Wiring the lock requires at least three connections; red (positive), black (negative), and blue (control).
Ensure the strike magnet is located at the correct position in the strike for the chosen installation orientation.
Ensure the power supply has the following current available to power the lock when supplied with the following;
2.0A for 24VDC supply with the heater on, 0.5A for 24V supply with the heater off, and 1.0A for 12VDC supply with the
heater off.
Use an appropriate wire gauge for the wire run distance between the lock and power supply.
Do not mount the lock operating upwards.
Warranty Information
The product is covered by a 3-year manufacturers' warranty against faulty or malfunctioning parts, components, or product. A faulty product can be
returned at the customers' expense to the seller for review. At the seller's discretion, either a replacement lock or affected part will be supplied to
remedy the fault. Installing the lock in a way that will lower the integrity of the sealing characteristics of the lock may void the warranty. Mistreatment
or ill-use of the lock may void the warranty.
Package Contents
Lock, Strike, Wire Loom, Neoprene Gasket (Optional)
Product Dimensions
22.6mm
57/64"
80.0mm
3 5/32"
15.0mm
19/32"
How to set the operating mode.
Locate the dip switches on the product, then set as per table shown.
RG80 Quick Start Guide
14.5mm
56.0mm
37/64"
2 13/64"
112.5mm
4 27/64"
48.0mm
60.0mm
1 57/64"
2 23/64"
22.5mm
22.0mm
57/64"
55/64"
Dip Switch #
1
2
OFF
OFF
OFF
ON
ON
OFF
ON
ON
X
X
X
X
X
X
X
X
Toggle the dip switch on the product before powering up.
Installation and Operating
Instructions Download
60.0mm
2 23/64"
80.0mm
3 5/32"
28.0mm
1 7/64"
Description
3
4
X
X
Normal Mode Operation
X
X
Toggle Mode Operation
X
X
Twin Wire Mode Operation
X
X
Diagnostic Mode Operation
OFF
X
Fail Safe Mode
ON
X
Fail Secure Mode
X
OFF
Heater Off
X
ON
Heater On (Requires 24VDC)
