Solution Tank - KENT Razor Plus 24C Parts List

2004-12

SOLUTION TANK

RAZOR
TM
2006-02
Item No. Ref. No.
1* 909 5327 000
[2]# 909 5475 000
3 909 5234 000
4 909 5236 000
5 08095000
6 xxx xxxx xxx
7 56412093
8 08603916
9 xxx xxxx xxx
10 xxx xxxx xxx
11 909 5235 000
12 56325624
13 145 9120 000
14 xxxxxxxx
15 145 9341 000
16 xxx xxxx xxx
17 145 1768 000
18 145 9828 000
19 xxxxxxxx
20 08812967
21 08812966
22 909 5835 000
23 xxxxxxxx
24 xxx xxxx xxx
25 909 5445 000
26 909 5238 000
26 909 5771 000
27 xxxxxxxx
28 xxx xxxx xxx
29 xxxxxxxx
30# 56325553
31 146 0116 00
32 909 5447 000
33 08603117
34 909 5301 000
35 08603668
36 08603228
37 909 5381 000
38 909 5382 000
40 xxx xxxx xxx
41 909 5954 000
42 56325587
43 08361400
44a 146 0454 000
45a 909 5906 000
46a 909 5905 000
47# 909 6263 000
a: see TSB IT 2005 - 003
Plus 24D/ 26D/ 28D/ 24C/ 28C
Qty Description
1 Extractible feed hose
1 Decal kit, Razor Plus 24D/ 26D/ 28D/ 24C/ 28C [(29, 40, page 5) (24, page 11) (59,66,67,68,69,
TM
page 35)]
1 Bracket, tank fixing
1 Closure, fresh water hose
2 O-Ring
1 Clamp (Elbow, solution tank kit)
2 Clamp
2 Clamp
1 Gasket (Elbow, solution tank kit)
2 Washer split (Tank fitting kit)
1 Hose, fresh water
4 Cap, tank locking
2 Washer flat 8x17
2 Washer flat 8x24 (Tank fitting kit)
5 Washer flat 5x20
2 Screw hex hd M8x20 (Tank fitting kit)
4 Screw socket hd M5x12
1 Screw socket hd M8x35
2 Screw sunk hd M8x12 (Tank fitting kit)
1 Clamp
1 Clamp
5 Handwheel M5x10
2 Washer flat 20,5x37 (Tank fitting kit)
1 Elbow 90° ø10 (Elbow, solution tank kit)
Fresh water tank
1 Bumper, front
1 Bumper, front for cylindrical deck
2 Bushing (Tank fitting kit)
2 Pin (Tank fitting kit)
2 Decal, water faucet (Decal kit, Razor
2 Vibration damping
2 Screw socket hd M6x25
Cover, tank
2 Sleeve
1 Rubber band
4 Screw cyl hd 4x14 thd form
1 Gasket
1 Tank fitting kit (10-14-16-19-23-27-28)
1 Elbow, solution tank kit (6-9-24)
2 Decal Razor Plus (Decal kit, Razor
TM
1 Screw M8x50
1 Washer flat 8x17
1 Nut hex low selflocking M6
3 Screw 3,9x16 thd forming - see TSB IT 2005 - 003
1 Plate rubber fixing - see TSB IT 2005 - 003
1 Water protection rubber - see TSB IT 2005 - 003
2 Column plate support
Plus 24D/ 26D/ 28D/ 24C/ 28C)
TM
Plus 24D/ 26D/ 28D/ 24C/ 28C)
TM
5
909 5429 000(3)2006-02
