INSTALLATION INSTRUCTIONS
VOLT
®
Belladonna LED Path/Area
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2014, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Volt Belladonna LED Path/Area
Summary of Contents for Volt Belladonna LED Path/Area
- Page 1 Belladonna LED Path/Area Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2014, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved. customersupport@voltlighting.com • 813.978.3700...
-
Page 2: Important Safety Instructions
INSTALLATION INSTRUCTIONS VOLT Belladonna LED Path/Area ® VL-1024 Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Package Contents A. (1) Fixture Body C. (1) Diffuser B. (1) LED Bulb Parts Required A. (1) Stake (Sold Separately) B. (1) Base (Sold Separately) Product Dimensions 11.25” 3.5” 8” 26.5” Install Stake Determine desired location for mounting fixture. Hammer stake into ground until Board flange of stake is flush to grade.
- Page 4 INSTALLATION INSTRUCTIONS VOLT Belladonna LED Path/Area ® VL-1024 Install Fixture Body to Stake Clear away area in ground at wireway Fixture Body slot in top of stake. Align the wireway slots on base and stake. Lay luminaire pigtail into wireway slots and thread...
- Page 5 Install Bulb Insert bulb with correct wattage and Socket type marked on fixture label. CAUTION: Do not exceed maximum wattage marked on luminaire label. NOTE: DO NOT touch bulb with bare hands. Use soft cloth to handle bulb. Bulb Install Diffuser Remove screws from the shade.
- Page 6 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2014, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
