INSTALLATION INSTRUCTIONS
VOLT
®
VOLT
®
VSPL-1045-BBZ and VSPL-1045-PBK
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2021, VOLT
customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
Solar Integrated LED Path Light
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Volt VSPL-1045-BBZ
Summary of Contents for Volt VSPL-1045-BBZ
- Page 1 Low Voltage Landscape Lighting ® VOLT Solar Integrated LED Path Light ® VSPL-1045-BBZ and VSPL-1045-PBK Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 •...
- Page 2 INSTALLATION INSTRUCTIONS VOLT Solar Integrated LED Path Light ® VSPL-1045-BBZ and VSPL-1045-PBK Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture Body Parts Required A. Riser B. Mounting Accessory Product Dimensions 8.7” 4” 7.5” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Solar Integrated LED Path Light ® VSPL-1045-BBZ and VSPL-1045-PBK Test Solar Light Black Material Solar Panel On/Off Switch Slide the ON/OFF switch of the fixture to the “ON” position. Cover solar panels completely by using black materials. The fixture will light up when the solar panel is covered and turn back off when it is uncovered.
- Page 5 Install Stake Determine the desired location Board for mounting the stake mount. Hammer the stake into the ground until flange of stake is flush to grade. To avoid damage to the stake, place a board on top of the stake while Stake hammering.
- Page 6 INSTALLATION INSTRUCTIONS VOLT Solar Integrated LED Path Light ® VSPL-1045-BBZ and VSPL-1045-PBK How to Replace Battery Remove Shield Shield Press the sides of the shield to remove it from the fixture body. Remove Luminaire Using a screwdriver, remove the Screw 3 screws.
- Page 7 Remove Circuit Board Remove the battery cover from the luminaire by using a screwdriver and removing the Screw screws. Battery Cover Luminaire Replace Battery Quick Connector Screw Press Battery Holder Luminaire Disconnect the quick connector by pressing the tabs on the side. Remove the old battery by removing the two screws.
- Page 8 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2021, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
