Wiring System - KENT Razor Plus 24C Parts List

2004-12

WIRING SYSTEM

RAZOR Plus 24D/ 26D/ 28D /24C /28C
2006-02 TM
Item No. Ref. No.
1 909 5478 000
2 xxx xxxx xxx
3 xxx xxxx xxx
4 145 6063 000
5 xxx xxxx xxx
6 xxx xxxx xxx
7 xxx xxxx xxx
8 909 5374 000
9 909 5309 000
10 xxx xxxx xxx
11 145 4799 000
12 xxx xxxx xxx
13 909 5313 000
14 909 5219 000
15 909 5323 000
16 909 5223 000
17 146 0659 000
18 145 8046 000
19 909 5749 000
20 909 5255 000
21 145 3798 000
22 909 5436 000
23 145 9144 000
24# 56001954
25 145 1980 000
26# 145 1261 000
27 08603689
28 xxx xxxx xxx
29 xxxxxxxx
30 145 1162 000
31 145 9141 000
32 145 1238 000
33 145 4485 000
34 xxx xxxx xxx
35# xxx xxxx xxx
36 xxx xxxx xxx
37# 145 9253 000
38 909 5519 000
39 xxx xxxx xxx
40 145 9740 000
41 08812322
42 145 9124 000
43 xxxxxxxx
44 xxxxxxxx
45 xxxxxxxx
46 909 5314 000
47 xxx xxxx xxx
48 08603682
49 xxx xxxx xxx
50 145 9961 000
51 xxxxxxxx
52 08050200
53 xxx xxxx xxx
54 145 1756 000
55 909 5777 000
56 xxx xxxx xxx
57 xxx xxxx xxx
Qty Description
1 Battery charger kit
1 Pulley (Wiring system Hardware kit)
1 Squeegee lift cable (Squeegee lever cable kit)
1 Battery connector
1 Spacer ø8,2xø12x9,6 (Squeegee lever Hardware kit)
1 Spacer ø6,5xø12x10 (Wiring system Hardware kit)
1 Spacer ø8,2xø12x13,5 (Wiring system Hardware kit)
1 Gasket leng.1200 mm
1 Drive switch
1 Lever (Squeegee lever Hardware kit)
1 Microswitch
2 Spring (Squeegee lever Hardware kit)
1 Inspection plate
1 Support
1 Fixing plate
1 Knob
1 Fuse holder
1 Fuse holder
1 Functions electronic board
1 Drive electronic board
2 Chock ø12
4 Spacer
2 Washer flat 4x9
4 Washer flat 5x10
1 Functions fuse 100A
3 Washer flat 5x15
8 Washer flat 6x18
3 Washer flat 6x18 (Squeegee lever cable kit- Wiring system hardware kit)
1 Screw M4x5 (Squeegee lever cable kit)
2 Screw hex hd M3x20
2 Screw hex hd M4x16
2 Screw hex hd M5x10
2 Screw hex hd M5x25
1 Screw hex hd M6x20 (Squeegee lever cable kit)
1 Screw M8x20 (Squeegee lever Hardware kit)
1 Screw hex hd M8x30 (Wiring system Hardware kit)
9 Screw M5x16
1 Gasket L=260 mm
1 Screw M6x20 (Squeegee lever cable kit)
2 Screw M6x30
2 Spacer ø5xø8x8
2 Nut hex self lock M3
1 Nut hex self lock M6 (Squeegee lever cable kit)
1 Nut hex low self lock M8 (Squeegee lever Hardware kit)
1 Nut hex low M6 (Wiring system Hardware kit)
1 Protection
1 Nut hex self lock M8 SS (Wiring system Hardware kit)
2 Nut hex self lock M6 SS
2 Nut hex M6 SS (Squeegee lever cable kit)
2 Washer flat 6x12,5
2 Washer flat 8x17 SS (Wiring system Hardware kit)
4 Nut cap M6
1 Screw M6x20 SS (Wiring system Hardware kit)
2 Screw 2,9x9,5 thd from SS
1 Electronic card cover starting from serial no. 1776829
1 Spacer (Squeegee lever Hardware kit)
1 Plate (Wiring system Hardware kit)
33
909 5429 000(3)2006-02
