Squeegee System - KENT Razor Plus 24C Parts List

2004-12

SQUEEGEE SYSTEM

RAZOR
TM
2006-02
Item No. Ref. No.
1 909 5218 000
2 08601574
3 08601854
4 146 1232 000
5 56325538
6 xxxxxxxx
7 xxxxxxxx
8 56325621
9 146 1498 000
10 08602422
11 xxx xxxx xxx
12 08361400
13 08600317
14 08601509
15 xxxxxxxx
16 909 5216 000
17 xxxxxxxx
18 909 5217 000
19 56471194
20 909 5348 000
20* 909 5513 000
21 56363855
22 08603665
23 909 5487 000
24 08603688
25 08603896
26 08603880
27 08603666
28 08603685
29 08603684
30 145 0461 000
31 909 5350 000
32 08812937
33 909 5349 000
34 909 5352 000
35 909 5351 000
36 08603675
37# 08603687
38 909 5396 000
39 909 5373 000
40 08812948
41 08603879
[42]* 909 5466 000
43 08603689
Plus 28D/ 28C
Qty Description
1 Fork
1 Handwheel M8x55
2 Spacer ø7xø10x8
1 Spacer ø15xø20x4
2 Washer flat 6x18
1 Washer flat 10x30 (Hardware squeegee holder kit)
1 Screw hex hd M10x70 (Hardware squeegee holder kit)
2 Screw hex hd M6x25
1 Screw M12x30
1 Spacer ø8xø10x7
1 Nut hex low M10 selflock (Hardware squeegee holder kit)
2 Nut hex low M6 selflock.
2 Nut hex low M8
1 Pin, squeegee support
1 Bushing ø10,4xø14x45 (Hardware squeegee holder kit)
1 Plate, squeegee support
2 Washer flat 15x25 nylon (Hardware squeegee holder kit)
1 Squeegee support
1 Latch (Kit squeegee Razor
1 Blade front (Kit squeegee Razor
1 Non marking front blade
2 Roller bumper (Kit squeegee Razor
2 Squeegee wheel (Kit squeegee Razor
1 Weldment squeegee tool (Kit squeegee Razor
6 Nut hex M5 SS (Kit squeegee Razor
2 Screw hex hd M5x45 SS (Kit squeegee Razor
1 Kit squeegee bumper roller(Kit squeegee Razor
2 Bracket squeegee wheel (Kit squeegee Razor
2 Nut hex self lock M4 SS (Kit squeegee Razor
2 Screw pan phil M4x10 SS (Kit squeegee Razor
11 Wing nut M6 (Kit squeegee Razor
1 Blade rear (Kit squeegee Razor
2 Spacer ø6,3xø9,5x21 (Kit squeegee Razor
1 Strap front (Kit squeegee Razor
1 Strap right rear (Kit squeegee Razor
1 Strap left rear (Kit squeegee Razor
2 Thumb nut squeegee fixing (Kit squeegee Razor
4 Screw hex hd 5x20 SS (Kit squeegee Razor
1 Hardware squeegee holder kit (6-7-11-15-17)
1 Kit squeegee Razor
TM
4,35,36,37,40,41)
2 Spacer, squeegee wheel (Kit squeegee Razor
1 Kit squeegee wheel (Kit squeegee Razor
1 Blades oil resistant kit Razor
2 Washer flat 6x18 SS (Kit squeegee bumper, Kit squeegee Razor
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C) (21-32-43)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C)
TM
Plus 28D-28C assembled (19,20,21,22,23,24,25,26,27,28,29,30,31,32,33,3
Plus 28D-28C)
TM
Plus 28D-28C) (22-24-25-27-37-40)
TM
Plus 28D-28C
TM
Plus 28D-28C)
TM
909 5429 000(3)2006-02
19
