Squeegee System - KENT Razor Plus 24C Parts List

2004-12

SQUEEGEE SYSTEM

RAZOR
TM
2006-02
Item No. Ref. No.
1 909 5218 000
2 08601574
3 08601854
4 146 1232 000
5 56325538
6 xxxxxxxx
7 xxxxxxxx
8 56325621
9 146 1498 000
10 08602422
11 xxx xxxx xxx
12 08361400
13 08600317
14 08601509
15 xxxxxxxx
16 909 5216 000
17 xxxxxxxx
18 909 5217 000
19 56471194
20 08603830
20* 909 5629 000
21 56363855
22 08603665
23 909 5294 000
24 08603687
25 08603688
26 08812948
27 08603879
28 08603685
29 08603684
30 145 0461 000
31 08603666
32 08812937
33 08603831
34 08603834
35 08603833
36 08603675
37 08603832
38 08603880
39 909 5372 000
40 909 5396 000
[41]* 08603973
42 08603896
43 08603689
Plus 24D/ 26D/ 24C
Qty Description
1 Fork
1 Handwheel M8x55
2 Spacer ø7xø10x8
1 Spacer ø15xø20x4
2 Washer flat 6x18
1 Washer flat 10x30(Hardware squeegee holder kit)
1 Screw hex hd M10x70(Hardware squeegee holder kit)
2 Screw hex hd M6x25
1 Screw M12x30
1 Spacer ø8xø10x7
1 Nut hex low M10 selflock (Hardware squeegee holder kit)
2 Nut hex low M6 selflock.
2 Nut hex low M8
1 Pin, squeegee support
1 Bushing ø10,4xø14x45 (Hardware squeegee holder kit)
1 Plate, squeegee support
2 Washer flat 15x25 nylon (Hardware squeegee holder kit)
1 Squeegee support
1 Latch (Kit squeegee Razor
1 Blade front (Kit squeegee Razor
1 Non marking front blade
2 Roller bumper (Kit squeegee Razor
2 Squeegee wheel (Kit squeegee Razor
1 Weldment squeegee tool(Kit squeegee Razor
4 Screw hex hd M5x20 SS(Kit squeegee Razor
6 Nut hex self lock M5 SS(Kit squeegee Razor
2 Spacer, squeegee wheel(Kit squeegee Razor
1 Kit squeegee wheel (Kit squeegee Razor
2 Nut hex self lock M4 SS (Kit squeegee Razor
2 Screw pan phil M4x10 SS (Kit squeegee Razor
10 Wing nut M6 (Kit squeegee Razor
2 Bracket squeegee wheel(Kit squeegee Razor
2 Spacer ø6,3xø9,5x21 (Kit squeegee Razor
1 Strap front (Kit squeegee Razor
1 Strap right rear (Kit squeegee Razor
1 Strap left rear (Kit squeegee Razor
2 Thumb nut squeegee fixing (Kit squeegee Razor
1 Blade rear(Kit squeegee Razor
1 Kit squeegee bumper roller (Kit squeegee Razor
1 Kit squeegee Razor
TM
25-26-27-28-29-30-31-32-33-34-35-36-37-38-42-43)
1 Hardware squeegee holder kit (6-7-11-15-17)
1 Blades oil resistant kit Razor
2 Screw hex hd M5x45 SS (Kit squeegee Razor
2 Washer flat 6x18 SS (Kit squeegee bumper roller - Kit squeegee Razor
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/26D/24C)
TM
Plus 24D/26D/24C)
TM
Plus 24D/26D/24C)
TM
Plus 24D/26D/24C)
TM
Plus 24D/26D/24C) (22-24-25-26-31-42)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C)
TM
Plus 24D/ 26D /24C) (21-32- 43)
TM
Plus 24D/ 26D /24C assembled (19-20-21-22-23-24-
Plus 24D/ 26D /24C
TM
Plus 24D/ 26D /24C - Kit squeegee wheel)
TM
17
Plus 24D/ 26D /24C)
TM
909 5429 000(3)2006-02
