Recovery Tank - KENT Razor Plus 24C Parts List

2004-12

RECOVERY TANK

RAZOR
TM
2006-02
Item No. Ref. No.
2 xxx xxxx xxx
3 08095000
4 909 5246 000
5 56412093
6 56329145
7 xxx xxxx xxx
8 909 5240 000
9 909 5245 000
10# 909 6230 000
12 145 1768 000
13 xxx xxxx xxx
14 xxx xxxx xxx
15 xxxxxxxx
16 xxx xxxx xxxx
17 56391690
18 xxxxxxxx
19 909 5912 000
19 909 5910 000
20 xxxxxxxx
21 56324497
22 xxx xxxx xxx
23 909 5197 000
24 xxx xxxx xxx
25 xxx xxxx xxx
26 909 5370 000
27 xxx xxxx xxx
28 909 5300 000
29 xxx xxxx xxx
30 xxx xxxx xxx
31 xxx xxxx xxx
32 xxx xxxx xxx
33 xxx xxxx xxx
34 909 5199 000
35# xxxxxxxx
36 xxx xxxx xxx
37 909 5200 000
38 909 5371 000
39# xxx xxxx xxx
40 xxx xxxx xxx
41 xxx xxxx xxx
41 xxx xxxx xxx
42 xxx xxxx xxx
43 xxx xxxx xxx
44 909 5383 000
45 909 5384 000
46 909 5476 000
47 909 5386 000
48 909 5387 000
48 909 5919 000
49 xxx xxxx xxx
50 xxx xxxx xxx
51 08602117
Plus 24D/ 26D/ 28D/ 24C/ 28C
Qty Description
1 Cover vacuum motor (Motor,vacuum cover kit)
1 O-ring
1 Gasket
1 Clamp, hose fixing
5 Clamp, hose fixing
1 Gasket, vacuum motor (Motor,vacuum cover kit)
1 Drain hose
1 Hose vacuum motor
1 Vacuum hose
1 Screw socket hd M5x12
2 Screw socket hd M6x55 (Cage float Hardware kit)
3 Screw M5x10 SS (Motor,vacuum cover kit)
2 Washer flat (Cage float fitting kit)
2 Screw pan hd 6x40 SS (Cage float fitting kit)
1 Floating ball
1 Gasket (Cage float fitting kit)
1 Kit recovery tank replace 909 5446 000
1 Recovery tank
1 Holder, float cage (Cage float fitting kit)
2 Cage, float
2 Cap (Cage float Hardware kit)
1 Acoustic insulation
1 Washer 8 (Motor,vacuum fitting kit)
1 Gasket (Motor,vacuum fitting kit)
1 Vacuum motor kit
1 Protection (Motor,vacuum fitting kit)
1 Acoustic insulation
3 Vibration damping (Motor,vacuum fitting kit)
5 Washer flat (Motor,vacuum fitting kit-Cage float Hardware kit)
1 Washer flat (Motor,vacuum fitting kit)
1 Screw hex hd M8x16 (Motor,vacuum fitting kit)
2 Screw M8x10 (Motor,vacuum fitting kit)
1 Hose, flexible w/elbows
3 Screw M6x12 (Motor,vacuum fitting kit)
3 Wing nut M6 (Motor,vacuum fitting kit)
1 Support
2 Carbon brush
1 Screw socket hd M6x12 (Tank, fitting kit)
1 Washer flat 6x12,5 SS (Tank, fitting kit)
1 Bracket (Tank, fitting kit) see TSB IT 2005-003
1 Bracket (Tank, fitting kit) see TSB IT 2005-003
1 Screw M6x10 (Tank, fitting kit)
3 Screw thd form 3,5x9,5 (Motor,vacuum cover kit)
1 Motor,vacuum cover kit (2-7-14-43)
1 Cage float Hardware kit (30-13-22)
1 Cage float fitting kit (15-16-18-20-49-50)
1 Motor,vacuum fitting kit (24-25-27-29-30-31-32-33-35-36)
1 Tank, fitting kit see TSB IT 2005-003 (39-40-41-42)
1 Tank, fitting kit see TSB IT 2005-003 (39-40-41-42)
2 Nut hex M6 SS (Cage float fitting kit)
2 Nut blind M6 SS (Cage float fitting kit)
1 Cap for tank
7
909 5429 000(3)2006-02
