- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® VOLT Gentle Splash Cast Brass Flood Light & Wall Wash ® ITEM: VFL-430-4-BBK 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- Page 2 INSTALLATION INSTRUCTIONS VOLT Gentle Splash Flood Light & Wall Wash VFL-430-4-BBK ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 PACKAGE CONTENTS A. (1) Stake B. (1) Luminaire PRODUCT DIMENSIONS 4” 2” 1.5” INSTALL STAKE Determine the desired location Board for mounting the stake mount. Hammer the stake into the ground until flange of stake is flush to grade. To avoid damage to the stake, place a board on top of the stake while hammering.
- Page 4 INSTALLATION INSTRUCTIONS VOLT® Gentle Splash Flood Light & Wall Wash VFL-430-4-BBK Remove Cover and Gasket with Lens Socket Lock Screw Cover Luminaire Gasket with lens Loosen the lock screws and remove the cover and gasket with the lens from the luminaire to expose the socket.
- Page 5 Remove Glare Guard Lock Screw Socket Cover Luminaire Gasket with lens Decide which lens you would like to use with this fixture. Then install the gasket with your lens of choice back onto the luminaire and secure with the lock screws. Install Luminaire to Stake Luminaire Clear away an area in the...
- Page 6 INSTALLATION INSTRUCTIONS VOLT® Gentle Splash Flood Light & Wall Wash VFL-430-4-BBK Wire Connection Pigtail Wire Connectors Main Low Voltage Supply Cable Strip both leads from the luminaire pigtail. Using two wire connectors (sold separately), connect the leads from the luminaire to the main supply cable leads.
- Page 7 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
