSTRUCTIONS VOLT BDL-550-4-BBZ-MR16-LL ® DIG A HOLE Dig a hole in the ground. Make Fixture sure there is approximately a 3” space surrounding all sides of the fixture housing for pea 3” 3” gravel or sand. 3” Hole Soil... - Page 5 INSTALL MR16 LAMP Insert the MR16 lamp with the correct Socket wattage and type as marked on the MR16 Lamp luminaire label. CAUTION: Do not exceed maximum wattage marked on luminaire label. NOTE: DO NOT touch lamp with bare hands. Use soft cloth to handle lamp. INSTALL FIXTURE COVER WITH GASKET Allen Wrench Place the fixture cover with...
- Page 6 INSTALLATION INSTRUCTIONS VOLT BDL-550-4-BBZ-MR16-LL ® 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com...
- Page 7 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com...
- Page 8 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2024, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
